Archiving Projects

You can save the elements of a project in a single, compressed Quartus II Archive File (. qar) by clicking

Project > Archive Project.

The .qar captures logic design, project, and settings files required to restore the project.

Use this technique to share projects between designers, or to transfer your project to a new version of the

Quartus II software, or to Altera support. You can optionally add compilation results, Qsys system files, and

third-party EDA tool files to the archive. If you restore the archive in a different version of the Quartus II

software, you must include the original .qdf in the archive to preserve original compilation results.

게이트-레벨시뮬레이션은타이밍시뮬레이션에서 기능적결과의차이만을확인한다. 만약게이트-레벨시뮬레 이션은문제없고타이밍시뮬레이션이실패했다면, 넷리스트 가아닌타이밍으로발생된부분임을나타낸다. 백-어노테이트 타이밍 시뮬레이션은 타이밍 정보가 있는 게이트-레벨 시뮬레이션이다. 이를 위해 FPGA 벤더는 VITAL (VHDL Gate Level) 넷리스트 또는 Verilog 넷리스 트를 생성한다

 always @ (posedge clk or negedge rst)

begin

if (~rst)

cnt <= 0;

else

begin

if(cnt < 834000)

cnt <= cnt + 1;

else

cnt <= 0;

end

if(cnt < HSYNC)

hsync <= 1;

else hsync <= 0;

if(cnt < VSYNC)

vsync <= 1;

else vsync <= 0;

end

 always @ (posedge clk or negedge rst)

begin

if (~rst)

cnt <= 0;

else

begin

if(cnt < 834000)

begin

cnt <= cnt + 1;

if(cnt < HSYNC)

hsync <= 1;

else hsync <= 0;

if(cnt < VSYNC)

vsync <= 1;

else vsync <= 0;

end

else

cnt <= 0;

end

end

//=======================================================

//  This code is generated by Terasic System Builder

//=======================================================

module PwmCtrl(RST_N, CLK, LED0);

input RST_N, CLK;

output LED0;

reg[27:0] counter0;

always @(negedge RST_N or posedge CLK)

begin

if(RST_N == 1'b0)

begin

counter0 <= 0;

end else begin

counter0 <= counter0 + 1;

end

end

assign LED0 = counter0[26];

endmodule

module DE0_NANO(

//////////// CLOCK //////////

CLOCK_50,

//////////// LED //////////

LED,

//////////// KEY //////////

KEY

);

//=======================================================

//  PARAMETER declarations

//=======================================================

//=======================================================

//  PORT declarations

//=======================================================

//////////// CLOCK //////////

input           CLOCK_50;

//////////// LED //////////

output      [7:0] LED;

//////////// KEY //////////

input      [1:0] KEY;

//=======================================================

//  REG/WIRE declarations

//=======================================================

//=======================================================

//  Structural coding

//=======================================================

PwmCtrl pwm(KEY[0],

CLOCK_50,

LED[0]);

endmodule

To enable the TalkBack feature in Quartus Prime, select Tools > Options. In the Options window, select Internet Connectivity from the menu, and click on TalkBack Options... to open the window shown in Figure 2. If you accept the TalkBack License Agreement, then check the box labelled Enable sending TalkBack data to Intel and click OK.

Intel Quartus Prime Pro Edition software does not support the following Intel Quartus Prime Standard Edition features:

— I/O Timing Analysis

— NativeLink third party tool integration

— Video and Image Processing Suite IP Cores

— Talkback features

— Various register merging and duplication settings

— Saving a node-level netlist as .vqm

— Compare project revisions

2016.10.31 16.1.0

Removed all references to Talkback feature.

Changed instances of Altera to Intel FPGA.

※ Quartus Prime Lite Edition の場合は、16.0 以前のバージョンを使用する際 TalkBack 機能を有効にする 必要があります。詳細はこちらの TIPS をご覧ください。

Quartus Prime Lite Edition의 경우 16.0 이전 버전을 사용하는 경우 TalkBack 기능을 활성화해야합니다. 자세한 것은 이쪽의 TIPS를 참조하십시오.

//=======================================================

//  This code is generated by Terasic System Builder

//=======================================================

module PwmCtrl(RST_N, CLK, LED0);

input RST_N, CLK;

output LED0;

reg[27:0] counter0;

always @(negedge RST_N or posedge CLK)

begin

if(RST_N == 1'b0)

begin

counter0 <= 0;

end else begin

counter0 <= counter0 + 1;

end

end

assign LED0 = counter0[1];

endmodule

module DE0_NANO(

//////////// CLOCK //////////

CLOCK_50,

//////////// LED //////////

LED,

//////////// KEY //////////

KEY

);

//=======================================================

//  PARAMETER declarations

//=======================================================

//=======================================================

//  PORT declarations

//=======================================================

//////////// CLOCK //////////

input           CLOCK_50;

//////////// LED //////////

output      [7:0] LED;

//////////// KEY //////////

input      [1:0] KEY;

//=======================================================

//  REG/WIRE declarations

//=======================================================

//=======================================================

//  Structural coding

//=======================================================

PwmCtrl pwm0(KEY[0],CLOCK_50,LED[0]);

endmodule

Error (170048): Selected device has 66 RAM location(s) of type M9K.  However, the current design needs more than 66 to successfully fit

Error (171000): Can't fit design in device
