몇년에 걸쳐서 막혔던게 이렇게 쉽게 몇번의 피드백으로 주어지다니..

공부가 의미없는 시대인가.. (현타)



curl -O https://raw.githubusercontent.com/nothings/stb/master/stb_image.h
wget https://m.health.chosun.com/site/data/img_dir/2025/04/08/2025040803041_0.jpg
mv 2025040803041_0.jpg dog.jpg



#include <GL/glut.h>
#include <math.h>
#include <stdio.h>

#define STB_IMAGE_IMPLEMENTATION
#include "stb_image.h"

// 창 크기
int width = 800;
int height = 600;

// 카메라 변수
float cam_pos_x = 5.0f, cam_pos_y = 4.0f, cam_pos_z = 5.0f;
float cam_yaw = -135.0f; // Y축 기준 회전 (좌/우)
float cam_pitch = -30.0f;  // X축 기준 회전 (상/하)
float fov = 45.0f; // 시야각 (줌인/아웃용)

// 마우스 상태 변수
int last_mouse_x, last_mouse_y;
int is_panning = 0; // 휠 드래그(패닝) 상태
int is_rotating = 0; // 좌클릭 드래그(회전) 상태

// 객체 회전 변수
float obj_rot_x = 0.0f;
float obj_rot_y = 0.0f;

// 클리핑 평면 변수
float near_plane = 1.0f;
float far_plane = 100.0f;

// 텍스처 변수
GLuint texture_id;
int texture_enabled = 1; // 텍스처 활성화 상태

// 카메라 방향 벡터 계산
void update_camera_vectors(float* front_x, float* front_z, float* up_x, float* up_y, float* up_z, float* right_x, float* right_z) {
	float yaw_rad = cam_yaw * M_PI / 180.0f;
	float pitch_rad = cam_pitch * M_PI / 180.0f;

	// 시점 방향 벡터
	*front_x = cos(yaw_rad) * cos(pitch_rad);
	*front_z = sin(yaw_rad) * cos(pitch_rad);

	// 오른쪽 벡터 (패닝에 사용)
	*right_x = cos(yaw_rad - M_PI / 2.0f);
	*right_z = sin(yaw_rad - M_PI / 2.0f);

	// 위쪽 벡터 (패닝에 사용)
	// 간단한 구현을 위해 Y축 고정
	*up_x = 0.0f;
	*up_y = 1.0f;
	*up_z = 0.0f;
}

void draw_scene() {
	glPushMatrix();
	glRotatef(obj_rot_x, 1.0f, 0.0f, 0.0f); // X축 회전
	glRotatef(obj_rot_y, 0.0f, 1.0f, 0.0f); // Y축 회전

	// 뚫린 상자 그리기 (6개의 면을 각각 그림)
	float thickness = 0.1f;

	// 앞면 (빨강)
	glPushMatrix();
	glColor3f(1.0, 0.0, 0.0);
	glTranslatef(0, 0, 1.5f);
	glScalef(3.0f, 3.0f, thickness);
	glutSolidCube(1.0);
	glPopMatrix();

	// 뒷면 (초록)
	glPushMatrix();
	glColor3f(0.0, 1.0, 0.0);
	glRotatef(180, 0, 1, 0);
	glTranslatef(0, 0, 1.5f);
	glScalef(3.0f, 3.0f, thickness);
	glutSolidCube(1.0);
	glPopMatrix();

	// 왼쪽 (파랑)
	glPushMatrix();
	glColor3f(0.0, 0.0, 1.0);
	glRotatef(-90, 0, 1, 0);
	glTranslatef(0, 0, 1.5f);
	glScalef(3.0f, 3.0f, thickness);
	glutSolidCube(1.0);
	glPopMatrix();

	// 오른쪽 (노랑)
	glPushMatrix();
	glColor3f(1.0, 1.0, 0.0);
	glRotatef(90, 0, 1, 0);
	glTranslatef(0, 0, 1.5f);
	glScalef(3.0f, 3.0f, thickness);
	glutSolidCube(1.0);
	glPopMatrix();

	// 윗면 (마젠타)
	glPushMatrix();
	glColor3f(1.0, 0.0, 1.0);
	glRotatef(90, 1, 0, 0);
	glTranslatef(0, 0, 1.5f);
	glScalef(3.0f, thickness, 3.0f - thickness*2);
	glutSolidCube(1.0);
	glPopMatrix();

