개소리 왈왈/육아관련 주저리2022. 2. 13. 22:44

배터리 방전 시킬 뻔

지하가 아니라 지상에 차를 대놔서

블랙박스 켜놨는데

일이주 운행안하고 주말에 왕복 30키로? 1시간 정도 운행한걸로는 부족했는지

시동이 한번에 안걸렸다 ㅠㅠ



내일 회사 차끌고 다녀와야하나..

저작자표시 (새창열림)

'개소리 왈왈 > 육아관련 주저리' 카테고리의 다른 글

태극기 구매  (0) 2022.02.27
17만 확진자  (4) 2022.02.23
휴가 9일차  (4) 2022.02.06
휴가 8일차  (0) 2022.02.05
휴가 7일차  (0) 2022.02.04
Posted by 구차니
개소리 왈왈/컴퓨터2022. 2. 12. 23:28

컴퓨터 메인보드가 보니.

SATA 6개나 있네?!

[링크 : https://www.asus.com/kr/Motherboards-Components/Motherboards/PRIME/PRIME-B250M-K/]



이전 2세대 녀석들은 죄다 4개 뿐이었는데

그래도.. 8베이 짜리 하나 탐나긴 한데.. 애매하네 ㅠㅠ

저작자표시 (새창열림)

'개소리 왈왈 > 컴퓨터' 카테고리의 다른 글

플로피  (0) 2022.02.25
슈퍼마이크로 2U 8bay 서버 구매  (0) 2022.02.15
gtx660 gtx750 gtx1030 hd7950  (0) 2022.02.07
뜬금없이 맥미니(혹은 맥북에어) 사고 싶다!!  (0) 2022.01.18
sd 메모리 지름  (0) 2022.01.10
Posted by 구차니
Linux2022. 2. 11. 22:06

linux cache clear

리눅스에서 이상하게 free 명령어에서 free 인 부분이 적게 나오는데

이럴때는 drop_caches를 강제로 하면 메모리가 돌아온다.

$ free -h
              total        used        free      shared  buff/cache   available
Mem:           7.7G        1.2G        5.8G        232M        757M        6.1G
스왑:        2.0G          0B        2.0G

# echo 3 > /proc/sys/vm/drop_caches

$ free -h
              total        used        free      shared  buff/cache   available
Mem:           7.7G        1.2G        5.9G        235M        667M        6.1G
스왑:        2.0G          0B        2.0G



리눅스 캐시의 종류를 좀 더 봐야 할 듯.

파일 시스템을 알아서 캐싱하는 느낌이었는데 2번 항목이 그런거였나?

1. Clear PageCache only.
# sync; echo 1 > /proc/sys/vm/drop_caches

2. Clear dentries and inodes.
# sync; echo 2 > /proc/sys/vm/drop_caches

3. Clear pagecache, dentries, and inodes.
# sync; echo 3 > /proc/sys/vm/drop_caches

[링크 : https://www.tecmint.com/clear-ram-memory-cache-buffer-and-swap-space-on-linux/amp/]

[링크 : https://support.huaweicloud.com/intl/en-us/trouble-ecs/ecs_trouble_0336.html]







저작자표시 (새창열림)

'Linux' 카테고리의 다른 글

dmesg log_buf_len  (0) 2022.06.29
bash set -e set -x  (0) 2022.06.22
sort 컬럼 별 정렬하기  (0) 2022.02.08
elementary os  (0) 2022.01.28
linux 터미널 pause, resume  (0) 2022.01.11
Posted by 구차니
Programming/golang2022. 2. 11. 19:38

go lang rest

node.js 처럼 go mod init 명령을 통해 모듈을 설치할 수 있는 것 같다.



go 1.10은 지원도 끊어졌고 해당 명령어 지원하지 않으니

g0 1.11은 가야 할 것 같다.

[링크 : https://stackoverflow.com/questions/60410729/unknown-subcommand-mod-error-while-running-go-mod-init]



아래껀 천천히 테스트 해봐야겠네..

(우분투 20.04로 가야하나...)

$ go mod init noah.io/ark/rest
$ vi main.go
package main

import (
"encoding/json"
"net/http"
)

var users = map[string]*User{}

type User struct {
Nickname string `json:"nickname"`
Email    string `json:"email"`
}

func main() {
http.HandleFunc("/users", func(wr http.ResponseWriter, r *http.Request) {
switch r.Method {
case http.MethodGet: // 조회
json.NewEncoder(wr).Encode(users) // 인코딩
case http.MethodPost: // 등록
var user User
json.NewDecoder(r.Body).Decode(&user) // 디코딩

users[user.Email] = &user

json.NewEncoder(wr).Encode(user) // 인코딩
}
})
http.ListenAndServe(":8080", nil)
}

[링크 : https://woony-sik.tistory.com/m/12]



$ go get github.com/julienschmidt/httprouter
$ vi rest.go
package main

import (
    "fmt"
    "github.com/julienschmidt/httprouter"
    "net/http"
    "log"
)

func Index(w http.ResponseWriter, r *http.Request, _ httprouter.Params) {
    fmt.Fprint(w, "Welcome!\n")
}

func Hello(w http.ResponseWriter, r *http.Request, ps httprouter.Params) {
    fmt.Fprintf(w, "hello, %s!\n", ps.ByName("name"))
}

func main() {
    router := httprouter.New()
    router.GET("/", Index)
    router.GET("/hello/:name", Hello)

    log.Fatal(http.ListenAndServe(":8080", router))
}

[링크 : https://okky.kr/article/386116]



+

backport를 깔아주면 된다고는 한다.

$ sudo add-apt-repository ppa:longsleep/golang-backports
$ sudo apt-get install software-properties-common
$ sudo apt-get update
$ sudo apt-get install golang-1.11

[링크 : https://www.gophp.io/install-go-1-11-on-ubuntu-18-04/]



추가해보니 1.18까지도 나왔나 보다.

$ sudo add-apt-repository ppa:longsleep/golang-backports
Golang 1.8, 1.9, 1.10, 1.11, 1.12, 1.13, 1.14, 1.15, 1.16, 1.17 and 1.18 PPA for Ubuntu
 더 많은 정보: https://launchpad.net/~longsleep/+archive/ubuntu/golang-backports
[ENTER]을 눌러 진행하거나 Ctrl-c를 눌러 추가하는것을 취소합니다.



그래도 1.17을 기준으로 설치 되는 듯.

$ sudo apt-get install golang
패키지 목록을 읽는 중입니다... 완료
의존성 트리를 만드는 중입니다
상태 정보를 읽는 중입니다... 완료
다음 패키지가 자동으로 설치되었지만 더 이상 필요하지 않습니다:
  golang-1.10-go golang-1.10-race-detector-runtime golang-1.10-src
  golang-1.11-doc golang-1.11-go golang-1.11-race-detector-runtime
  golang-1.11-src golang-race-detector-runtime
Use 'sudo apt autoremove' to remove them.
다음의 추가 패키지가 설치될 것입니다 :
  golang-1.17 golang-1.17-doc golang-1.17-go golang-1.17-src golang-doc
  golang-go golang-src
제안하는 패키지:
  bzr | brz mercurial subversion
다음 새 패키지를 설치할 것입니다:
  golang golang-1.17 golang-1.17-doc golang-1.17-go golang-1.17-src golang-doc
다음 패키지를 업그레이드할 것입니다:
  golang-go golang-src
2개 업그레이드, 6개 새로 설치, 0개 제거 및 1개 업그레이드 안 함.
72.0 M바이트 아카이브를 받아야 합니다.
이 작업 후 424 M바이트의 디스크 공간을 더 사용하게 됩니다.
저작자표시 (새창열림)

'Programming > golang' 카테고리의 다른 글

golang gore(repl), delve  (0) 2022.03.31
go build 옵션  (0) 2022.03.31
go lang static http server  (0) 2022.03.10
go hello world build static / shared  (0) 2022.02.17
golang  (0) 2020.05.18
Posted by 구차니
Linux API/linux2022. 2. 11. 11:06

파일 존재유무 확인하기

tmpfs에 touch로 파일을 생성/삭제하면서 테스트 해보니

마우스 이벤트에 묶여있어도 cpu 점유율 이 크게 오르지 않는걸 봐서는 부하가 크지 않은 듯.



if( access( fname, F_OK ) == 0 ) {
    // file exists
} else {
    // file doesn't exist
}

[링크 : https://stackoverflow.com/questions/230062/whats-the-best-way-to-check-if-a-file-exists-in-c]



#include <unistd.h>
int access(const char *pathname, int mode);

The mode specifies the accessibility check(s) to be performed, and is either the value F_OK, or a mask consisting of the bitwise OR of one or more of R_OK, W_OK, and X_OK. F_OK tests for the existence of the file. R_OK, W_OK, and X_OK test whether the file exists and grants read, write, and execute permissions, respectively.

[링크 : https://linux.die.net/man/2/access]



F_OK 파일 존재여부
R_OK 파일 read 퍼미션 여부
W_OK 파일 write 퍼미션 여부
X_OK 파일 execute 퍼미션 여부
저작자표시 (새창열림)

'Linux API > linux' 카테고리의 다른 글

posix message queue  (0) 2022.09.21
zeroMQ  (0) 2022.09.20
select, poll, epoll  (0) 2021.11.02
Unhandled fault: external abort on non-linefetch  (0) 2021.05.25
Stopped (tty input)  (0) 2021.05.21
Posted by 구차니
embeded/jetson2022. 2. 10. 11:27

jetson nano deepstream

jetson nano developer (4GB 모델)로 해서 그런지

xavier nx에서 할때랑 비교하면 초기 구동 시간이 어마어마하게 오래 걸린다.



[링크 : https://docs.nvidia.com/metropolis/deepstream/dev-guide/text/DS_Quickstart.html] 빠른 실행

[링크 : https://docs.nvidia.com/metropolis/deepstream/dev-guide/] 목차

[링크 : https://docs.nvidia.com/metropolis/deepstream/dev-guide/text/DS_ref_app_deepstream.html]

[링크 : https://docs.nvidia.com/metropolis/deepstream/dev-guide/text/DS_Zero_Coding_Sample_Graphs.html#deepstream-app]

저작자표시 (새창열림)

'embeded > jetson' 카테고리의 다른 글

azure custom vision - precision, recall  (0) 2022.03.28
flud nvidia cuda  (0) 2022.03.28
jetson nano developer board(구형) 부팅 문제  (0) 2022.02.09
nvidia jetson nano 2gb / csi  (0) 2022.01.21
jetson nano gpu 사용 상태 확인  (0) 2022.01.20
Posted by 구차니
embeded/raspberry pi2022. 2. 10. 10:45

rpi i2c oled

동일한 녀석인듯? 일단 시도 해봐야 겠다.



