htop graph style

htop 이 armbian 에서는 온도도 나오고 좋아 보이길래 어떻게 설정하나 찾아보는데

htop 홈페이지에서 cpu 그래프가.. 신기한게 보여서 빌드도 해보는데 안되서 좌절하다가

[링크 : https://htop.dev/screenshots.html]

[링크 : https://github.com/htop-dev/htop]

htop graph 로 검색해보니 먼가 걸려나온다.

Remember you can press space bar to change the meter style. That way you can get the graph display you want.
And by the way, graph display for Load average will not probably work what you expect. It's work-in-progress. Patches are welcome.

[링크 : https://github.com/hishamhm/htop/issues/440]

F2(setup) 에서 Meters에 하단에 보니 Space / Style!

아무튼 CPU와 같은 녀석들은 [Bar] 라고 되어있는데 이걸 space 누르면 스타일이 변경된다.

저작자표시 (새창열림)

'Linux > Ubuntu' 카테고리의 다른 글

edid-read (0)	2023.08.17
ubutnu file(파일) 에서 삼바 목록 안나오고 부적절한 인수 에러 (0)	2023.07.24
mono-complete (0)	2023.07.05
ubuntu 22.04 wayland vs x.org on 4K dual (0)	2023.06.26
ubuntu 22.04 GUI/CLI 부팅 (0)	2023.06.18

Posted by 구차니

valgrind callgrind

valgrind는 일반적으로 메모리 누수를 찾는데 쓰지만

call graph라고 해야하나? call 관련 추적도 가능하다고 하니 다음에 돌려봐야겠다.

tool에 여러가지 있는데 cachegrind 정도만 찾아봤던 흔적이 있네..

$ valgrind --tool=
32bit-core     arm-core       i386           mips64-cpu     power64-linux
32bit-linux    arm-vfpv3      lackey         mips64-fpu     powerpc
32bit-sse      arm-with       massif         none           s390-acr
64bit-avx      cachegrind     memcheck       power-altivec  s390-fpr
64bit-core     callgrind      mips           power-core     s390-vx
64bit-linux    dhat           mips-cp0       power-fpu      s390x
64bit-sse      drd            mips-cpu       power-linux    s390x-core64
amd64          exp-bbv        mips-fpu       power-vsx      s390x-linux64
amd64-avx      getoff         mips64         power64-core   s390x-vx
arm            helgrind       mips64-cp0     power64-core2

[링크 : https://jchern.tistory.com/13]

[링크 : https://velog.io/@wjddms206/Valgrind-프로파일러-callgrind]

+

[링크 : http://www.cs.columbia.edu/~sedwards/presentations/iccad2003-somenzi.pdf]

[링크 : https://fileadmin.cs.lth.se/cs/Education/EDAF15/labs/lab4/index.html]

저작자표시 (새창열림)

'프로그램 사용 > valgrind' 카테고리의 다른 글

valgrind 누수 종류 (0)	2022.01.18
vaglind 사용 (0)	2022.01.14
valgrind 지원 플랫폼 (0)	2014.10.15
valgrind GUI frontend- kcachegrind / valkyrie (0)	2014.10.15

Posted by 구차니

openOCD와 jtag

문득.. JTAG은 표준인데 왜 업체별로 다르지? 라는 생각에 검색하다 보니

공용으로 쓸 수 있는진 모르겠지만

openOCD를 이용하면 viviado 등이 없어도 FPGA에 쓸 수 있다고 하는걸 봐서는

openOCD가 각종 jtag를 지원한다고 보는게 맞을 듯.

We decided to support both urJTAG and the well known OpenOCD out of the box.

Supported devices
The list of supported devices is constantly being expanded and here is a small selection of the supported devices.