	// 아랫면 (시안)
	glPushMatrix();
	glColor3f(0.0, 1.0, 1.0);
	glRotatef(-90, 1, 0, 0);
	glTranslatef(0, 0, 1.5f);
	glScalef(3.0f, thickness, 3.0f - thickness*2);
	glutSolidCube(1.0);
	glPopMatrix();


	// 텍스처가 입혀진 원통 그리기
	if (texture_enabled) {
		glEnable(GL_TEXTURE_2D);
		glBindTexture(GL_TEXTURE_2D, texture_id);
	}

	glColor3f(1.0, 1.0, 1.0); // 텍스처와 곱해질 색상
	GLUquadric* quad = gluNewQuadric();
	gluQuadricTexture(quad, GL_TRUE);
	gluCylinder(quad, 0.5, 0.5, 2.0, 32, 32);
	gluDeleteQuadric(quad);

	if (texture_enabled) {
		glDisable(GL_TEXTURE_2D);
	}

	glPopMatrix();
}

// 텍스트 렌더링 함수
void render_text(int x, int y, const char* string) {
	glRasterPos2f(x, y);
	for (const char* c = string; *c != '\0'; c++) {
		glutBitmapCharacter(GLUT_BITMAP_HELVETICA_12, *c);
	}
}

// 행렬 정보 출력 함수
void draw_matrix_info() {
	GLfloat modelview[16];
	GLfloat projection[16];
	GLfloat rotation[16];
	char buffer[128];

	glGetFloatv(GL_MODELVIEW_MATRIX, modelview);
	glGetFloatv(GL_PROJECTION_MATRIX, projection);

	// 회전 행렬 계산
	glMatrixMode(GL_MODELVIEW);
	glPushMatrix();
	glLoadIdentity();
	glRotatef(obj_rot_x, 1.0f, 0.0f, 0.0f);
	glRotatef(obj_rot_y, 0.0f, 1.0f, 0.0f);
	glGetFloatv(GL_MODELVIEW_MATRIX, rotation);
	glPopMatrix();

	glColor3f(1.0, 1.0, 1.0); // 흰색으로 설정

	// 2D 렌더링을 위해 투영 행렬 변경
	glMatrixMode(GL_PROJECTION);
	glPushMatrix();
	glLoadIdentity();
	gluOrtho2D(0, width, 0, height);

	glMatrixMode(GL_MODELVIEW);
	glPushMatrix();
	glLoadIdentity();

	// Model-View Matrix 정보 출력
	sprintf(buffer, "Model-View Matrix:");
	render_text(10, height - 20, buffer);
	for (int i = 0; i < 4; i++) {
		sprintf(buffer, "%.2f %.2f %.2f %.2f", modelview[i*4], modelview[i*4+1], modelview[i*4+2], modelview[i*4+3]);
		render_text(10, height - 35 - (i * 15), buffer);
	}

	// Projection Matrix 정보 출력
	sprintf(buffer, "Projection Matrix:");
	render_text(10, height - 100, buffer);
	for (int i = 0; i < 4; i++) {
		sprintf(buffer, "%.2f %.2f %.2f %.2f", projection[i*4], projection[i*4+1], projection[i*4+2], projection[i*4+3]);
		render_text(10, height - 115 - (i * 15), buffer);
	}

	// Rotation Matrix 정보 출력
	sprintf(buffer, "Rotation Matrix:");
	render_text(10, height - 180, buffer);
	for (int i = 0; i < 4; i++) {
		sprintf(buffer, "%.2f %.2f %.2f %.2f", rotation[i*4], rotation[i*4+1], rotation[i*4+2], rotation[i*4+3]);
		render_text(10, height - 195 - (i * 15), buffer);
	}

	// Near/Far 정보 출력
	sprintf(buffer, "Near: %.2f, Far: %.2f", near_plane, far_plane);
	render_text(10, height - 260, buffer);

	// 원래의 투영, 모델뷰 행렬로 복원
	glMatrixMode(GL_PROJECTION);
	glPopMatrix();
	glMatrixMode(GL_MODELVIEW);
	glPopMatrix();
}

void display() {
	glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);

	float yaw_rad = cam_yaw * M_PI / 180.0f;
	float pitch_rad = cam_pitch * M_PI / 180.0f;
	float eye_separation = 0.5f; // 눈 사이 간격