[링크 : https://rudalskim.tistory.com/109]



+

일단 사용한 라이브러리는 deprecated 이고

[링크 : https://github.com/adafruit/Adafruit_Python_SSD1306]



이미지를 출력하도록 해놔서 python의 image 라이브러리를 이용하여 text도 그려서 출력하는 듯.

[링크 : https://github.com/adafruit/Adafruit_Python_SSD1306/blob/master/examples/animate.py]



+

하라는 대로 해서 하니 나오긴 한데, 해당 라이브러리에서 이미지 말고 텍스트를 출력 할 수 있는진 좀 봐야 할 듯.

import time
import Adafruit_GPIO.SPI as SPI
import Adafruit_SSD1306
from PIL import Image

RST = 25
DC = 24
SPI_PORT = 0
SPI_DEVICE = 0

disp = Adafruit_SSD1306.SSD1306_128_64(rst=RST)
disp.begin()
disp.clear()
disp.display()

image = Image.open('test.png').resize((disp.width, disp.height), Image.ANTIALIAS).convert('1')
disp.image(image)
disp.display()



테스트 용으로 대충 128x64 사이즈로 만든 png 파일



아래와 같이 잘 나온다.



다만 OLED 라고 해도 리프레시는 존재하는지(당연한건가...?)

셔터속도에 따라 비어보이는 경우가 존재한다.

저작자표시 (새창열림)

'embeded > raspberry pi' 카테고리의 다른 글

라즈베리 파이2 / 마인크래프트  (0) 2022.03.18
rpi opencv python pid servo  (0) 2022.03.08
라즈베리 파이 부품 도착  (0) 2022.02.09
rpi csi to dsi...  (0) 2022.01.21
rpi 7" dsi  (0) 2022.01.21
Posted by 구차니
embeded/raspberry pi2022. 2. 9. 22:31

라즈베리 파이 부품 도착

0.96인치 128x64 화이트 OLED

1인치도 안되서 그런가 무지 작긴 하네

16x16 폰트로 8*4 대충.. 32글짜 정도 표시할 수 있으려나?



라즈베리 카메라

머.. 싼걸로 사서 jetson nano 에는 쓸 수 없다지만

문득.. 카메라가 다르면 드라이버 차이로 cpu 점유율이 어떻게 달라지나 궁금하긴 하네?

저작자표시 (새창열림)

'embeded > raspberry pi' 카테고리의 다른 글

rpi opencv python pid servo  (0) 2022.03.08
rpi i2c oled  (0) 2022.02.10
rpi csi to dsi...  (0) 2022.01.21
rpi 7" dsi  (0) 2022.01.21
rpi DSI 7인치 터치 스크린  (0) 2022.01.20
Posted by 구차니
embeded/jetson2022. 2. 9. 10:24

jetson nano developer board(구형) 부팅 문제

전원을 넣어주어도 금세 꺼져서, 운이 좋게 한번 부팅되었을때 로그를 보는데도 원인을 모르겠다.

[링크 : https://forums.developer.nvidia.com/t/trusty-image-missing-on-bootup/60519]



도대체 이녀석에게 무슨일이 있었던 걸까 -ㅁ-

방열판 고정기구(별나사 고정되는) 안에 캐패시터 하나가 완전 가루가 되었네



느낌으로는... pmic i2c 통신이 안되서 부팅하다가 전원부족으로 강제종료 아닐까 싶은데...

[0000.797] Verifying TBC in OdmNonSecureSBK mode
[0000.807] Bootloader load address is 0xa0000000, entry address is 0xa0000258
[0000.814] Bootloader downloaded successfully.
[0000.819] Downloaded Tboot-CPU binary to 0xa0000258
[0000.824] MAX77620_GPIO5 configured
[0000.827] CPU power rail is up
[0000.830] CPU clock enabled
[0000.834] Performing RAM repair
[0000.836] Updating A64 Warmreset Address to 0xa00002e9
[0000.842] Loading NvTbootBootloaderDTB
[0002.153] Verifying NvTbootBootloaderDTB in OdmNonSecureSBK mode
[0002.224] Bootloader DTB Load Address: 0x83000000
[0002.229] Loading NvTbootKernelDTB
[0003.540] Verifying NvTbootKernelDTB in OdmNonSecureSBK mode
[0003.611] Kernel DTB Load Address: 0x83100000
[0003.619] Loading cboot binary
[0005.304] Verifying EBT in OdmNonSecureSBK mode
[0005.345] Bootloader load address is 0x92c00000, entry address is 0x92c00258
[0005.352] Bootloader downloaded successfully.
[0005.544] Using BFS PT to query partitions
[0005.548] Next binary entry address: 0x92c00258
[0005.553] BoardId: 3448
[0005.557] Overriding pmu board id with proc board id
[0005.562] Display board id is not available
[0007.061] Verifying SC7EntryFw in OdmNonSecureSBK mode
[0007.117] /bpmp deleted
[0007.119] SC7EntryFw header found loaded at 0xff700000
[0007.307] OVR2 PMIC
[0007.309] Bpmp FW successfully loaded
[0007.325] WB0 init successfully at 0xff780000
[0007.329] Set NvDecSticky Bits
[0007.333] GSC2 address ff53fffc value c0edbbcc
[0007.339] GSC MC Settings done
[0007.344] TOS Image length 53680
[0007.347]  Monitor size 53680
[0007.350]  OS size 0
[0007.511] Secure Os AES-CMAC Verification Success!
[0007.516] TOS image cipher info: plaintext
[0007.520] Loading and Validation of Secure OS Successful
[0007.536] SC7 Entry Firmware - 0xff700000, 0x4000
[0007.540] NvTbootPackSdramParams: start.
[0007.545] NvTbootPackSdramParams: done.
[0007.549] Tegraboot started after 53290 us
[0007.553] Basic modules init took 5647304 us
[0007.557] NvTbootQspiFlashIoctl: Opcode = 1 not supported
[0007.562] Sec Bootdevice Read Time = 12 ms, Read Size = 65 KB
[0007.568] Sec Bootdevice Write Time = 0 ms, Write Size = 0 KB
[0007.573] Storage Device Read Time = 6740 ms, Read Size = 2306 KB
[0007.579] Storage Device Write Time = 0 ms, Write Size = 0 KB
[0007.585] Next stage binary read took 1530458 us
[0007.589] Carveout took -1542138 us
[0007.593] CPU initialization took 2041862 us
[0007.597] Total time taken by TegraBoot 7677486 us

