하드웨어/intel ME&AMT2020. 11. 8. 15:42

여전히 헷갈리는데 intel AMT가 intel ME의  sub systemd으로 보이는데

intel ME만 있을 경우에는 웹 인터페이스나 MEBx 가 안뜨는건가?

아무튼 내 서버에서는 ME 설정은 있어도 MEBx는 없어서 일단 실패..



[링크 : https://www.itkairos.com/168]

'하드웨어 > intel ME&AMT' 카테고리의 다른 글

intel AMT/ME, ubuntu 18.04 /dev/impi  (2) 2020.11.11
Elitebook 2760p 의 intel AMT 접속  (0) 2020.11.11
HP elitebook 2760p / intel ME?  (0) 2020.11.09
intel AMT - bitlocker 우회가능?  (0) 2018.01.15
HP 2710p Intel ME ...?!  (2) 2017.11.28
Posted by 구차니

정확하게는 OCP 하드웨어 스펙 문서

그래도 동일하게 생겨 먹은 녀석에 대한 문서가 보이니 즐겁네

그나저나.. 페이스북 서버?





[링크 : http://files.opencompute.org/oc/public.php?service=files&t=935ae31805d3e7a120bf5b0d08db819c&download]



Facebook server Intel Xeon motherboard v2 (aka Windmill):

[링크 : https://forums.servethehome.com/index.php?threads/open-compute-windmill-v2-motherboard.9638/page-6]

'하드웨어 > Server Case & board' 카테고리의 다른 글

/dev/ipmi0 on ThunderX  (0) 2020.11.12
DCMI / IPMI, ipmiutil  (0) 2020.11.08
redfish  (0) 2020.09.25
벤더별 ipmi 명칭  (0) 2020.09.24
nmap을 이용하여 ILO 포트 검색하기  (0) 2020.09.18
Posted by 구차니

하나 팔았더니 하나가 또 생기네



FINECO FX-4V 라는 모델

음성인식에 FPV 되는 드론





[링크 : https://xcopter.com/product/두로카리스마-fx-4v/28282/]

[링크 : https://play.google.com/store/apps/details?id=com.hk.rd3dvc&hl=en_US&gl=US]

'개소리 왈왈 > 쿼드콥터(RC)' 카테고리의 다른 글

pixhawk  (5) 2024.10.07
RC카 분해 2  (2) 2020.07.24
오늘의 지름 - 메카넘 휠 RC카  (0) 2020.07.23
알카라인과 충전지 차이인가..  (0) 2020.05.16
L298N + RC 카 개조중  (0) 2020.04.29
Posted by 구차니
Linux/Ubuntu2020. 11. 7. 15:24

콴타 서버  파워가 이제 돌려받아져서 오랫만에 켜서 테스트 해보는데

영 안뜨네.. 얘도 ipmi 가 있는것 같긴한데 되는 장비를 못 보겠다 ㅠㅠ

$ sudo apt install ipmitool
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following additional packages will be installed:
  freeipmi-common libfreeipmi17 libopenipmi0 libsensors-config libsensors5
  libsnmp-base libsnmp35 openipmi
Suggested packages:
  freeipmi-tools lm-sensors snmp-mibs-downloader
The following NEW packages will be installed:
  freeipmi-common ipmitool libfreeipmi17 libopenipmi0 libsensors-config
  libsensors5 libsnmp-base libsnmp35 openipmi
0 upgraded, 9 newly installed, 0 to remove and 6 not upgraded.
Need to get 3298 kB of archives.
After this operation, 14.6 MB of additional disk space will be used.
Do you want to continue? [Y/n]

$ ipmitool
Could not open device at /dev/ipmi0 or /dev/ipmi/0 or /dev/ipmidev/0: No such file or directory

$ sudo dmidecode -t 1
# dmidecode 3.2
Getting SMBIOS data from sysfs.
SMBIOS 2.7 present.