	// 오른쪽 벡터 계산
	float right_x = cos(yaw_rad - M_PI / 2.0f);
	float right_z = sin(yaw_rad - M_PI / 2.0f);

	// 왼쪽 눈 렌더링
	glViewport(0, 0, width / 2, height);
	glMatrixMode(GL_PROJECTION);
	glLoadIdentity();
	gluPerspective(fov, (double)(width/2) / (double)height, near_plane, far_plane);
	glMatrixMode(GL_MODELVIEW);
	glLoadIdentity();

	float left_cam_x = cam_pos_x - right_x * eye_separation / 2.0f;
	float left_cam_z = cam_pos_z - right_z * eye_separation / 2.0f;
	float look_at_x = left_cam_x + cos(yaw_rad) * cos(pitch_rad);
	float look_at_y = cam_pos_y + sin(pitch_rad);
	float look_at_z = left_cam_z + sin(yaw_rad) * cos(pitch_rad);
	gluLookAt(left_cam_x, cam_pos_y, left_cam_z, look_at_x, look_at_y, look_at_z, 0.0, 1.0, 0.0);
	draw_scene();
	draw_matrix_info();

	// 오른쪽 눈 렌더링
	glViewport(width / 2, 0, width / 2, height);
	glMatrixMode(GL_PROJECTION);
	glLoadIdentity();
	gluPerspective(fov, (double)(width/2) / (double)height, near_plane, far_plane);
	glMatrixMode(GL_MODELVIEW);
	glLoadIdentity();

	float right_cam_x = cam_pos_x + right_x * eye_separation / 2.0f;
	float right_cam_z = cam_pos_z + right_z * eye_separation / 2.0f;
	look_at_x = right_cam_x + cos(yaw_rad) * cos(pitch_rad);
	look_at_y = cam_pos_y + sin(pitch_rad);
	look_at_z = right_cam_z + sin(yaw_rad) * cos(pitch_rad);
	gluLookAt(right_cam_x, cam_pos_y, right_cam_z, look_at_x, look_at_y, look_at_z, 0.0, 1.0, 0.0);
	draw_scene();
	draw_matrix_info();

	glutSwapBuffers();
}

void reshape(int w, int h) {
	width = w;
	h = h > 0 ? h : 1;
	glViewport(0, 0, width, height);

	glMatrixMode(GL_PROJECTION);
	glLoadIdentity();
	gluPerspective(fov, (double)width / (double)height, 1.0, 100.0);
}

void keyboard(unsigned char key, int x, int y) {
	float speed = 0.1f;
	float yaw_rad = cam_yaw * M_PI / 180.0f;

	switch (key) {
		case 'w':
			cam_pos_x += cos(yaw_rad) * speed;
			cam_pos_z += sin(yaw_rad) * speed;
			break;
		case 's':
			cam_pos_x -= cos(yaw_rad) * speed;
			cam_pos_z -= sin(yaw_rad) * speed;
			break;
		case 'a':
			cam_pos_x += cos(yaw_rad - M_PI / 2.0f) * speed;
			cam_pos_z += sin(yaw_rad - M_PI / 2.0f) * speed;
			break;
		case 'd':
			cam_pos_x -= cos(yaw_rad - M_PI / 2.0f) * speed;
			cam_pos_z -= sin(yaw_rad - M_PI / 2.0f) * speed;
			break;
		case 'r': // 리셋 기능
			cam_pos_x = 5.0f; cam_pos_y = 4.0f; cam_pos_z = 5.0f;
			cam_yaw = -135.0f;
			cam_pitch = -30.0f;
			fov = 45.0f;
			obj_rot_x = 0.0f;
			obj_rot_y = 0.0f;
			near_plane = 1.0f;
			far_plane = 100.0f;
			reshape(width, height);
			break;
		case 'i': // near 증가
			near_plane += 0.1f;
			break;
		case 'k': // near 감소
			near_plane -= 0.1f;
			if (near_plane < 0.1f) near_plane = 0.1f; // 0보다 작아지지 않도록
			break;
		case 'o': // far 증가
			far_plane += 0.1f;
			break;
		case 'l': // far 감소
			far_plane -= 0.1f;
			if (far_plane < near_plane) far_plane = near_plane + 0.1f; // near보다 작아지지 않도록
			break;
		case 't': // 텍스처 토글
			texture_enabled = !texture_enabled;
			break;
	}
	glutPostRedisplay();
}