[0007.601] Starting CPU & Halting co-processor

64NOTICE:  BL31: v1.3(release):b5eeb33f7
NOTICE:  BL31: Built : 12:09:37, Jul 26 2021
ERROR:   Error initializing runtime service trusty_fast
[0007.724] RamCode = 0
[0007.728] LPDDR4 Training: Read DT: Number of tables = 2
[0007.733] EMC Training (SRC-freq: 204000; DST-freq: 1600000)
[0007.746] EMC Training Successful
[0007.749] 408000 not found in DVFS table
[0007.756] RamCode = 0
[0007.759] DT Write: emc-table@204000 succeeded
[0007.764] DT Write: emc-table@1600000 succeeded
[0007.769] LPDDR4 Training: Write DT: Number of tables = 2
[0007.964]
[0007.965] Debug Init done
[0007.968] Marked DTB cacheable
[0007.971] Bootloader DTB loaded at 0x83000000
[0007.975] Marked DTB cacheable
[0007.978] Kernel DTB loaded at 0x83100000
[0007.982] DeviceTree Init done
[0007.995] Pinmux applied successfully
[0007.999] gicd_base: 0x50041000
[0008.003] gicc_base: 0x50042000
[0008.006] Interrupts Init done
[0008.010] Using base:0x60005090 & irq:208 for tick-timer
[0008.015] Using base:0x60005098 for delay-timer
[0008.020] platform_init_timer: DONE
[0008.023] Timer(tick) Init done
[0008.027] osc freq = 38400 khz
[0008.031]
[0008.032] Welcome to L4T Cboot
[0008.035]
[0008.036] Cboot Version: 00.00.2018.01-t210-c952b4e6
[0008.041] calling constructors
[0008.044] initializing heap
[0008.047] initializing threads
[0008.049] initializing timers
[0008.052] creating bootstrap completion thread
[0008.057] top of bootstrap2()
[0008.060] CPU: ARM Cortex A57
[0008.062] CPU: MIDR: 0x411FD071, MPIDR: 0x80000000
[0008.067] initializing platform
[0008.074] Manufacturer: MF = 0xc2, ID MSB = 0x25
[0008.079] ID LSB = 0x36, ID-CFI len = 194 bytes
[0008.083] Macronix QSPI chip present
[0008.087] SPI device register
[0008.090] init boot device
[0008.092] allocating memory for boot device(SPI)
[0008.097] registering boot device
[0008.106] sdmmc node status = okay
[0008.110] sdcard instance = 0
[0008.112] sdmmc cd-inverted
[0008.115] sdcard gpio handle 0x5b
[0008.118] sdcard gpio pin 0xc9
[0008.121] sdcard gpio flags 0x0
[0008.124] vmmc-supply 0x9d
[0008.127] Instance: 0
[0008.129] Allocating memory for context
[0008.133] enabling clock
[0008.135] sd card init
[0008.138] Check card present and stable
[0008.141] Send command 0
[0008.158] Send command 3
[0008.162] Set RCA for the card
[0008.165] Query card specific data by command 9
[0008.171] Parse CSD data
[0008.174] Send command 7
[0008.184] Calling sd device register
[0008.188] Init sdcard
[0008.190] Allocating memory for boot device
[0008.194] Registering user device
[0008.207] Enable APE clock
[0008.210] Un-powergate APE partition
[0008.213] of_register: registering tegra_udc to of_hal
[0008.218] of_register: registering inv20628-driver to of_hal
[0008.224] of_register: registering ads1015-driver to of_hal
[0008.229] of_register: registering lp8557-bl-driver to of_hal
[0008.235] of_register: registering bq2419x_charger to of_hal
[0008.241] of_register: registering bq27441_fuel_gauge to of_hal
[0008.252] gpio framework initialized
[0008.256] of_register: registering tca9539_gpio to of_hal
[0008.261] of_register: registering tca9539_gpio to of_hal
[0008.266] of_register: registering i2c_bus_driver to of_hal
[0008.272] of_register: registering i2c_bus_driver to of_hal
[0008.277] of_register: registering i2c_bus_driver to of_hal
[0008.283] pmic framework initialized
[0008.286] of_register: registering max77620_pmic to of_hal
[0008.292] regulator framework initialized
[0008.296] of_register: registering tps65132_bl_driver to of_hal
[0008.302] initializing target
[0008.308] gpio_driver_register: register 'tegra_gpio_driver' driver
[0008.316] board ID = D78, board SKU = 0
[0008.319] Skipping Z3!
[0008.324] fixed regulator driver initialized
[0008.341] initializing OF layer
[0008.344] NCK carveout not present
[0008.348] Skipping dts_overrides
[0008.352] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.368] I2C Bus Init done
[0008.371] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.381] I2C Bus Init done
[0008.384] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.394] I2C Bus Init done
[0008.397] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.407] I2C Bus Init done
[0008.409] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.420] I2C Bus Init done
[0008.422] of_children_init: Ops found for compatible string maxim,max77620
[0008.432] max77620_init using irq 118
[0008.437] register 'maxim,max77620' pmic
[0008.442] gpio_driver_register: register 'max77620-gpio' driver
[0008.448] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.458] I2C Bus Init done
[0008.462] NCK carveout not present
[0008.471] Find /i2c@7000c000's alias i2c0
[0008.475] get eeprom at 1-a0, size 256, type 0
[0008.484] Find /i2c@7000c500's alias i2c2
[0008.487] get eeprom at 3-a0, size 256, type 0
[0008.492] get eeprom at 3-ae, size 256, type 0
[0008.496] pm_ids_update: Updating 1,a0, size 256, type 0
[0008.502] I2C slave not started
[0008.505] I2C write failed
[0008.507] Writing offset failed
[0008.510] eeprom_init: EEPROM read failed
[0008.514] pm_ids_update: eeprom init failed
[0008.518] pm_ids_update: Updating 3,a0, size 256, type 0
[0008.548] pm_ids_update: The pm board id is 3448-0000-200
[0008.555] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0008.564] pm_ids_update: pm id update successful
[0008.568] pm_ids_update: Updating 3,ae, size 256, type 0
[0008.598] pm_ids_update: The pm board id is 3449-0000-200
[0008.604] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0008.612] pm_ids_update: pm id update successful
[0008.643] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0008.648] shim_eeprom_update_mac:267: Failed to update 0 MAC address in DTB
[0008.656] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0008.662] shim_eeprom_update_mac:267: Failed to update 1 MAC address in DTB
[0008.670] updating /chosen/nvidia,ethernet-mac node 00:04:4b:e5:59:5d
[0008.677] Plugin Manager: Parse ODM data 0x00084000
[0008.690] shim_cmdline_install: /chosen/bootargs: earlycon=uart8250,mmio32,0x70006000
[0008.704] Find /i2c@7000c000's alias i2c0
[0008.708] get eeprom at 1-a0, size 256, type 0
[0008.717] Find /i2c@7000c500's alias i2c2
[0008.721] get eeprom at 3-a0, size 256, type 0
[0008.725] get eeprom at 3-ae, size 256, type 0
[0008.729] pm_ids_update: Updating 1,a0, size 256, type 0
[0008.735] I2C slave not started
[0008.738] I2C write failed
[0008.740] Writing offset failed
[0008.743] eeprom_init: EEPROM read

[0008.747] pm_ids_update: eeprom init failed
[0008.751] pm_ids_update: Updating 3,a0, size 256, type 0
[0008.782] pm_ids_update: The pm board id is 3448-0000-200
[0008.788] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0008.795] pm_ids_update: pm id update successful
[0008.799] pm_ids_update: Updating 3,ae, size 256, type 0
[0008.829] pm_ids_update: The pm board id is 3449-0000-200
[0008.836] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0008.842] pm_ids_update: pm id update successful
[0008.873] Add serial number:1422019083619 as DT property
[0008.880] Applying platform configs
[0008.887] platform-init is not present. Skipping
[0008.891] calling apps_init()
[0008.917] Found 14 GPT partitions in "sd0"
[0008.921] Proceeding to Cold Boot
[0008.924] starting app android_boot_app
[0008.928] Device state: unlocked
[0008.931] display console init
[0008.939] could not find regulator
[0008.942] hdmi cable connected
[0008.958] edid read success
[0008.976] DT entry for leds-pwm not found
[0008.979] edid read success
[0008.982] width = 640, height = 480, frequency = 25174825
[0008.987] width = 640, height = 480, frequency = 25174825
[0008.993] width = 640, height = 480, frequency = 25174825
[0008.998] width = 1920, height = 1080, frequency = 148500000
[0009.004] width = 720, height = 480, frequency = 27000000
[0009.009] width = 720, height = 480, frequency = 27000000
[0009.015] width = 720, height = 480, frequency = 26973026
[0009.020] width = 720, height = 576, frequency = 26973026
[0009.025] width = 1280, height = 720, frequency = 74175824
[0009.031] width = 1280, height = 720, frequency = 74175824
[0009.036] width = 1920, height = 1080, frequency = 148351648
[0009.042] width = 1920, height = 1080, frequency = 148351648
[0009.048] width = 1920, height = 1080, frequency = 74175824
[0009.053] width = 1920, height = 1080, frequency = 74175824
[0009.059] width = 1920, height = 1080, frequency = 74175824
[0009.064] Best mode Width = 1920, Height = 1080, freq = 148351648
[0009.072] tmds-config node not found
[0009.076] pmc_set_io_pad_voltage: Error -2 retrieving platform-io-pad-voltagepropsetting 'avdd-io-hdmi-dp' regulator                                                                                                                         to 1050000 micro volts
[0009.091] setting 'vdd-1v8' regulator to 1800000 micro volts
[0009.098] could not find regulator
[0009.102] could not find regulator
[0009.105] could not find regulator
[0009.133] using default cmu settings
[0009.137] dc_hdmi_enable, starting HDMI initialisation
[0009.143] dc_hdmi_enable, HDMI initialisation complete
[0009.148] list and configure display window
[0009.157] display console init completed
[0009.168] subnode volume_up is not found !
[0009.172] subnode back is not found !
[0009.175] subnode volume_down is not found !
[0009.179] subnode menu is not found !
[0009.183] Gpio keyboard init success
[0009.233] found decompressor handler: lz4-legacy
[0009.248] decompressing blob (type 1)...
[0009.318] load_bmp_blob: panelresolution=1080 type=3
[0009.368] decompressor handler not found
[0009.372] load_firmware_blob: Firmware blob loaded, entries=2
[0009.378] XUSB blob version 0 size 126464 @ 0x934b928c
[0009.384] -------> se_aes_verify_sbk_clear: 747
[0009.388] se_aes_verify_sbk_clear: Error
[0009.392] SE operation failed
[0009.395] bl_battery_charging: connected to external power supply
[0009.407] device_query_partition_size: failed to open partition sd0:MSC !
[0009.414] MSC Partition not found
[0009.420] device_query_partition_size: failed to open partition sd0:USP !
[0009.427] USP partition read failed!
[0009.430] blob_init: blob-partition USP header read failed
[0009.436] android_boot Unable to update recovery partition
[0009.441] kfs_getpartname: name = LNX
[0009.445] Loading kernel from LNX
[0009.586] load kernel from storage
[0009.597] decompressor handler not found
[0009.680] Successfully loaded kernel and ramdisk images
[0009.686] board ID = D78, board SKU = 0
[0009.690] sdmmc node status = okay
[0009.693] sdcard instance = 0
[0009.696] sdmmc cd-inverted
[0009.699] sdcard gpio handle 0x5b
[0009.702] sdcard gpio pin 0xc9
[0009.705] sdcard gpio flags 0x0
[0009.708] vmmc-supply 0x9d
[0009.711] cd_gpio_pin = 201
[0009.714] pin_state = 0
[0009.716] Found sdcard
[0009.718] SD-card IS present ...
[0009.721] load_and_boot_kernel: SD card detected OK
[0009.727] load_bmp_blob: panelresolution=1080 type=3
[0010.223] display bmp image done
[0010.226] NCK carveout not present
[0010.229] Skipping dts_overrides
[0010.233] NCK carveout not present
[0010.242] Find /i2c@7000c000's alias i2c0
[0010.246] get eeprom at 1-a0, size 256, type 0
[0010.255] Find /i2c@7000c500's alias i2c2
[0010.258] get eeprom at 3-a0, size 256, type 0
[0010.263] get eeprom at 3-ae, size 256, type 0
[0010.267] pm_ids_update: Updating 1,a0, size 256, type 0
[0010.273] I2C slave not started
[0010.276] I2C write failed
[0010.278] Writing offset failed
[0010.281] eeprom_init: EEPROM read failed
[0010.285] pm_ids_update: eeprom init failed
[0010.289] pm_ids_update: Updating 3,a0, size 256, type 0
[0010.319] pm_ids_update: The pm board id is 3448-0000-200
[0010.326] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0010.335] pm_ids_update: pm id update successful
[0010.339] pm_ids_update: Updating 3,ae, size 256, type 0
[0010.369] pm_ids_update: The pm board id is 3449-0000-200
[0010.375] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0010.383] pm_ids_update: pm id update successful
[0010.414] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0010.419] shim_eeprom_update_mac:267: Failed to update 0 MAC address in DTB
[0010.427] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0010.433] shim_eeprom_update_mac:267: Failed to update 1 MAC address in DTB
[0010.441] updating /chosen/nvidia,ethernet-mac node 00:04:4b:e5:59:5d
[0010.448] Plugin Manager: Parse ODM data 0x00084000
[0010.461] shim_cmdline_install: /chosen/bootargs: earlycon=uart8250,mmio32,0x70006000
[0010.469] Add serial number:1422019083619 as DT property
[0010.478] "bpmp" doesn't exist, creating
[0010.484] Updated bpmp info to DTB
[0010.488] Updated initrd info to DTB
[0010.492] "proc-board" doesn't exist, creating
[0010.498] Updated board info to DTB
[0010.501] "pmu-board" doesn't exist, creating
[0010.507] Updated board info to DTB
[0010.510] "display-board" doesn't exist, creating
[0010.516] Updated board info to DTB
[0010.520] "reset" doesn't exist, creating
[0010.524] Updated reset info to DTB
[0010.528] Cmdline: tegraid=21.1.2.0.0 ddr_die=4096M@2048M section=512M memtype=0 vpr_resize usb_port_owner_info=0 la                                                                                                                        ne_owner_info=0 emc_max_dvfs=0 touch_id=0@63 video=tegrafb no_console_suspend=1 console=ttyS0,115200n8 debug_uartport                                                                                                                        =lsport,0 earlyprintk=uart8250-32bit,0x70006000 maxcpus=4 usbcore.old_scheme_first=1 lp0_vec=0x1000@0xff780000 core_e                                                                                                                        dp_mv=1075 core_edp_ma=4000 gpt tegra_fbmem=0x800000@0x92cb4000 is_hdmi_initialised=1
[0010.567] DTB cmdline: earlycon=uart8250,mmio32,0x70006000
[0010.573] boot image cmdline: root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fb                                                                                                                        con=map:0 net.ifnames=0
[0010.586] Updated bootarg info to DTB
[0010.589] Adding uuid 00000001644476401800000006018280 to DT
[0010.595] Adding eks info 0 to DT
[0010.601] WARNING: Failed to pass NS DRAM ranges to TOS, err: -7
[0010.607] Updated memory info to DTB
[0010.612] Updated system-lp0-disable info to DTB
[0010.620] set vdd_core voltage to 1075 mv
[0010.624] setting 'vdd-core' regulator to 1075000 micro volts