ARM7TDMI » fx LPC2148, AT91SAM7
ARM720T » fx LH79520, EP7312
ARM9TDMI
ARM920T » fx S3C2410, S3C2440
ARM922T
ARM926EJS » fx S3C2412, STN8811, STN8815
ARM966E » fx STR91XF
ARM11 » fx S3C6400, OMAP2420, MSM7200
ARM1136
ARM1156
ARM1176
CORTEX-M1 » fx LPC11 series
CORTEX-M3 » fx LM3S series, STM32F1/F2/F3 series, LPC17 series
CORTEX-M4 » fx STM32F4
CORTEX-A8 » fx OMAP3530 BeagleBoard
CORTEX-A8 » fx DM3730 BeagleBoard-xM
CORTEX-A9 » fx OMAP4430 PandaBoard
XSCALE » fx PXA255, PXA270, IXP42X
MARVEL » fx FEROCEON CPU CORE
FPGA » fx Xilinx Spartan, Virtex or Altera Cyclone, Stratix
CPLD » fx Xilinx CoolRunner or Altera MAX

Technical details
The board itself is 5 by 5 cm with a USB B connector at one side and JTAG and IO headers at another.

The JTAG port supports a wide range of voltages, as it is connected to a couple of voltage translators (74LVC2T45). This makes the uniJTAG even more universal, as you can use it together with any JTAG�able device, running at 1.2V to 5.5V.

The IO header can be used as 8 single controllable IO�s, or it can be used as a full standard UART port. With a jumper you can chose whether the IO�s should be at a 5V level, or a 3.3V level.

The board has also an onboard EEProm for storing the FT2232 configurations, so the uniJTAG is a plug and play solution, and it automatically enumerates as a JTAG and a Serial device.

[링크 : http://www.tkjelectronics.dk/?p=products&product=unijtag]

다른 JTAG을 사용..

$ lsusb
Bus 001 Device 006: ID 0403:6014 Future Technology Devices International, Ltd FT232H Single HS USB-UART/FIFO IC
Bus 001 Device 028: ID 09fb:6001 Altera Blaster

$ sudo /opt/openocd/bin/openocd -d \
             -f /opt/openocd/share/openocd/scripts/interface/ftdi/digilent_jtag_smt2.cfg \
             -f /opt/openocd/share/openocd/scripts/cpld/xilinx-xc6s.cfg \
             -c "adapter_khz 1000"

$ sudo /opt/openocd/bin/openocd \
             -f /opt/openocd/share/openocd/scripts/interface/altera-usb-blaster.cfg \
             -f /opt/openocd/share/openocd/scripts/cpld/xilinx-xc6s.cfg \
             -c "adapter_khz 1000; init; xc6s_program xc6s.tap; pld load 0 ./ise/top.bit ; exit"

[링크 : https://tomverbeure.github.io/2019/09/15/Loading-a-Spartan-6-bitstream-with-openocd.html]

저작자표시 (새창열림)

'embeded > ARM' 카테고리의 다른 글

ARM NEON SLP (0)	2023.08.07
cortex a9 ptm (0)	2023.07.21
cmsis (Common Microcontroller Software Interface Standard) (0)	2023.02.27
i.mx8m plus arm trust zone (0)	2023.02.24
ampere altra / 기가바이트 R272-P30 / 우분투 (0)	2023.02.03

Posted by 구차니

html canvas와 시간 그래프 흘리기

canvas에 먼가 그려져 있어야 테스트를 하니 일단 줄을 그리고

const canvas = document.getElementById("myCanvas");
const ctx = canvas.getContext("2d");

// Start a new Path
ctx.beginPath();
ctx.moveTo(0, 0);
ctx.lineTo(300, 150);

// Draw the Path
ctx.stroke();

[링크 : https://www.w3schools.com/jsref/canvas_lineto.asp]

여기서 나오는 waterfall display를 canvas로 간단하게 그려보려고 하니

[링크 : https://www.arc.id.au/Spectrogram.html]

간간히 아래와 같은 경고? 에러가 나지만 일단 무시하고 실행은 가능하니 나중에 찾아봐야 할 듯.

tt.html:27 Canvas2D: Multiple readback operations using getImageData are faster with the willReadFrequently attribute set to true. See: https://html.spec.whatwg.org/multipage/canvas.html#concept-canvas-will-read-frequently

[링크 : https://html.spec.whatwg.org/multipage/canvas.html#concept-canvas-will-read-frequently]

getImageData를 이용하여 좌상단으로 부터 가장 아래 1줄 빼고 복사하고

putImageData를 이용하여 복사한 그림을 위에 1줄 비우고 붙여넣는다.