void specialKeys(int key, int x, int y) {
	float rot_speed = 5.0f;
	switch (key) {
		case GLUT_KEY_UP:
			obj_rot_x -= rot_speed;
			break;
		case GLUT_KEY_DOWN:
			obj_rot_x += rot_speed;
			break;
		case GLUT_KEY_LEFT:
			obj_rot_y -= rot_speed;
			break;
		case GLUT_KEY_RIGHT:
			obj_rot_y += rot_speed;
			break;
	}
	glutPostRedisplay();
}

void mouse(int button, int state, int x, int y) {
	// 휠 줌 인/아웃
	if (button == 3) { // 휠 업
		fov -= 1.0f;
		if (fov < 1.0f) fov = 1.0f;
		reshape(width, height); // 투영 행렬 업데이트
	} else if (button == 4) { // 휠 다운
		fov += 1.0f;
		if (fov > 90.0f) fov = 90.0f;
		reshape(width, height); // 투영 행렬 업데이트
	}

	// 휠 클릭 (패닝)
	if (button == GLUT_MIDDLE_BUTTON) {
		if (state == GLUT_DOWN) {
			is_panning = 1;
			last_mouse_x = x;
			last_mouse_y = y;
		} else {
			is_panning = 0;
		}
	}

	// 좌클릭 (회전)
	if (button == GLUT_LEFT_BUTTON) {
		if (state == GLUT_DOWN) {
			is_rotating = 1;
			last_mouse_x = x;
			last_mouse_y = y;
		} else {
			is_rotating = 0;
		}
	}
	glutPostRedisplay();
}

void motion(int x, int y) {
	int dx = x - last_mouse_x;
	int dy = y - last_mouse_y;
	last_mouse_x = x;
	last_mouse_y = y;

	if (is_panning) {
		float pan_speed = 0.01f;
		float front_x, front_z, up_x, up_y, up_z, right_x, right_z;
		update_camera_vectors(&front_x, &front_z, &up_x, &up_y, &up_z, &right_x, &right_z);

		cam_pos_x -= right_x * dx * pan_speed;
		cam_pos_z -= right_z * dx * pan_speed;
		cam_pos_y += dy * pan_speed; // Y축 방향으로 이동
	} else if (is_rotating) {
		float rot_speed = 0.5f;
		obj_rot_y += dx * rot_speed;
		obj_rot_x += dy * rot_speed;
	}
	glutPostRedisplay();
}


void init() {
	glClearColor(0.1, 0.1, 0.1, 1.0);
	glEnable(GL_DEPTH_TEST);
}

// 텍스처 로드 함수
void load_texture(const char* filename) {
	int width, height, nrChannels;
	unsigned char *data = stbi_load(filename, &width, &height, &nrChannels, 0);
	if (data) {
		glGenTextures(1, &texture_id);
		glBindTexture(GL_TEXTURE_2D, texture_id);

		glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_REPEAT);
		glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_REPEAT);
		glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
		glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);

		GLenum format = (nrChannels == 4) ? GL_RGBA : GL_RGB;
		glTexImage2D(GL_TEXTURE_2D, 0, format, width, height, 0, format, GL_UNSIGNED_BYTE, data);
		stbi_image_free(data);
	} else {
		printf("Failed to load texture: %s\n", filename);
		stbi_image_free(data);
	}
}

void print_help() {
	printf("====== Key Controls ======\n");
	printf(" w, a, s, d : Move Camera\n");
	printf(" Arrow Keys : Rotate Object\n");
	printf(" i, k       : Adjust Near Plane\n");
	printf(" o, l       : Adjust Far Plane\n");
	printf(" r          : Reset Camera and Object\n");
	printf(" t          : Toggle Texture\n");
	printf("--------------------------\n");
	printf("====== Mouse Controls ======\n");
	printf(" Left Drag  : Rotate Object\n");
	printf(" Wheel Drag : Pan Camera\n");
	printf(" Wheel Scroll: Zoom (Adjust FOV)\n");
	printf("==========================\n");
}

int main(int argc, char** argv) {
	print_help();
	glutInit(&argc, argv);
	glutInitDisplayMode(GLUT_DOUBLE | GLUT_RGBA | GLUT_DEPTH);
	glutInitWindowSize(width, height);
	glutCreateWindow("OpenGL Camera Control Demo");