전원이 부족할 경우(USB3.0 허브/ 외부전원 사용)

정상 부팅 로그와 비교해보니 imx219(카메라) 초기화 해보면서 전원 부족으로 죽은 듯?

[0000.126] [TegraBoot] (version 00.00.2018.01-l4t-33e7fa82)
[0000.131] Processing in cold boot mode Bootloader 2
[0000.135] A02 Bootrom Patch rev = 1023
[0000.139] Power-up reason: pmc por
[0000.142] No Battery Present
[0000.145] pmic max77620 reset reason
[0000.148] pmic max77620 NVERC : 0x40
[0000.152] RamCode = 0
[0000.154] Platform has DDR4 type RAM
[0000.157] max77620 disabling SD1 Remote Sense
[0000.161] Setting DDR voltage to 1125mv
[0000.165] Serial Number of Pmic Max77663: 0x291ae2
[0000.173] Entering ramdump check
[0000.176] Get RamDumpCarveOut = 0x0
[0000.179] RamDumpCarveOut=0x0,  RamDumperFlag=0xe59ff3f8
[0000.184] Last reboot was clean, booting normally!
[0000.189] Sdram initialization is successful
[0000.193] SecureOs Carveout Base=0x00000000ff800000 Size=0x00800000
[0000.199] Lp0 Carveout Base=0x00000000ff780000 Size=0x00001000
[0000.205] BpmpFw Carveout Base=0x00000000ff700000 Size=0x00080000
[0000.211] GSC1 Carveout Base=0x00000000ff600000 Size=0x00100000
[0000.217] GSC2 Carveout Base=0x00000000ff500000 Size=0x00100000
[0000.223] GSC4 Carveout Base=0x00000000ff400000 Size=0x00100000
[0000.228] GSC5 Carveout Base=0x00000000ff300000 Size=0x00100000
[0000.234] GSC3 Carveout Base=0x000000017f300000 Size=0x00d00000
[0000.250] RamDump Carveout Base=0x00000000ff280000 Size=0x00080000
[0000.256] Platform-DebugCarveout: 0
[0000.260] Nck Carveout Base=0x00000000ff080000 Size=0x00200000
[0000.266] Non secure mode, and RB not enabled.
[0000.272] Invalid GPT Partition
[0000.287] Using BFS PT to query partitions
[0000.291] failed to load NvTbootTbootCpu from (2:0)
[0000.296] re-load NvTbootTbootCpu from (4:0)
[0000.349] Csd NumOfBlocks=122142720
[0000.408] Using GPT Primary to query partitions
[0000.416] Loading Tboot-CPU binary
[0000.793] Verifying TBC in OdmNonSecureSBK mode
[0000.803] Bootloader load address is 0xa0000000, entry address is 0xa0000258
[0000.810] Bootloader downloaded successfully.
[0000.814] Downloaded Tboot-CPU binary to 0xa0000258
[0000.819] MAX77620_GPIO5 configured
[0000.823] CPU power rail is up
[0000.826] CPU clock enabled
[0000.829] Performing RAM repair
[0000.832] Updating A64 Warmreset Address to 0xa00002e9
[0000.837] Loading NvTbootBootloaderDTB
[0002.149] Verifying NvTbootBootloaderDTB in OdmNonSecureSBK mode
[0002.220] Bootloader DTB Load Address: 0x83000000
[0002.225] Loading NvTbootKernelDTB
[0003.536] Verifying NvTbootKernelDTB in OdmNonSecureSBK mode
[0003.607] Kernel DTB Load Address: 0x83100000
[0003.615] Loading cboot binary
[0005.299] Verifying EBT in OdmNonSecureSBK mode
[0005.341] Bootloader load address is 0x92c00000, entry address is 0x92c00258
[0005.348] Bootloader downloaded successfully.
[0005.540] Using BFS PT to query partitions
[0005.544] Next binary entry address: 0x92c00258
[0005.549] BoardId: 3448
[0005.553] Overriding pmu board id with proc board id
[0005.558] Display board id is not available
[0007.057] Verifying SC7EntryFw in OdmNonSecureSBK mode
[0007.113] /bpmp deleted
[0007.115] SC7EntryFw header found loaded at 0xff700000
[0007.303] OVR2 PMIC
[0007.305] Bpmp FW successfully loaded
[0007.321] WB0 init successfully at 0xff780000
[0007.325] Set NvDecSticky Bits
[0007.329] GSC2 address ff53fffc value c0edbbcc
[0007.335] GSC MC Settings done
[0007.340] TOS Image length 53680
[0007.343]  Monitor size 53680
[0007.346]  OS size 0
[0007.507] Secure Os AES-CMAC Verification Success!
[0007.512] TOS image cipher info: plaintext
[0007.516] Loading and Validation of Secure OS Successful
[0007.532] SC7 Entry Firmware - 0xff700000, 0x4000
[0007.536] NvTbootPackSdramParams: start.
[0007.541] NvTbootPackSdramParams: done.
[0007.545] Tegraboot started after 53275 us
[0007.549] Basic modules init took 5643106 us
[0007.553] NvTbootQspiFlashIoctl: Opcode = 1 not supported
[0007.558] Sec Bootdevice Read Time = 12 ms, Read Size = 65 KB
[0007.564] Sec Bootdevice Write Time = 0 ms, Write Size = 0 KB
[0007.569] Storage Device Read Time = 6740 ms, Read Size = 2306 KB
[0007.575] Storage Device Write Time = 0 ms, Write Size = 0 KB
[0007.581] Next stage binary read took 1530455 us
[0007.585] Carveout took -1542135 us
[0007.588] CPU initialization took 2041873 us
[0007.593] Total time taken by TegraBoot 7673299 us