결과적으로 가장 왼쪽 위 1픽셀은 남은채 나머지는 아래로 흘러내리는 애니메이션 완성!

<!DOCTYPE html>
<html>
<head>
</head>
<body>
    <canvas id="sepctrograph" height=500 width=1800></canvas>
    <script>
        function init_canvas()
        {
            canvas = document.getElementById("sepctrograph")
            ctx = canvas.getContext("2d");

            // Start a new Path
            ctx.beginPath();
            ctx.moveTo(0, 0);
            ctx.lineTo(300, 150);

            // Draw the Path
            ctx.stroke();
        }

        function flow_canvas()
        {
            console.log("ing");
            canvas = document.getElementById("sepctrograph")
            ctx = canvas.getContext("2d");
            imgObj = ctx.getImageData(0,0, canvas.width, canvas.height - 1);
            ctx.putImageData(imgObj, 0, 1); // next line draw
        }

        init_canvas();
        setInterval(flow_canvas, 1000);

    </script>
    </body>
</html>

+

새로 생성하지 않고 getImageData로 받은건 이상하게 편집이 안되는 느낌이라..

그냥 높이 1짜리로 새롭게 만들어서, 가장 위에 한줄 넣는게 무난한 듯.

const myImageData = ctx.createImageData(width, height);

[링크 : https://developer.mozilla.org/en-US/docs/Web/API/Canvas_API/Tutorial/Pixel_manipulation_with_canvas]

저작자표시 (새창열림)

'Programming > javascript & HTML' 카테고리의 다른 글

숫자에 콤마 찍기(자릿수 표현) (0)	2023.07.27
canvas 없는 getcontext (0)	2023.07.12
javascript 정수는 정수가 아니다 (0)	2023.04.06
websocket binarytype (0)	2023.04.04
자바스크립트 소수점 자르기 (0)	2023.03.13

Posted by 구차니

orange pi 3 install_to_emmc 는 실패, dd는 성공

sd 카드 내용 전체를 eMMC로 복사하니 된다. 이게 머야(!)

[링크 : https://www.reddit.com/r/OrangePI/comments/vpzhjw/how_can_i_put_a_os_in_the_emmc_3_lts/]

+

안되잖아?!

$ wget https://raw.githubusercontent.com/loboris/OrangePi-BuildLinux/master/install_to_emmc
$ chmod +x install_to_emmc
$ sudo ./install_to_emmc
Thu 06 Jul 2023 02:34:17 AM UTC
===============================
Installing Linux system to emmc
===============================

Error: boot0_OPI.fex not found.

+

차라리 armbian 기반에 해야하려나?

[링크 : https://forum.libreelec.tv/thread/25388-orange-pi-3-emmc-install/]

-------

사용자 메뉴얼에 보면 install_to_emmc 치면 설치된다는데

정작 Orangepi3_2.1.0_ubuntu_focal_desktop_linux5.4.65.img 이미지를 이용해서 부팅해보면

해당 스크립트가 없다. debian도 아니고 ubuntu focal 이면 20.04인데

자기들이 릴리즈 하고 어디서 받으라는 말도 없는건 도대체 멀까?

3. Program Linux system into EMMC Flash chip through script
If you purchased the Orange Pi 3 development board with EMMC Flash chip, after booting the Linux system through the TF card, you can also burn the Linux system into EMMC Flash through the install_to_emmc script.
Enter the install_to_emmc command in the Linux terminal, and then enter y as prompted, and the Linux system will automatically be burned into EMMC Flash. After the programming is complete, turn off the power, remove the TF card, and then power on the Linux system in EMMC Flash automatically.