	glutDisplayFunc(display);
	glutReshapeFunc(reshape);
	glutKeyboardFunc(keyboard);
	glutSpecialFunc(specialKeys);
	glutMouseFunc(mouse);
	glutMotionFunc(motion); // 마우스 버튼이 눌린 상태에서의 움직임

	init();
	load_texture("dog.jpg"); // 텍스처 로드
	glutMainLoop();

	return 0;
}

'Programming > openGL' 카테고리의 다른 글

blender in openGL  (0) 2025.04.28
opengl glortho gluperspective  (0) 2023.08.28
glReadPixels() 와 glUseProgram()  (0) 2022.11.17
openCV + openGL  (0) 2022.02.08
glMatrixMode()  (0) 2020.04.14
Posted by 구차니
Programming/openGL2025. 4. 28. 19:06

Open Asset Import Library(assimp) 를 이용해서 blender를 읽어오고 openGL로 그릴수 있는 것으로 보인다.



Features

  • Reads more than 30 3D file formats, including Collada, X, 3DS, Blend, Obj
  • Converts them to a hierarchical in-memory data structure
  • Provides 'post-processing steps' to improve the input data, i.e. generate normals and tangents or fix import issues.
  • Provides APIs for both C and C++
  • Imports skeleton animations and skinning weights
  • Supports complex multi-layer materials
  • www.open3mod.com/ is an Open-Source viewer that is based off assimp to view models (Windows only)

[링크 : https://sourceforge.net/projects/assimp/]



Assimp::Importer importer;
const aiScene *scene = importer.ReadFile(filename,aiProcessPreset_TargetRealtime_Fast);
aiMesh *mesh = scene->mMeshes[0]; //assuming you only want the first mesh

float *vertexArray;
float *normalArray;
float *uvArray;

int numVerts;
next extract the data

numVerts = mesh->mNumFaces*3;

vertexArray = new float[mesh->mNumFaces*3*3];
normalArray = new float[mesh->mNumFaces*3*3];
uvArray = new float[mesh->mNumFaces*3*2];

for(unsigned int i=0;i<mesh->mNumFaces;i++)
{
    const aiFace& face = mesh->mFaces[i];

    for(int j=0;j<3;j++)
    {
        aiVector3D uv = mesh->mTextureCoords[0][face.mIndices[j]];
        memcpy(uvArray,&uv,sizeof(float)*2);
        uvArray+=2;

        aiVector3D normal = mesh->mNormals[face.mIndices[j]];
        memcpy(normalArray,&normal,sizeof(float)*3);
        normalArray+=3;

        aiVector3D pos = mesh->mVertices[face.mIndices[j]];
        memcpy(vertexArray,&pos,sizeof(float)*3);
        vertexArray+=3;
    }
}

uvArray-=mesh->mNumFaces*3*2;
normalArray-=mesh->mNumFaces*3*3;
vertexArray-=mesh->mNumFaces*3*3;

[링크 : https://nickthecoder.wordpress.com/2013/01/20/mesh-loading-with-assimp/]

    [링크 : https://stackoverflow.com/questions/35111681/make-a-model-in-blender-and-load-in-opengl]



'Programming > openGL' 카테고리의 다른 글

openGL 스터디용 gemini 생성 코드  (0) 2025.07.16
opengl glortho gluperspective  (0) 2023.08.28
glReadPixels() 와 glUseProgram()  (0) 2022.11.17
openCV + openGL  (0) 2022.02.08
glMatrixMode()  (0) 2020.04.14
Posted by 구차니
Programming/openGL2023. 8. 28. 19:28

orthogonal(직교)

perspective(원근)



-1.0 ~ 1.0 사이로 정규화 해야 한다는데, 그래서 이전에 막 잘리고 난리였던 듯..

[링크 : https://www.scratchapixel.com/lessons/3d-basic-rendering/perspective-and-orthographic-projection-matrix/orthographic-projection-matrix.html]

[링크 : https://heinleinsgame.tistory.com/m/11]



'Programming > openGL' 카테고리의 다른 글

openGL 스터디용 gemini 생성 코드  (0) 2025.07.16
blender in openGL  (0) 2025.04.28
glReadPixels() 와 glUseProgram()  (0) 2022.11.17
openCV + openGL  (0) 2022.02.08
glMatrixMode()  (0) 2020.04.14
Posted by 구차니
Programming/openGL2022. 11. 17. 17:49

wayland / weston 에서 glReadPixels를 통해 읽어 오는게 실패해서 찾아보니

glUserProgram()을 하면 된다는데.. 문제는 어떤 컨텍스트의 정보를 어떻게 받아오냐 일 듯..



glPixelStorei(GL_PACK_ALIGNMENT, 1);
glReadPixels(0, 0, output->width, output->height, GL_RGBA, GL_UNSIGNED_BYTE, data);

[링크 : https://github.com/ereslibre/wayland/blob/master/compositor/screenshooter.c]



It's an error to call anything but a very limited set of functions between glBegin and glEnd. That list is mostly composed of functions related to specifying attributes of a vertex (e.g., glVertex, glNormal, glColor, glTexCoord, etc.).