[0007.597] Starting CPU & Halting co-processor

64NOTICE:  BL31: v1.3(release):b5eeb33f7
NOTICE:  BL31: Built : 12:09:37, Jul 26 2021
ERROR:   Error initializing runtime service trusty_fast
[0007.719] RamCode = 0
[0007.724] LPDDR4 Training: Read DT: Number of tables = 2
[0007.729] EMC Training (SRC-freq: 204000; DST-freq: 1600000)
[0007.742] EMC Training Successful
[0007.745] 408000 not found in DVFS table
[0007.751] RamCode = 0
[0007.755] DT Write: emc-table@204000 succeeded
[0007.760] DT Write: emc-table@1600000 succeeded
[0007.764] LPDDR4 Training: Write DT: Number of tables = 2
[0007.960]
[0007.961] Debug Init done
[0007.963] Marked DTB cacheable
[0007.966] Bootloader DTB loaded at 0x83000000
[0007.971] Marked DTB cacheable
[0007.974] Kernel DTB loaded at 0x83100000
[0007.978] DeviceTree Init done
[0007.991] Pinmux applied successfully
[0007.995] gicd_base: 0x50041000
[0007.999] gicc_base: 0x50042000
[0008.002] Interrupts Init done
[0008.006] Using base:0x60005090 & irq:208 for tick-timer
[0008.011] Using base:0x60005098 for delay-timer
[0008.015] platform_init_timer: DONE
[0008.019] Timer(tick) Init done
[0008.023] osc freq = 38400 khz
[0008.026]
[0008.028] Welcome to L4T Cboot
[0008.031]
[0008.032] Cboot Version: 00.00.2018.01-t210-c952b4e6
[0008.037] calling constructors
[0008.040] initializing heap
[0008.042] initializing threads
[0008.045] initializing timers
[0008.048] creating bootstrap completion thread
[0008.052] top of bootstrap2()
[0008.055] CPU: ARM Cortex A57
[0008.058] CPU: MIDR: 0x411FD071, MPIDR: 0x80000000
[0008.063] initializing platform
[0008.070] Manufacturer: MF = 0xc2, ID MSB = 0x25
[0008.075] ID LSB = 0x36, ID-CFI len = 194 bytes
[0008.079] Macronix QSPI chip present
[0008.083] SPI device register
[0008.086] init boot device
[0008.088] allocating memory for boot device(SPI)
[0008.093] registering boot device
[0008.102] sdmmc node status = okay
[0008.105] sdcard instance = 0
[0008.108] sdmmc cd-inverted
[0008.111] sdcard gpio handle 0x5b
[0008.114] sdcard gpio pin 0xc9
[0008.117] sdcard gpio flags 0x0
[0008.120] vmmc-supply 0x9d
[0008.123] Instance: 0
[0008.125] Allocating memory for context
[0008.129] enabling clock
[0008.131] sd card init
[0008.133] Check card present and stable
[0008.137] Send command 0
[0008.154] Send command 3
[0008.158] Set RCA for the card
[0008.161] Query card specific data by command 9
[0008.167] Parse CSD data
[0008.170] Send command 7
[0008.180] Calling sd device register
[0008.183] Init sdcard
[0008.186] Allocating memory for boot device
[0008.190] Registering user device
[0008.203] Enable APE clock
[0008.205] Un-powergate APE partition
[0008.209] of_register: registering tegra_udc to of_hal
[0008.214] of_register: registering inv20628-driver to of_hal
[0008.220] of_register: registering ads1015-driver to of_hal
[0008.225] of_register: registering lp8557-bl-driver to of_hal
[0008.231] of_register: registering bq2419x_charger to of_hal
[0008.237] of_register: registering bq27441_fuel_gauge to of_hal
[0008.248] gpio framework initialized
[0008.251] of_register: registering tca9539_gpio to of_hal
[0008.257] of_register: registering tca9539_gpio to of_hal
[0008.262] of_register: registering i2c_bus_driver to of_hal
[0008.268] of_register: registering i2c_bus_driver to of_hal
[0008.273] of_register: registering i2c_bus_driver to of_hal
[0008.279] pmic framework initialized
[0008.282] of_register: registering max77620_pmic to of_hal
[0008.288] regulator framework initialized
[0008.292] of_register: registering tps65132_bl_driver to of_hal
[0008.298] initializing target
[0008.303] gpio_driver_register: register 'tegra_gpio_driver' driver
[0008.312] board ID = D78, board SKU = 0
[0008.315] Skipping Z3!
[0008.320] fixed regulator driver initialized
[0008.337] initializing OF layer
[0008.340] NCK carveout not present
[0008.343] Skipping dts_overrides
[0008.348] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.364] I2C Bus Init done
[0008.367] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.377] I2C Bus Init done
[0008.379] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.390] I2C Bus Init done
[0008.392] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.403] I2C Bus Init done
[0008.405] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.415] I2C Bus Init done
[0008.418] of_children_init: Ops found for compatible string maxim,max77620
[0008.428] max77620_init using irq 118
[0008.433] register 'maxim,max77620' pmic
[0008.437] gpio_driver_register: register 'max77620-gpio' driver
[0008.444] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.454] I2C Bus Init done
[0008.458] NCK carveout not present
[0008.467] Find /i2c@7000c000's alias i2c0
[0008.471] get eeprom at 1-a0, size 256, type 0
[0008.479] Find /i2c@7000c500's alias i2c2
[0008.483] get eeprom at 3-a0, size 256, type 0
[0008.488] get eeprom at 3-ae, size 256, type 0
[0008.492] pm_ids_update: Updating 1,a0, size 256, type 0
[0008.497] I2C slave not started
[0008.500] I2C write failed
[0008.503] Writing offset failed
[0008.506] eeprom_init: EEPROM read failed
[0008.510] pm_ids_update: eeprom init failed
[0008.514] pm_ids_update: Updating 3,a0, size 256, type 0
[0008.544] pm_ids_update: The pm board id is 3448-0000-200
[0008.551] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0008.559] pm_ids_update: pm id update successful
[0008.564] pm_ids_update: Updating 3,ae, size 256, type 0
[0008.594] pm_ids_update: The pm board id is 3449-0000-200
[0008.600] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0008.608] pm_ids_update: pm id update successful
[0008.638] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0008.644] shim_eeprom_update_mac:267: Failed to update 0 MAC address in DTB
[0008.652] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0008.658] shim_eeprom_update_mac:267: Failed to update 1 MAC address in DTB
[0008.666] updating /chosen/nvidia,ethernet-mac node 00:04:4b:e5:59:5d
[0008.673] Plugin Manager: Parse ODM data 0x00084000
[0008.686] shim_cmdline_install: /chosen/bootargs: earlycon=uart8250,mmio32,0x70006000
[0008.700] Find /i2c@7000c000's alias i2c0
[0008.704] get eeprom at 1-a0, size 256, type 0
[0008.713] Find /i2c@7000c500's alias i2c2
[0008.716] get eeprom at 3-a0, size 256, type 0
[0008.721] get eeprom at 3-ae, size 256, type 0
[0008.725] pm_ids_update: Updating 1,a0, size 256, type 0
[0008.731] I2C slave not started
[0008.734] I2C write failed
[0008.736] Writing offset failed
[0008.739] eeprom_init: EEPROM read failed
[0008.743] pm_ids_update: eeprom init failed
[0008.747] pm_ids_update: Updating 3,a0, size 256, type 0
[0008.777] pm_ids_update: The pm board id is 3448-0000-200
[0008.784] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0008.790] pm_ids_update: pm id update successful
[0008.795] pm_ids_update: Updating 3,ae, size 256, type 0
[0008.825] pm_ids_update: The pm board id is 3449-0000-200
[0008.831] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0008.838] pm_ids_update: pm id update successful
[0008.869] Add serial number:1422019083619 as DT property
[0008.876] Applying platform configs
[0008.883] platform-init is not present. Skipping
[0008.887] calling apps_init()
[0008.912] Found 14 GPT partitions in "sd0"
[0008.916] Proceeding to Cold Boot
[0008.920] starting app android_boot_app
[0008.923] Device state: unlocked
[0008.926] display console init
[0008.935] could not find regulator
[0008.958] hdmi cable not connected
[0008.961] is_hdmi_needed: HDMI not connected, returning false
[0008.967] DT entry for leds-pwm not found
h[0008.974] dmi is not connected
[0008.977] sor0 is not supported
[0008.980] display_console_init: no valid display out_type
[0008.988] subnode volume_up is not found !
[0008.992] subnode back is not found !
[0008.996] subnode volume_down is not found !
[0009.000] subnode menu is not found !
[0009.003] Gpio keyboard init success
[0009.054] found decompressor handler: lz4-legacy
[0009.068] decompressing blob (type 1)...
[0009.134] display_resolution: No display init
[0009.139] Failed to retrieve display resolution
[0009.143] Could not load/initialize BMP blob...ignoring
[0009.194] decompressor handler not found
[0009.198] load_firmware_blob: Firmware blob loaded, entries=2
[0009.204] XUSB blob version 0 size 126464 @ 0x92cb328c
[0009.210] -------> se_aes_verify_sbk_clear: 747
[0009.214] se_aes_verify_sbk_clear: Error
[0009.218] SE operation failed
[0009.221] bl_battery_charging: connected to external power supply
[0009.230] display_console_ioctl: No display init
[0009.234] switch_backlight failed
[0009.240] device_query_partition_size: failed to open partition sd0:MSC !
[0009.247] MSC Partition not found
[0009.253] device_query_partition_size: failed to open partition sd0:USP !
[0009.260] USP partition read failed!
[0009.264] blob_init: blob-partition USP header read failed
[0009.269] android_boot Unable to update recovery partition
[0009.275] kfs_getpartname: name = LNX
[0009.278] Loading kernel from LNX
[0009.421] load kernel from storage
[0009.432] decompressor handler not found
[0009.516] Successfully loaded kernel and ramdisk images
[0009.521] board ID = D78, board SKU = 0
[0009.526] sdmmc node status = okay
[0009.529] sdcard instance = 0
[0009.532] sdmmc cd-inverted
[0009.535] sdcard gpio handle 0x5b
[0009.538] sdcard gpio pin 0xc9
[0009.541] sdcard gpio flags 0x0
[0009.544] vmmc-supply 0x9d
[0009.547] cd_gpio_pin = 201
[0009.549] pin_state = 0
[0009.552] Found sdcard
[0009.554] SD-card IS present ...
[0009.557] load_and_boot_kernel: SD card detected OK
[0009.563] display_resolution: No display init
[0009.567] Failed to retrieve display resolution
[0009.571] bmp blob is not loaded and initialized
[0009.576] Failed to display boot-logo
[0009.580] NCK carveout not present
[0009.583] Skipping dts_overrides
[0009.586] NCK carveout not present
[0009.595] Find /i2c@7000c000's alias i2c0
[0009.599] get eeprom at 1-a0, size 256, type 0
[0009.608] Find /i2c@7000c500's alias i2c2
[0009.612] get eeprom at 3-a0, size 256, type 0
[0009.616] get eeprom at 3-ae, size 256, type 0
[0009.621] pm_ids_update: Updating 1,a0, size 256, type 0
[0009.626] I2C slave not started
[0009.629] I2C write failed
[0009.632] Writing offset failed
[0009.635] eeprom_init: EEPROM read failed
[0009.639] pm_ids_update: eeprom init failed
[0009.643] pm_ids_update: Updating 3,a0, size 256, type 0
[0009.673] pm_ids_update: The pm board id is 3448-0000-200
[0009.680] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0009.688] pm_ids_update: pm id update successful
[0009.693] pm_ids_update: Updating 3,ae, size 256, type 0
[0009.723] pm_ids_update: The pm board id is 3449-0000-200
[0009.729] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0009.737] pm_ids_update: pm id update successful
[0009.767] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0009.773] shim_eeprom_update_mac:267: Failed to update 0 MAC address in DTB
[0009.781] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0009.787] shim_eeprom_update_mac:267: Failed to update 1 MAC address in DTB
[0009.795] updating /chosen/nvidia,ethernet-mac node 00:04:4b:e5:59:5d
[0009.801] Plugin Manager: Parse ODM data 0x00084000
[0009.814] shim_cmdline_install: /chosen/bootargs: earlycon=uart8250,mmio32,0x70006000
[0009.823] Add serial number:1422019083619 as DT property
[0009.831] "bpmp" doesn't exist, creating
[0009.837] Updated bpmp info to DTB
[0009.842] Updated initrd info to DTB
[0009.845] "proc-board" doesn't exist, creating
[0009.851] Updated board info to DTB
[0009.855] "pmu-board" doesn't exist, creating
[0009.861] Updated board info to DTB
[0009.864] "display-board" doesn't exist, creating
[0009.870] Updated board info to DTB
[0009.873] "reset" doesn't exist, creating
[0009.878] Updated reset info to DTB
[0009.881] display_console_ioctl: No display init
[0009.886] display_console_ioctl: No display init
[0009.890] display_console_ioctl: No display init
[0009.895] Cmdline: tegraid=21.1.2.0.0 ddr_die=4096M@2048M section=512M memtype=0 vpr_resize usb_port_owner_info=0 lane_owner_info=0 emc_max_dvfs=0 touch_id=0@63 video=tegrafb no_console_suspend=1 console=ttyS0,115200n8 debug_uartport=lsport,0 earlyprintk=uart8250-32bit,0x70006000 maxcpus=4 usbcore.old_scheme_first=1 lp0_vec=0x1000@0xff780000 core_edp_mv=1075 core_edp_ma=4000 gpt
[0009.929] DTB cmdline: earlycon=uart8250,mmio32,0x70006000
[0009.935] boot image cmdline: root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fbcon=map:0 net.ifnames=0
[0009.948] Updated bootarg info to DTB
[0009.952] Adding uuid 00000001644476401800000006018280 to DT
[0009.958] Adding eks info 0 to DT
[0009.963] WARNING: Failed to pass NS DRAM ranges to TOS, err: -7
[0009.969] Updated memory info to DTB
[0009.975] Updated system-lp0-disable info to DTB
[0009.983] set vdd_core voltage to 1075 mv
[0009.986] setting 'vdd-core' regulator to 1075000 micro volts
[0009.992] Found secure-pmc; disable BPMP