root@OrangePi:~# install_to_emmc
WARNING: EMMC WILL BE ERASED !, Continue (y/N)? y
Erasing EMMC ...
Creating new filesystem on EMMC ...
New filesystem created on /dev/mmcblk0.
Partitioning EMMC ...
Creating boot & linux partitions
OK.
Formating fat partition ...
fat partition formated.
Formating linux partition (ext4), please wait ...
linux partition formated.
Instaling u-boot to EMMC ...
Mounting EMMC partitions...
FAT partitions mounted to /tmp/_fatdir
linux partition mounted to /tmp/_extdir
Copying file system to EMMC ...
Creating "fstab"
*******************************
Linux system installed to EMMC.
*******************************

인터넷 찾아보니

아래 스크립트가 나오는데 sd로 부팅하니 mmcblk1 : mmc1:0001 8GTF4R 7.28 GiB 라고 나오는걸 보면

/dev/mmcblk1이 emmc

/dev/mmcblk2 가 sdcard인것 같은데

스크립트 내용으로는 sdcard 변수가 emmc 경로여야 한다.

파일 전체 수정으로 emmc 라고 이름을 좀 바꿔주던가 헷갈리구루

#!/bin/bash

if [ "$(id -u)" != "0" ]; then
   echo "Script must be run as root !"
   exit 0
fi

echo ""
date
echo -e "\033[36m==============================="
echo "Installing Linux system to emmc"
echo -e "===============================\033[37m"
setterm -default
echo ""

_format=${1}

fatsize=64

sdcard="/dev/mmcblk1"
odir="/tmp/_extdir"
bootdir="/tmp/_fatdir"

if [ ! -b ${sdcard}boot0 ]; then
    echo "Error: EMMC not found."
    exit 1
fi
if [ ! -f /boot/boot0_OPI.fex ]; then
    echo "Error: boot0_OPI.fex not found."
    exit 1
fi
if [ ! -f /boot/u-boot_OPI-emmc.fex ]; then
    echo "Error: u-boot_OPI-emmc.fex not found."
    exit 1
fi

umount ${sdcard}* > /dev/null 2>&1
#----------------------------------------------------------
echo ""
echo -n "WARNING: EMMC WILL BE ERASED !, Continue (y/N)?  "
read -n 1 ANSWER

if [ ! "${ANSWER}" = "y" ] ; then
    echo "."
    echo "Canceled.."
    exit 0
fi
echo ""
#----------------------------------------------------------

echo "Erasing EMMC ..."
dd if=/dev/zero of=${sdcard} bs=1M count=32 > /dev/null 2>&1
sync
sleep 1

echo "Creating new filesystem on EMMC ..."
echo -e "o\nw" | fdisk ${sdcard} > /dev/null 2>&1
sync
echo "  New filesystem created on $sdcard."
sleep 1
partprobe -s ${sdcard} > /dev/null 2>&1
if [ $? -ne 0 ]; then
    echo "ERROR."
    exit 1
fi
sleep 1

echo "Partitioning EMMC ..."
sfat=40960
efat=$(( $fatsize * 1024 * 1024 / 512 + $sfat - 1))
echo "  Creating boot & linux partitions"
sext4=$(( $efat + 1))
eext4=""
echo -e "n\np\n1\n$sfat\n$efat\nn\np\n2\n$sext4\n$eext4\nt\n1\nb\nt\n2\n83\nw" | fdisk ${sdcard} > /dev/null 2>&1
echo "  OK."
sync
sleep 2
partprobe -s ${sdcard} > /dev/null 2>&1
if [ $? -ne 0 ]; then
    echo "ERROR."
    exit 1
fi
sleep 1

echo "Formating fat partition ..."
dd if=/dev/zero of=${sdcard}p1 bs=1M count=1 oflag=direct > /dev/null 2>&1
sync
sleep 1
mkfs.vfat -n EMMCBOOT ${sdcard}p1 > /dev/null 2>&1
if [ $? -ne 0 ]; then
    echo "  ERROR formating fat partition."
    exit 1
fi
echo "  fat partition formated."