So, if your OpenGL implementation is following the OpenGL specification, glReadPixels should return immediately without executing because of being called within a glBegin/glEnd group. Remove those from around your calls, and glReadPixels should work as expected.

[링크 : https://stackoverflow.com/questions/19351568/glreadpixels-doesnt-work]



I figured it out. All I had to do was add glUseProgram(0) at the very end of the draw cylinder function. After more than 3 weeks of looking into this.

[링크 : https://computergraphics.stackexchange.com/questions/8354/why-is-glreadpixels-only-working-in-certain-cases]



glUseProgram — Installs a program object as part of current rendering state

[링크 : https://registry.khronos.org/OpenGL-Refpages/gl4/html/glUseProgram.xhtml]

[링크 : https://stackoverflow.com/questions/13546461/what-does-gluseprogram0-do]

'Programming > openGL' 카테고리의 다른 글

blender in openGL  (0) 2025.04.28
opengl glortho gluperspective  (0) 2023.08.28
openCV + openGL  (0) 2022.02.08
glMatrixMode()  (0) 2020.04.14
opengl superbible 3rd 리눅스 빌드 패키지  (0) 2020.04.08
Posted by 구차니
Programming/openGL2022. 2. 8. 12:47

mat 변수가 나오는걸 봐서는 구버전이라.. 요즘꺼에 돌려보려면 조금 고생할 듯.

openGL은 텍스쳐까진 보질 못해서 코드를 이해 못하겠네..



[링크 : https://webnautes.tistory.com/1098]

'Programming > openGL' 카테고리의 다른 글

opengl glortho gluperspective  (0) 2023.08.28
glReadPixels() 와 glUseProgram()  (0) 2022.11.17
glMatrixMode()  (0) 2020.04.14
opengl superbible 3rd 리눅스 빌드 패키지  (0) 2020.04.08
opengl super bible 3rd - 4,5 chapter  (0) 2020.04.06
Posted by 구차니
Programming/openGL2020. 4. 14. 21:49

GL_MODELVIEW와 GL_PROJECTION만 예제로 많이 보았는데

GL_COLOR와 GL_TEXTURE도 가능한 옵션(?)이다.



void glMatrixMode(GLenum mode);

GL_MODELVIEW
Applies subsequent matrix operations to the modelview matrix stack.

GL_PROJECTION
Applies subsequent matrix operations to the projection matrix stack.

GL_TEXTURE
Applies subsequent matrix operations to the texture matrix stack.

GL_COLOR
Applies subsequent matrix operations to the color matrix stack.

[링크 : https://www.khronos.org/registry/OpenGL-Refpages/gl2.1/xhtml/glMatrixMode.xml]

'Programming > openGL' 카테고리의 다른 글

glReadPixels() 와 glUseProgram()  (0) 2022.11.17
openCV + openGL  (0) 2022.02.08
opengl superbible 3rd 리눅스 빌드 패키지  (0) 2020.04.08
opengl super bible 3rd - 4,5 chapter  (0) 2020.04.06
openGL 책 보면서 정리중 - 챕터3  (0) 2020.04.05
Posted by 구차니
Programming/openGL2020. 4. 8. 21:05

2004년 책이라 안될줄 알았는데 다행이 몇개 패키지 설치하니 정상적으로 빌드되도 잘 작동된다.



