embeded/i.mx 8m plus2023. 5. 26. 10:56

baudrate 보소.. 이런 변태 같은 -_-

3.1 Serial logging setup
To help troubleshoot issues during boot, use the USB micro-B port on i.MX EVK boards to output U-Boot and
UEFI firmware serial debug logs to a host PC. The USB micro-B port on the EVK presents a virtual serial port to
the host PC, which can be read by common Windows serial terminal applications such as HyperTerminal, Tera
Term, or PuTTY.
1. Connect the target and the PC using the cable mentioned above.
2. Open Device Manager on the PC and locate the Enhanced Virtual serial device and note the COM port
number.
3. Open the terminal on the PC. Configure the Enhanced Virtual serial/COM port to 921600 baud/s, 8-bit, onestop bit.

[링크 : https://www.nxp.com/docs/en/quick-reference-guide/IMXWQSG.pdf]



아무튼 baudrate 맞추니 이상하게 라도 나온다(키보드 인식 안해서 uart를 통해서 제어해야 하다니 -_ㅠ)



Device manager 뜨는게 없다.



Boot Manager 에서는 UEFI 옵션별로 뜨는데



요건 i.mx8mp 보드의 eMMC로 부팅하는거. 어떤 버전이 구워져있는진 모르겠지만

부팅하다가 kernel panic 뜨는데 어쩌면 윈도우용으로 부트로더가 설정하는 바람에

uboot + kernel 에서 설정되지 않는 부분때문에 그런걸지도 모르겠다.



윈도우 IoT 이미지가 2.5MB 밖에 안되서 그런가 SD 카드로 부팅하려고 하면 진행이 안된다.



Boot Maintenance Manager 에서는 먼가 조금 뜨는데 들어간다고 먼가 되는게 있는 것도 아니라서..



그나마 console option 으로 들어가면 input / output / stderr 요런걸로 어떤 장치를 쓸거냐 정도만 나온다.

그냥 윈도우 처럼 GUI 화면은 도대체 어떻게 해야 하냐..