dd if=/dev/zero of=${sdcard}p2 bs=1M count=1 oflag=direct > /dev/null 2>&1
sync
sleep 1
if [ "${_format}" = "btrfs" ] ; then
    echo "Formating linux partition (btrfs), please wait ..."
    # format as btrfs
    mkfs.btrfs -O ^extref,^skinny-metadata -f -L emmclinux ${sdcard}p2 > /dev/null 2>&1
    if [ $? -ne 0 ]; then
        echo "ERROR formating btrfs partition."
        exit 1
    fi
else
    echo "Formating linux partition (ext4), please wait ..."
    mkfs.ext4 -L emmclinux ${sdcard}p2 > /dev/null 2>&1
    if [ $? -ne 0 ]; then
        echo "ERROR formating ext4 partition."
        exit 1
    fi
fi
echo "  linux partition formated."

#************************************************************************
echo ""
echo "Instaling u-boot to EMMC ..."
dd if=/boot/boot0_OPI.fex of=${sdcard} bs=1k seek=8 > /dev/null 2>&1
if [ $? -ne 0 ]; then
    echo "ERROR installing u-boot."
    exit 1
fi
dd if=/boot/u-boot_OPI-emmc.fex of=${sdcard} bs=1k seek=16400 > /dev/null 2>&1
if [ $? -ne 0 ]; then
echo "ERROR installing u-boot."
exit 0
fi
sync
#************************************************************************

# -------------------------------------------------------------------

if [ ! -d $bootdir ]; then
    mkdir -p $bootdir
fi
rm $bootdir/* > /dev/null 2>&1
sync
umount $bootdir > /dev/null 2>&1

if [ ! -d $odir ]; then
    mkdir -p $odir
fi
rm -rf $odir/* > /dev/null 2>&1
sync
umount $odir > /dev/null 2>&1
sleep 1

# ================
# MOUNT PARTITIONS
# ================

if [ "${_format}" = "btrfs" ] ; then
    _mntopt="-o compress-force=lzo"
else
    _mntopt=""
fi

echo ""
echo "Mounting EMMC partitions..."

if ! mount ${sdcard}p1 $bootdir; then
    echo "ERROR mounting fat partitions..."
    exit 1
fi
if ! mount ${_mntopt} ${sdcard}p2 $odir; then
    echo "ERROR mounting linux partitions..."
    umount $bootdir
    exit 1
fi
echo "FAT partitions mounted to $bootdir"
echo "linux partition mounted to $odir"

#-----------------------------------------------------------------------------------------------
echo ""
echo "Copying file system to EMMC ..."
echo ""

#-----------------------------------------------------------------------------------------
rsync -r -t -p -o -g -x --delete -l -H -D --numeric-ids -s --stats / $odir/ > /dev/null 2>&1
if [ $? -ne 0 ]; then
    echo "  ERROR."
fi
#-----------------------------------------------------------------------------------------
sync

rm $odir/usr/local/bin/fs_resize_warning > /dev/null 2>&1

echo "  Creating \"fstab\""
echo "# OrangePI fstab" > $odir/etc/fstab
if [ "${_format}" = "btrfs" ] ; then
    echo "/dev/mmcblk0p2  /  btrfs subvolid=0,noatime,nodiratime,compress=lzo  0 1" >> $odir/etc/fstab
else
    echo "/dev/mmcblk0p2  /  ext4  errors=remount-ro,noatime,nodiratime  0 1" >> $odir/etc/fstab
fi
echo "/dev/mmcblk0p1  /media/boot  vfat  defaults  0 0" >> $odir/etc/fstab
echo "tmpfs /tmp  tmpfs nodev,nosuid,mode=1777  0 0" >> $odir/etc/fstab
sync

#-----------------------------------------------------------------------------------------
rsync -r -t -p -o -g -x --delete -l -H -D --numeric-ids -s --stats /media/boot/ $bootdir/ > /dev/null 2>&1
if [ $? -ne 0 ]; then
    echo "  ERROR."
fi
#-----------------------------------------------------------------------------------------
sync