U-Boot 2020.04-g46e4604c78 (Jul 26 2021 - 12:09:42 -0700)

SoC: tegra210
Model: NVIDIA Jetson Nano Developer Kit
Board: NVIDIA P3450-0000
DRAM:  4 GiB
MMC:   sdhci@700b0000: 1, sdhci@700b0600: 0
Loading Environment from SPI Flash... SF: Detected mx25u3235f with page size 256 Bytes, erase size 4 KiB, total 4 MiB
*** Warning - bad CRC, using default environment

In:    serial
Out:   serial
Err:   serial
Net:   No ethernet found.
Hit any key to stop autoboot:  2  1  0
switch to partitions #0, OK
mmc1 is current device
Scanning mmc 1:1...
Found /boot/extlinux/extlinux.conf
Retrieving file: /boot/extlinux/extlinux.conf
845 bytes read in 28 ms (29.3 KiB/s)
1:primary kernel
Retrieving file: /boot/initrd
7160133 bytes read in 334 ms (20.4 MiB/s)
Retrieving file: /boot/Image
34484232 bytes read in 1514 ms (21.7 MiB/s)
append: tegraid=21.1.2.0.0 ddr_die=4096M@2048M section=512M memtype=0 vpr_resize usb_port_owner_info=0 lane_owner_info=0 emc_max_dvfs=0 touch_id=0@63 video=tegrafb no_console_suspend=1 console=ttyS0,115200n8 debug_uartport=lsport,0 earlyprintk=uart8250-32bit,0x70006000 maxcpus=4 usbcore.old_scheme_first=1 lp0_vec=0x1000@0xff780000 core_edp_mv=1075 core_edp_ma=4000 gpt  earlycon=uart8250,mmio32,0x70006000  root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fbcon=map:0 net.ifnames=0 quiet root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fbcon=map:0 net.ifnames=0
## Flattened Device Tree blob at 83100000
   Booting using the fdt blob at 0x83100000
ERROR: reserving fdt memory region failed (addr=0 size=0)
ERROR: reserving fdt memory region failed (addr=0 size=0)
   Using Device Tree in place at 0000000083100000, end 000000008317ce2a
copying carveout for /host1x@50000000/dc@54200000...
copying carveout for /host1x@50000000/dc@54240000...

Starting kernel ...

[    0.000000] Booting Linux on physical CPU 0x0
[    0.000000] Linux version 4.9.253-tegra (buildbrain@mobile-u64-5496-d5000) (gcc version 7.3.1 20180425 [linaro-7.3-2018.05 revision d29120a424ecfbc167ef90065c0eeb7f91977701] (Linaro GCC 7.3-2018.05) ) #1 SMP PREEMPT Mon Jul 26 12:13:06 PDT 2021
[    0.000000] Boot CPU: AArch64 Processor [411fd071]
[    0.000000] OF: fdt:memory scan node memory@80000000, reg size 32,
[    0.000000] OF: fdt: - 80000000 ,  7ee00000
[    0.000000] OF: fdt: - 100000000 ,  7f200000
[    0.000000] earlycon: uart8250 at MMIO32 0x0000000070006000 (options '')
[    0.000000] bootconsole [uart8250] enabled
[    1.067771] tegradc tegradc.1: dpd enable lookup fail:-19
[    1.573559] Host read timeout at address 545c00c4
 P@@(h !@H"





microUSB 2A 이상 공급시 정상부팅

[0000.126] [TegraBoot] (version 00.00.2018.01-l4t-33e7fa82)
[0000.131] Processing in cold boot mode Bootloader 2
[0000.135] A02 Bootrom Patch rev = 1023
[0000.139] Power-up reason: pmc por
[0000.142] No Battery Present
[0000.145] pmic max77620 reset reason
[0000.148] pmic max77620 NVERC : 0x40
[0000.152] RamCode = 0
[0000.154] Platform has DDR4 type RAM
[0000.157] max77620 disabling SD1 Remote Sense
[0000.161] Setting DDR voltage to 1125mv
[0000.165] Serial Number of Pmic Max77663: 0x291ae2
[0000.173] Entering ramdump check
[0000.176] Get RamDumpCarveOut = 0x0
[0000.179] RamDumpCarveOut=0x0,  RamDumperFlag=0xe59ff3f8
[0000.184] Last reboot was clean, booting normally!
[0000.189] Sdram initialization is successful
[0000.193] SecureOs Carveout Base=0x00000000ff800000 Size=0x00800000
[0000.199] Lp0 Carveout Base=0x00000000ff780000 Size=0x00001000
[0000.205] BpmpFw Carveout Base=0x00000000ff700000 Size=0x00080000
[0000.211] GSC1 Carveout Base=0x00000000ff600000 Size=0x00100000
[0000.217] GSC2 Carveout Base=0x00000000ff500000 Size=0x00100000
[0000.223] GSC4 Carveout Base=0x00000000ff400000 Size=0x00100000
[0000.228] GSC5 Carveout Base=0x00000000ff300000 Size=0x00100000
[0000.234] GSC3 Carveout Base=0x000000017f300000 Size=0x00d00000
[0000.250] RamDump Carveout Base=0x00000000ff280000 Size=0x00080000
[0000.256] Platform-DebugCarveout: 0
[0000.260] Nck Carveout Base=0x00000000ff080000 Size=0x00200000
[0000.266] Non secure mode, and RB not enabled.
[0000.272] Invalid GPT Partition
[0000.287] Using BFS PT to query partitions
[0000.291] failed to load NvTbootTbootCpu from (2:0)
[0000.296] re-load NvTbootTbootCpu from (4:0)
[0000.349] Csd NumOfBlocks=122142720
[0000.408] Using GPT Primary to query partitions
[0000.416] Loading Tboot-CPU binary
[0000.793] Verifying TBC in OdmNonSecureSBK mode
[0000.803] Bootloader load address is 0xa0000000, entry address is 0xa0000258
[0000.810] Bootloader downloaded successfully.
[0000.814] Downloaded Tboot-CPU binary to 0xa0000258
[0000.819] MAX77620_GPIO5 configured
[0000.823] CPU power rail is up
[0000.826] CPU clock enabled
[0000.829] Performing RAM repair
[0000.832] Updating A64 Warmreset Address to 0xa00002e9
[0000.837] Loading NvTbootBootloaderDTB
[0002.149] Verifying NvTbootBootloaderDTB in OdmNonSecureSBK mode
[0002.220] Bootloader DTB Load Address: 0x83000000
[0002.225] Loading NvTbootKernelDTB
[0003.536] Verifying NvTbootKernelDTB in OdmNonSecureSBK mode
[0003.607] Kernel DTB Load Address: 0x83100000
[0003.615] Loading cboot binary
[0005.299] Verifying EBT in OdmNonSecureSBK mode
[0005.341] Bootloader load address is 0x92c00000, entry address is 0x92c00258
[0005.348] Bootloader downloaded successfully.
[0005.540] Using BFS PT to query partitions
[0005.544] Next binary entry address: 0x92c00258
[0005.549] BoardId: 3448
[0005.553] Overriding pmu board id with proc board id
[0005.558] Display board id is not available
[0007.057] Verifying SC7EntryFw in OdmNonSecureSBK mode
[0007.113] /bpmp deleted
[0007.115] SC7EntryFw header found loaded at 0xff700000
[0007.303] OVR2 PMIC
[0007.305] Bpmp FW successfully loaded
[0007.321] WB0 init successfully at 0xff780000
[0007.325] Set NvDecSticky Bits
[0007.329] GSC2 address ff53fffc value c0edbbcc
[0007.335] GSC MC Settings done
[0007.340] TOS Image length 53680
[0007.343]  Monitor size 53680
[0007.346]  OS size 0
[0007.507] Secure Os AES-CMAC Verification Success!
[0007.512] TOS image cipher info: plaintext
[0007.516] Loading and Validation of Secure OS Successful
[0007.532] SC7 Entry Firmware - 0xff700000, 0x4000
[0007.536] NvTbootPackSdramParams: start.
[0007.541] NvTbootPackSdramParams: done.
[0007.545] Tegraboot started after 53275 us
[0007.549] Basic modules init took 5643086 us
[0007.553] NvTbootQspiFlashIoctl: Opcode = 1 not supported
[0007.558] Sec Bootdevice Read Time = 12 ms, Read Size = 65 KB
[0007.564] Sec Bootdevice Write Time = 0 ms, Write Size = 0 KB
[0007.569] Storage Device Read Time = 6740 ms, Read Size = 2306 KB
[0007.575] Storage Device Write Time = 0 ms, Write Size = 0 KB
[0007.581] Next stage binary read took 1530456 us
[0007.585] Carveout took -1542135 us
[0007.588] CPU initialization took 2041876 us
[0007.593] Total time taken by TegraBoot 7673283 us