Handle 0x0001, DMI type 1, 27 bytes
System Information
        Manufacturer: Quanta
        Product Name: Freedom
        Version: C1
        Serial Number: To be filled by O.E.M.
        UUID: 26f47cac-5bb2-11d9-899f-9c4c68493100
        Wake-up Type: LAN Remote
        SKU Number: 16DIMM
        Family: Server

$ sudo dmidecode -t 2
# dmidecode 3.2
Getting SMBIOS data from sysfs.
SMBIOS 2.7 present.

Handle 0x0002, DMI type 2, 15 bytes
Base Board Information
        Manufacturer: Quanta
        Product Name: Winterfell
        Version: To be filled by O.E.M.
        Serial Number: To be filled by O.E.M.
        Asset Tag: To be filled by O.E.M.
        Features:
                Board is a hosting board
                Board is replaceable
        Location In Chassis: Left
        Chassis Handle: 0x0003
        Type: Motherboard
        Contained Object Handles: 0

$ sudo dmidecode -t 3
# dmidecode 3.2
Getting SMBIOS data from sysfs.
SMBIOS 2.7 present.

Handle 0x0003, DMI type 3, 22 bytes
Chassis Information
        Manufacturer: Quanta
        Type: Rack Mount Chassis
        Lock: Not Present
        Version: To Be Filled By O.E.M.
        Serial Number: To Be Filled By O.E.M.
        Asset Tag: To Be Filled By O.E.M.
        Boot-up State: Safe
        Power Supply State: Safe
        Thermal State: Safe
        Security Status: None
        OEM Information: 0x00000000
        Height: 2 U
        Number Of Power Cords: 1
        Contained Elements: 0
        SKU Number: To be filled by O.E.M.

$ sudo modprobe ipmi_devintf
$ ll /dev/i
i2c-0    initctl  input/
$ sudo modprobe ipmi_si
modprobe: ERROR: could not insert 'ipmi_si': No such device

$ dmesg | tail
[  197.942225] IPMI message handler: version 39.2
[  197.944408] ipmi device interface
[  210.061984] ipmi_si: IPMI System Interface driver
[  210.062167] ipmi_si: Unable to find any System Interface(s)



+

[링크 : http://coffeenix.net/board_print.php?bd_code=1765]

'Linux > Ubuntu' 카테고리의 다른 글

우분투 패키지 버전 확인하기  (0) 2020.12.16
ubuntu 20.04 한글입력기  (2) 2020.12.07
우분투에서 부팅 USB 만들기(iso)  (0) 2020.10.06
jaaa - JACK and ALSA Audio Analyser  (0) 2020.10.05
ipmitool  (0) 2020.09.24
Posted by 구차니
Programming/c# & winform2020. 11. 6. 18:01

+ 2020.11.10



상당히 강력하게 해석을 해주는데 문제는.. 5/1/2008이 5월 1일인지 1월 5일인지 모르겠는데

일단은 "월/일/년" 으로 해석을 해준다. 다른 언어권에서도 저렇게 해주려나?

DateTime.Parse("5/1/2008 8:30:52 AM", System.Globalization.CultureInfo.InvariantCulture)

[링크 : https://docs.microsoft.com/ko-kr/dotnet/api/system.datetime?view=netcore-3.1]



---



[링크 : https://j07051.tistory.com/590]

[링크 : https://stackoverflow.com/questions/15203534/convert-todatetime-how-to-set-format]

[링크 : https://stackoverflow.com/questions/21383045/convert-string-to-datetime-with-form-yyyy-mm-dd-hhmmss-in-c-sharp/21383146]

'Programming > c# & winform' 카테고리의 다른 글

winform c# 폰트 바꾸면 다이얼로그 크기가 바뀐다?  (2) 2020.11.12
C# 시간 관련 클래스  (0) 2020.11.10
c#에서 ini 파일 사용하기  (0) 2020.11.05
C# UTC -> 지역시간  (0) 2020.11.05
c# gps(nmea parser)  (0) 2020.11.05
Posted by 구차니

(keyworda|keywordb)

에 정규표현식으로 검색하면 된다.