# UMOUNT
if ! umount $bootdir; then
  echo "ERROR unmounting fat partition."
  exit 1
fi
rm -rf $bootdir/* > /dev/null 2>&1
rmdir $bootdir > /dev/null 2>&1

if ! umount $odir; then
    echo "ERROR unmounting linux partitions."
    exit 0
fi

rm -rf $odir/* > /dev/null 2>&1
rmdir $odir > /dev/null 2>&1
sync

echo ""
echo -e "\033[36m*******************************"
echo "Linux system installed to EMMC."
echo -e "*******************************\033[37m"
setterm -default
echo ""

exit 0

[링크 : https://github.com/loboris/OrangePi-BuildLinux/blob/master/install_to_emmc]

저작자표시 (새창열림)

'embeded > orange pi' 카테고리의 다른 글

orange pi 3 못써먹겠네! (0)	2023.07.07
rk3588 HDMI RX interface (0)	2023.06.30
android on orange pi 3 (0)	2022.12.07
allwinner A시리즈 백도어 (0)	2022.11.06
orange pi 3 관련 문서 (0)	2022.01.03

Posted by 구차니

mono-complete

msbuild 쓰라는데

$ xbuild test_proj.sln

>>>> xbuild tool is deprecated and will be removed in future updates, use msbuild instead <<<<

정작 패키지 검색하면 나오는건 xbuild. ubuntu 22.04 에서 mono가 이상한건가?

$ apt-cache search msbuild
mono-xbuild - MSBuild-compatible build system for Mono
libmono-addins-msbuild-cil-dev - MSBuild task library for Mono.Addins
libmono-addins-msbuild0.2-cil - MSBuild task library for Mono.Addins

$ apt-cache search mono-complete
mono-complete - complete Mono runtime, development tools and all libraries

[링크 : https://jjeongil.tistory.com/1988]

저작자표시 (새창열림)

'Linux > Ubuntu' 카테고리의 다른 글

ubutnu file(파일) 에서 삼바 목록 안나오고 부적절한 인수 에러 (0)	2023.07.24
htop graph style (0)	2023.07.07
ubuntu 22.04 wayland vs x.org on 4K dual (0)	2023.06.26
ubuntu 22.04 GUI/CLI 부팅 (0)	2023.06.18
ubuntu dmesg 막혔네? (0)	2023.06.01

Posted by 구차니

fft window type과 진폭 보정계수

Uniform은 rectangular 인 것 같고(1이니까)

그 외에는... Energy correction은 어떻게 써먹어야 하려나?

[링크 : https://community.sw.siemens.com/s/article/window-correction-factors]

저작자표시 (새창열림)

'프로그램 사용 > fft, fftw' 카테고리의 다른 글

tek.com fft 관련 문서 (0)	2023.07.19
sfft (0)	2023.07.12
fft window 함수 (0)	2023.07.03
pFFFT 사용법 (0)	2023.06.15
fft 결과의 amplitude가 0.5가 나오는 이유 (0)	2023.06.13

Posted by 구차니

구차니의 잡동사니 모음

'잡동사니'에 해당되는 글 13451건

개피곤

'개소리 왈왈 > 육아관련 주저리' 카테고리의 다른 글

zynq fsbl

'embeded > FPGA - XILINX' 카테고리의 다른 글

orange pi 3 못써먹겠네!

'embeded > orange pi' 카테고리의 다른 글

htop graph style

'Linux > Ubuntu' 카테고리의 다른 글

valgrind callgrind

'프로그램 사용 > valgrind' 카테고리의 다른 글

openOCD와 jtag

'embeded > ARM' 카테고리의 다른 글

html canvas와 시간 그래프 흘리기

'Programming > javascript & HTML' 카테고리의 다른 글

orange pi 3 install_to_emmc 는 실패, dd는 성공

'embeded > orange pi' 카테고리의 다른 글

mono-complete

'Linux > Ubuntu' 카테고리의 다른 글

fft window type과 진폭 보정계수

'프로그램 사용 > fft, fftw' 카테고리의 다른 글

카테고리

공지사항

태그목록

최근에 올라온 글

최근에 달린 댓글

티스토리툴바