[0007.597] Starting CPU & Halting co-processor

64NOTICE:  BL31: v1.3(release):b5eeb33f7
NOTICE:  BL31: Built : 12:09:37, Jul 26 2021
ERROR:   Error initializing runtime service trusty_fast
[0007.719] RamCode = 0
[0007.724] LPDDR4 Training: Read DT: Number of tables = 2
[0007.729] EMC Training (SRC-freq: 204000; DST-freq: 1600000)
[0007.742] EMC Training Successful
[0007.745] 408000 not found in DVFS table
[0007.751] RamCode = 0
[0007.755] DT Write: emc-table@204000 succeeded
[0007.760] DT Write: emc-table@1600000 succeeded
[0007.764] LPDDR4 Training: Write DT: Number of tables = 2
[0007.960]
[0007.961] Debug Init done
[0007.963] Marked DTB cacheable
[0007.966] Bootloader DTB loaded at 0x83000000
[0007.971] Marked DTB cacheable
[0007.974] Kernel DTB loaded at 0x83100000
[0007.978] DeviceTree Init done
[0007.991] Pinmux applied successfully
[0007.995] gicd_base: 0x50041000
[0007.999] gicc_base: 0x50042000
[0008.002] Interrupts Init done
[0008.006] Using base:0x60005090 & irq:208 for tick-timer
[0008.011] Using base:0x60005098 for delay-timer
[0008.015] platform_init_timer: DONE
[0008.019] Timer(tick) Init done
[0008.023] osc freq = 38400 khz
[0008.026]
[0008.028] Welcome to L4T Cboot
[0008.031]
[0008.032] Cboot Version: 00.00.2018.01-t210-c952b4e6
[0008.037] calling constructors
[0008.040] initializing heap
[0008.042] initializing threads
[0008.045] initializing timers
[0008.048] creating bootstrap completion thread
[0008.052] top of bootstrap2()
[0008.055] CPU: ARM Cortex A57
[0008.058] CPU: MIDR: 0x411FD071, MPIDR: 0x80000000
[0008.063] initializing platform
[0008.070] Manufacturer: MF = 0xc2, ID MSB = 0x25
[0008.075] ID LSB = 0x36, ID-CFI len = 194 bytes
[0008.079] Macronix QSPI chip present
[0008.083] SPI device register
[0008.086] init boot device
[0008.088] allocating memory for boot device(SPI)
[0008.093] registering boot device
[0008.102] sdmmc node status = okay
[0008.105] sdcard instance = 0
[0008.108] sdmmc cd-inverted
[0008.111] sdcard gpio handle 0x5b
[0008.114] sdcard gpio pin 0xc9
[0008.117] sdcard gpio flags 0x0
[0008.120] vmmc-supply 0x9d
[0008.123] Instance: 0
[0008.125] Allocating memory for context
[0008.129] enabling clock
[0008.131] sd card init
[0008.133] Check card present and stable
[0008.137] Send command 0
[0008.154] Send command 3
[0008.158] Set RCA for the card
[0008.161] Query card specific data by command 9
[0008.167] Parse CSD data
[0008.170] Send command 7
[0008.180] Calling sd device register
[0008.183] Init sdcard
[0008.186] Allocating memory for boot device
[0008.190] Registering user device
[0008.203] Enable APE clock
[0008.205] Un-powergate APE partition
[0008.209] of_register: registering tegra_udc to of_hal
[0008.214] of_register: registering inv20628-driver to of_hal
[0008.220] of_register: registering ads1015-driver to of_hal
[0008.225] of_register: registering lp8557-bl-driver to of_hal
[0008.231] of_register: registering bq2419x_charger to of_hal
[0008.237] of_register: registering bq27441_fuel_gauge to of_hal
[0008.248] gpio framework initialized
[0008.251] of_register: registering tca9539_gpio to of_hal
[0008.257] of_register: registering tca9539_gpio to of_hal
[0008.262] of_register: registering i2c_bus_driver to of_hal
[0008.268] of_register: registering i2c_bus_driver to of_hal
[0008.273] of_register: registering i2c_bus_driver to of_hal
[0008.279] pmic framework initialized
[0008.282] of_register: registering max77620_pmic to of_hal
[0008.288] regulator framework initialized
[0008.292] of_register: registering tps65132_bl_driver to of_hal
[0008.298] initializing target
[0008.303] gpio_driver_register: register 'tegra_gpio_driver' driver
[0008.311] board ID = D78, board SKU = 0
[0008.315] Skipping Z3!
[0008.320] fixed regulator driver initialized
[0008.337] initializing OF layer
[0008.340] NCK carveout not present
[0008.344] Skipping dts_overrides
[0008.348] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.364] I2C Bus Init done
[0008.367] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.377] I2C Bus Init done
[0008.379] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.390] I2C Bus Init done
[0008.392] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.403] I2C Bus Init done
[0008.405] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.415] I2C Bus Init done
[0008.418] of_children_init: Ops found for compatible string maxim,max77620
[0008.428] max77620_init using irq 118
[0008.433] register 'maxim,max77620' pmic
[0008.437] gpio_driver_register: register 'max77620-gpio' driver
[0008.444] of_children_init: Ops found for compatible string nvidia,tegra210-i2c
[0008.454] I2C Bus Init done
[0008.458] NCK carveout not present
[0008.467] Find /i2c@7000c000's alias i2c0
[0008.471] get eeprom at 1-a0, size 256, type 0
[0008.479] Find /i2c@7000c500's alias i2c2
[0008.483] get eeprom at 3-a0, size 256, type 0
[0008.488] get eeprom at 3-ae, size 256, type 0
[0008.492] pm_ids_update: Updating 1,a0, size 256, type 0
[0008.497] I2C slave not started
[0008.500] I2C write failed
[0008.503] Writing offset failed
[0008.506] eeprom_init: EEPROM read failed
[0008.510] pm_ids_update: eeprom init failed
[0008.514] pm_ids_update: Updating 3,a0, size 256, type 0
[0008.544] pm_ids_update: The pm board id is 3448-0000-200
[0008.551] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0008.559] pm_ids_update: pm id update successful
[0008.564] pm_ids_update: Updating 3,ae, size 256, type 0
[0008.594] pm_ids_update: The pm board id is 3449-0000-200
[0008.600] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0008.608] pm_ids_update: pm id update successful
[0008.638] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0008.644] shim_eeprom_update_mac:267: Failed to update 0 MAC address in DTB
[0008.652] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0008.658] shim_eeprom_update_mac:267: Failed to update 1 MAC address in DTB
[0008.666] updating /chosen/nvidia,ethernet-mac node 00:04:4b:e5:59:5d
[0008.673] Plugin Manager: Parse ODM data 0x00084000
[0008.686] shim_cmdline_install: /chosen/bootargs: earlycon=uart8250,mmio32,0x70006000
[0008.700] Find /i2c@7000c000's alias i2c0
[0008.704] get eeprom at 1-a0, size 256, type 0
[0008.712] Find /i2c@7000c500's alias i2c2
[0008.716] get eeprom at 3-a0, size 256, type 0
[0008.721] get eeprom at 3-ae, size 256, type 0
[0008.725] pm_ids_update: Updating 1,a0, size 256, type 0
[0008.730] I2C slave not started
[0008.733] I2C write failed
[0008.736] Writing offset failed
[0008.739] eeprom_init: EEPROM read failed
[0008.743] pm_ids_update: eeprom init failed
[0008.747] pm_ids_update: Updating 3,a0, size 256, type 0
[0008.777] pm_ids_update: The pm board id is 3448-0000-200
[0008.783] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0008.790] pm_ids_update: pm id update successful
[0008.795] pm_ids_update: Updating 3,ae, size 256, type 0
[0008.825] pm_ids_update: The pm board id is 3449-0000-200
[0008.831] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0008.838] pm_ids_update: pm id update successful
[0008.869] Add serial number:1422019083619 as DT property
[0008.876] Applying platform configs
[0008.883] platform-init is not present. Skipping
[0008.887] calling apps_init()
[0008.912] Found 14 GPT partitions in "sd0"
[0008.916] Proceeding to Cold Boot
[0008.919] starting app android_boot_app
[0008.923] Device state: unlocked
[0008.926] display console init
[0008.935] could not find regulator
[0008.958] hdmi cable not connected
[0008.961] is_hdmi_needed: HDMI not connected, returning false
[0008.967] hDT entry for leds-pwm not found
d[0008.974] mi is not connected
[0008.977] sor0 is not supported
[0008.980] display_console_init: no valid display out_type
[0008.988] subnode volume_up is not found !
[0008.992] subnode back is not found !
[0008.996] subnode volume_down is not found !
[0009.000] subnode menu is not found !
[0009.003] Gpio keyboard init success
[0009.054] found decompressor handler: lz4-legacy
[0009.068] decompressing blob (type 1)...
[0009.134] display_resolution: No display init
[0009.138] Failed to retrieve display resolution
[0009.143] Could not load/initialize BMP blob...ignoring
[0009.194] decompressor handler not found
[0009.198] load_firmware_blob: Firmware blob loaded, entries=2
[0009.204] XUSB blob version 0 size 126464 @ 0x92cb328c
[0009.210] -------> se_aes_verify_sbk_clear: 747
[0009.214] se_aes_verify_sbk_clear: Error
[0009.218] SE operation failed
[0009.221] bl_battery_charging: connected to external power supply
[0009.230] display_console_ioctl: No display init
[0009.234] switch_backlight failed
[0009.240] device_query_partition_size: failed to open partition sd0:MSC !
[0009.247] MSC Partition not found
[0009.253] device_query_partition_size: failed to open partition sd0:USP !
[0009.260] USP partition read failed!
[0009.263] blob_init: blob-partition USP header read failed
[0009.269] android_boot Unable to update recovery partition
[0009.274] kfs_getpartname: name = LNX
[0009.278] Loading kernel from LNX
[0009.421] load kernel from storage
[0009.432] decompressor handler not found
[0009.516] Successfully loaded kernel and ramdisk images
[0009.521] board ID = D78, board SKU = 0
[0009.526] sdmmc node status = okay
[0009.529] sdcard instance = 0
[0009.532] sdmmc cd-inverted
[0009.535] sdcard gpio handle 0x5b
[0009.538] sdcard gpio pin 0xc9
[0009.541] sdcard gpio flags 0x0
[0009.544] vmmc-supply 0x9d
[0009.547] cd_gpio_pin = 201
[0009.549] pin_state = 0
[0009.552] Found sdcard
[0009.554] SD-card IS present ...
[0009.557] load_and_boot_kernel: SD card detected OK
[0009.563] display_resolution: No display init
[0009.567] Failed to retrieve display resolution
[0009.571] bmp blob is not loaded and initialized
[0009.576] Failed to display boot-logo
[0009.580] NCK carveout not present
[0009.583] Skipping dts_overrides
[0009.586] NCK carveout not present
[0009.596] Find /i2c@7000c000's alias i2c0
[0009.599] get eeprom at 1-a0, size 256, type 0
[0009.608] Find /i2c@7000c500's alias i2c2
[0009.612] get eeprom at 3-a0, size 256, type 0
[0009.616] get eeprom at 3-ae, size 256, type 0
[0009.621] pm_ids_update: Updating 1,a0, size 256, type 0
[0009.626] I2C slave not started
[0009.629] I2C write failed
[0009.632] Writing offset failed
[0009.635] eeprom_init: EEPROM read failed
[0009.639] pm_ids_update: eeprom init failed
[0009.643] pm_ids_update: Updating 3,a0, size 256, type 0
[0009.673] pm_ids_update: The pm board id is 3448-0000-200
[0009.680] Adding plugin-manager/ids/3448-0000-200=/i2c@7000c500:module@0x50
[0009.688] pm_ids_update: pm id update successful
[0009.693] pm_ids_update: Updating 3,ae, size 256, type 0
[0009.723] pm_ids_update: The pm board id is 3449-0000-200
[0009.729] Adding plugin-manager/ids/3449-0000-200=/i2c@7000c500:module@0x57
[0009.737] pm_ids_update: pm id update successful
[0009.767] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0009.773] shim_eeprom_update_mac:267: Failed to update 0 MAC address in DTB
[0009.781] eeprom_get_mac: EEPROM invalid MAC address (all 0xff)
[0009.787] shim_eeprom_update_mac:267: Failed to update 1 MAC address in DTB
[0009.795] updating /chosen/nvidia,ethernet-mac node 00:04:4b:e5:59:5d
[0009.801] Plugin Manager: Parse ODM data 0x00084000
[0009.814] shim_cmdline_install: /chosen/bootargs: earlycon=uart8250,mmio32,0x70006000
[0009.823] Add serial number:1422019083619 as DT property
[0009.831] "bpmp" doesn't exist, creating
[0009.837] Updated bpmp info to DTB
[0009.842] Updated initrd info to DTB
[0009.845] "proc-board" doesn't exist, creating
[0009.851] Updated board info to DTB
[0009.855] "pmu-board" doesn't exist, creating
[0009.861] Updated board info to DTB
[0009.864] "display-board" doesn't exist, creating
[0009.870] Updated board info to DTB
[0009.873] "reset" doesn't exist, creating
[0009.878] Updated reset info to DTB
[0009.881] display_console_ioctl: No display init
[0009.886] display_console_ioctl: No display init
[0009.890] display_console_ioctl: No display init
[0009.895] Cmdline: tegraid=21.1.2.0.0 ddr_die=4096M@2048M section=512M memtype=0 vpr_resize usb_port_owner_info=0 lane_owner_info=0 emc_max_dvfs=0 touch_id=0@63 video=tegrafb no_console_suspend=1 console=ttyS0,115200n8 debug_uartport=lsport,0 earlyprintk=uart8250-32bit,0x70006000 maxcpus=4 usbcore.old_scheme_first=1 lp0_vec=0x1000@0xff780000 core_edp_mv=1075 core_edp_ma=4000 gpt
[0009.929] DTB cmdline: earlycon=uart8250,mmio32,0x70006000
[0009.935] boot image cmdline: root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fbcon=map:0 net.ifnames=0
[0009.948] Updated bootarg info to DTB
[0009.952] Adding uuid 00000001644476401800000006018280 to DT
[0009.958] Adding eks info 0 to DT
[0009.963] WARNING: Failed to pass NS DRAM ranges to TOS, err: -7
[0009.969] Updated memory info to DTB
[0009.975] Updated system-lp0-disable info to DTB
[0009.983] set vdd_core voltage to 1075 mv
[0009.987] setting 'vdd-core' regulator to 1075000 micro volts
[0009.992] Found secure-pmc; disable BPMP