[링크 : https://stackoverflow.com/questions/12215896/searching-multiple-files-for-multiple-words/17874867]

'프로그램 사용 > notepad++' 카테고리의 다른 글

notepad++ multi line edit  (0) 2019.12.30
notepad++ for ubuntu?  (0) 2019.12.21
notepad++ 주석 삭제하기  (4) 2018.05.09
notepad++ 특정 라인 열도록 실행하기  (0) 2018.01.02
notepad++ 따옴표 자동완성 끄기  (0) 2017.12.10
Posted by 구차니
Programming/c# & winform2020. 11. 5. 17:46

환경 설정파일로 ini 만한게 없긴하지..



[링크 : https://www.nuget.org/packages/ini-parser/]

[링크 : https://wookoa.tistory.com/417]

[링크 : https://github.com/Enichan/Ini]



'Programming > c# & winform' 카테고리의 다른 글

C# 시간 관련 클래스  (0) 2020.11.10
c# 문자열을 시간으로  (6) 2020.11.06
C# UTC -> 지역시간  (0) 2020.11.05
c# gps(nmea parser)  (0) 2020.11.05
c# label rotate  (0) 2020.11.04
Posted by 구차니

엑셀에서는 아이콘으로 있었는데

메뉴를 한참들어가서 옵션을 열고 체크해줘야 하다니 ㅠㅠ





[링크 : https://www.yangel.org/DODOxe/OfficeOA/6408]

Posted by 구차니

구글 지도 에서 export 가능한 포멧이 GPX인데 XML 기반이다.

GPX를 NMEA(GPS raw data) 형식으로 변환이 가능하면

구글 어스에서 내가 경로를 만들어서 raw 데이터로 쓸 수 있으려나?





gpx to nmea를 해보는데 output data가 NMEA 0183으로 지정된다. NMEA 2000은 파일 포맷이 아닌건가?

그리고 변환해보니 (point.gpx) GPWPL 로만 생성이 된다.



[링크 : https://mygeodata.cloud/converter/gpx-to-nmea]

[링크 : https://mygeodata.cloud/converter/nmea-to-gpx]



[링크 : https://wiki.openstreetmap.org/wiki/Converting/NMEA_to_GPX]

'이론 관련 > 컴퓨터 관련' 카테고리의 다른 글

fp16  (0) 2021.05.10
gps 체크섬  (0) 2020.11.17
NMEA / GPS 날짜&시간  (0) 2020.11.05
온프레미스  (0) 2020.10.27
NMEA 포맷  (0) 2020.10.26
Posted by 구차니
Programming/c# & winform2020. 11. 5. 15:39

위는 결과는 UTC 시간을 출력해주고

아래 결과는 지역시간(한국이니 UTC+9 = KST)으로 출력된다

label2.Text = TimeZoneInfo.ConvertTimeToUtc(DateTime.Now).ToString();
label2.Text = DateTime.Now.ToString();



GPS 에서 사용하는 스타일로 UTC를 출력하기

DateTime utc = TimeZoneInfo.ConvertTimeToUtc(DateTime.Now);
label2.Text = "" + String.Format("{0:D2}", utc.Year % 100) + String.Format("{0:D2}", utc.Month) + String.Format("{0:D2}", utc.Day);
label2.Text += " " + String.Format("{0:D2}", utc.Hour) + String.Format("{0:D2}", utc.Minute) + String.Format("{0:D2}", utc.Second);

[링크 : https://docs.microsoft.com/ko-kr/dotnet/api/system.datetime.tolocaltime?view=netcore-3.1]

[링크 : https://docs.microsoft.com/ko-kr/dotnet/standard/datetime/converting-between-time-zones]



+

2020.11.06



utc를 저장하고 ToLocalTime() 한번 실행해주면 지역시간으로 바뀐다.

public DateTime ToLocalTime ();

[링크 : https://docs.microsoft.com/ko-kr/dotnet/api/system.datetime.tolocaltime?view=netcore-3.1]

'Programming > c# & winform' 카테고리의 다른 글

c# 문자열을 시간으로  (6) 2020.11.06
c#에서 ini 파일 사용하기  (0) 2020.11.05
c# gps(nmea parser)  (0) 2020.11.05
c# label rotate  (0) 2020.11.04
c# tooltip  (0) 2020.11.04
Posted by 구차니