$ sudo apt-get install libglu1-mesa-dev freeglut3-dev mesa-common-dev
[링크 : http://www.codebind.com/linux-tutorials/install-opengl-ubuntu-linux/]



$ sudo apt-get install libxmu-dev libxi-dev
[링크 : https://ubuntuforums.org/showthread.php?t=1703770]



'Programming > openGL' 카테고리의 다른 글

openCV + openGL  (0) 2022.02.08
glMatrixMode()  (0) 2020.04.14
opengl super bible 3rd - 4,5 chapter  (0) 2020.04.06
openGL 책 보면서 정리중 - 챕터3  (0) 2020.04.05
glEnable(), glPushAttrib()  (0) 2020.04.04
Posted by 구차니
Programming/openGL2020. 4. 6. 21:51

아 정리하기 귀찮다 -ㅁ-

'Programming > openGL' 카테고리의 다른 글

glMatrixMode()  (0) 2020.04.14
opengl superbible 3rd 리눅스 빌드 패키지  (0) 2020.04.08
openGL 책 보면서 정리중 - 챕터3  (0) 2020.04.05
glEnable(), glPushAttrib()  (0) 2020.04.04
openGL superbible 3rd ed. 읽기 시작  (0) 2020.04.03
Posted by 구차니
Programming/openGL2020. 4. 5. 22:11

이건 블로그 보다 위키에 정리 하는게 나으려나?



glBegin(GL_POINTS)

    glPointSize()

    glGetFloatv(GL_POINT_SIZE_RANGE,..)

    glGetFloatv(GL_POINT_SIZE_GRANULARITY,..) // 낱알 모양, 입자의 형상

glEnd()





glBegin(GL_LINES)

    glLineWidth(GLFloat value)

    glGetFloatv(GL_LINE_WIDTH_RANGE,..)

    glGetFloatv(GL_LINE_WIDTH_GRANULARITY,..) // 낱알 모양, 입자의 형상

glEnd()



glBegin(GL_LINE_STRIP)



glBegin(GL_LINE_STIPPLE)

    glLineStipple(GLint factor, GLushort pattern) // factor : 픽셀 단위 길이, pattern : 선의 형상

glEnd()



glBegin(GL_LINE_LOOP)





삼각형

glEnable(GL_CULL_FACE)

glDisable(GL_CULL_FACE)

glShadeModel(GL_FLAT) // GL_SMOOTH

glBegin(GL_TRIANGLES)

glBegin(GL_TRIANGLE_STRIP)

glBegin(GL_TRIANGLE_FAN)

    glFrontFace(GL_CW)

    glFrontFace(GL_CCW)

glEnd()



glEnable(GL_DEPTH_TEST)

    glDepthMask(GL_FALSE) // GL_TRUE

    glClearDepth(GLclampd value)



stipple (점묘법)

1bit color bitmap으로 선에 패턴을 그리거나 폴리곤에 32x32 사이즈의 패턴을 입힐 수 있으나

텍스쳐와는 다르게 rotate 되지 않는 특성을 지님(반대로 생각하면 선에 패턴을 그어 두면 줌 배율 상관없이 선 크기가 고정된다?)



scissor

win32api에서 갱신영역 지정해서 cpu 조금 먹게 하는 것과 비슷한 기법

직사각형 식으로 x,y,w,h 로만 지정이 가능



stencil

스텐실 마스크를 통해서 원하는 위치만을 렌더링 할 수 있다고 하는데 좀 많이 복잡함

glutInitDisplayMode(GLUT_STENCIL)

glEnable(GL_STENCIL_TEST)

glStencilFunc()

glClear(GL_STENCIL_BUFFER_BIT)

glClearStencil(GLint s)

glStencilOp(fail, z-fail, z-succes)

/*

GL_KEEP - 보존

GL_ZERO - 0으로

GL_REPLACE - glStencilFunc() 지정값으로 대체

GL_INCR - 증가

GL_DECR - 감소

GL_INVERT - 반전

GL_INCR_WRAP - 조건에 의해 증가

GL_DECR_WRAP - 조건에 의해 감소

*/

Posted by 구차니
Programming/openGL2020. 4. 4. 10:15

두 함수가 다루는 내용이 비슷한 느낌이라 일단 스크랩



glEnable()은 GL_FOG 이런걸 쓰다면

glPushAttrib()는 GL_FOG_BIT 이런걸 쓴다. 접미가 다른게 붙는걸 보니

다른 enum을 쓰는 함수이긴 한데 내부 구조가 어떻게 짜여있는지가 궁금해지는 함수



[링크 : https://www.khronos.org/registry/OpenGL-Refpages/gl2.1/xhtml/glEnable.xml]

[링크 : https://www.khronos.org/registry/OpenGL-Refpages/gl2.1/xhtml/glPushAttrib.xml]

Posted by 구차니