U-Boot 2020.04-g46e4604c78 (Jul 26 2021 - 12:09:42 -0700)

SoC: tegra210
Model: NVIDIA Jetson Nano Developer Kit
Board: NVIDIA P3450-0000
DRAM:  4 GiB
MMC:   sdhci@700b0000: 1, sdhci@700b0600: 0
Loading Environment from SPI Flash... SF: Detected mx25u3235f with page size 256 Bytes, erase size 4 KiB, total 4 MiB
*** Warning - bad CRC, using default environment

In:    serial
Out:   serial
Err:   serial
Net:   No ethernet found.
Hit any key to stop autoboot:  2  1  0
switch to partitions #0, OK
mmc1 is current device
Scanning mmc 1:1...
Found /boot/extlinux/extlinux.conf
Retrieving file: /boot/extlinux/extlinux.conf
845 bytes read in 28 ms (29.3 KiB/s)
1:primary kernel
Retrieving file: /boot/initrd
7160133 bytes read in 334 ms (20.4 MiB/s)
Retrieving file: /boot/Image
34484232 bytes read in 1513 ms (21.7 MiB/s)
append: tegraid=21.1.2.0.0 ddr_die=4096M@2048M section=512M memtype=0 vpr_resize usb_port_owner_info=0 lane_owner_info=0 emc_max_dvfs=0 touch_id=0@63 video=tegrafb no_console_suspend=1 console=ttyS0,115200n8 debug_uartport=lsport,0 earlyprintk=uart8250-32bit,0x70006000 maxcpus=4 usbcore.old_scheme_first=1 lp0_vec=0x1000@0xff780000 core_edp_mv=1075 core_edp_ma=4000 gpt  earlycon=uart8250,mmio32,0x70006000  root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fbcon=map:0 net.ifnames=0 quiet root=/dev/mmcblk0p1 rw rootwait rootfstype=ext4 console=ttyS0,115200n8 console=tty0 fbcon=map:0 net.ifnames=0
## Flattened Device Tree blob at 83100000
   Booting using the fdt blob at 0x83100000
ERROR: reserving fdt memory region failed (addr=0 size=0)
ERROR: reserving fdt memory region failed (addr=0 size=0)
   Using Device Tree in place at 0000000083100000, end 000000008317ce2a
copying carveout for /host1x@50000000/dc@54200000...
copying carveout for /host1x@50000000/dc@54240000...

Starting kernel ...

[    0.000000] Booting Linux on physical CPU 0x0
[    0.000000] Linux version 4.9.253-tegra (buildbrain@mobile-u64-5496-d5000) (gcc version 7.3.1 20180425 [linaro-7.3-2018.05 revision d29120a424ecfbc167ef90065c0eeb7f91977701] (Linaro GCC 7.3-2018.05) ) #1 SMP PREEMPT Mon Jul 26 12:13:06 PDT 2021
[    0.000000] Boot CPU: AArch64 Processor [411fd071]
[    0.000000] OF: fdt:memory scan node memory@80000000, reg size 32,
[    0.000000] OF: fdt: - 80000000 ,  7ee00000
[    0.000000] OF: fdt: - 100000000 ,  7f200000
[    0.000000] earlycon: uart8250 at MMIO32 0x0000000070006000 (options '')
[    0.000000] bootconsole [uart8250] enabled
[    1.080366] tegradc tegradc.1: dpd enable lookup fail:-19
[    1.586070] Host read timeout at address 545c00c4
[    1.784584] imx219 7-0010: imx219_board_setup: error during i2c read probe (-121)
[    1.792265] imx219 7-0010: board setup failed
[    1.820680] imx219 8-0010: imx219_board_setup: error during i2c read probe (-121)
[    1.828261] imx219 8-0010: board setup failed
[    2.750802] cgroup: cgroup2: unknown option "nsdelegate"
[    3.746759] using random self ethernet address
[    3.751247] using random host ethernet address
[    4.192542] random: crng init done
[    4.195947] random: 7 urandom warning(s) missed due to ratelimiting
[    4.211160] using random self ethernet address
[    4.215693] using random host ethernet address
[   11.856321] Please complete system configuration setup on the serial port provided by Jetson's USB device mode connection. e.g. /dev/ttyACMx where x can 0, 1, 2 etc.
저작자표시 (새창열림)

'embeded > jetson' 카테고리의 다른 글

flud nvidia cuda  (0) 2022.03.28
jetson nano deepstream  (0) 2022.02.10
nvidia jetson nano 2gb / csi  (0) 2022.01.21
jetson nano gpu 사용 상태 확인  (0) 2022.01.20
jetson nano 2g dev. kit 셋업  (0) 2022.01.20
Posted by 구차니
Linux2022. 2. 8. 17:59

sort 컬럼 별 정렬하기

ls 해서 용량별로 보고 싶어 검색



흐음.. 아름답지 않아!! (길어서 외우기 싫다는 의미)

$ ls --sort=size -l



이런 산뜻한 걸 먼저 알려줬어야지!!

-S Sort by file size, largest first

[링크 : https://www.cyberciti.biz/faq/linux-ls-command-sort-by-file-size/]



$ sort -k 3,3 myFile

[링크 : https://unix.stackexchange.com/questions/104525/sort-based-on-the-third-column]



-k, --key=POS1[,POS2]
       start a key at POS1 (origin 1), end it at POS2 (default end of line)

[링크 : https://linux.die.net/man/1/sort]



우분투 내 도움말에는 key 라고 나오네. 설명이 와닫지 않아!

       -k, --key=KEYDEF
              sort via a key; KEYDEF gives location and type
저작자표시 (새창열림)

'Linux' 카테고리의 다른 글

bash set -e set -x  (0) 2022.06.22
linux cache clear  (0) 2022.02.11
elementary os  (0) 2022.01.28
linux 터미널 pause, resume  (0) 2022.01.11
systemctl TTYPath  (0) 2022.01.06
Posted by 구차니

티스토리툴바
