Programming/rust2023. 5. 25. 12:46

rust에 추가된 개념으로 변수의 소유권 이라는 것이 있다.

좀 더 봐야 하지만, stack에 저장되는 경우에는 적용이 되지 않고 heap에 저장되는 변수들에 대해서 적용 될 것으로 예상된다.

변수 타입중 primitive와는 연관이 없을 것 같긴하다.

[링크 : https://doc.rust-lang.org/book/ch03-02-data-types.html]



소유자는 하나이다. 이게 포인트

Ownership Rules
First, let’s take a look at the ownership rules. Keep these rules in mind as we work through the examples that illustrate them:

Each value in Rust has an owner.
There can only be one owner at a time.
When the owner goes out of scope, the value will be dropped.



primitive 타입이라 그런건지 아니면 heap이 아닌 stack에 생성되는 변수이기 때문인진 좀 더 봐야 하지만

x = 5; y = x;의 경우에는 5의 소유권이 x에 있지만 y = x를 통해 x가 지닌 5의 소유권이 y에게로 가는 것으로 보이진 않는다.

Variables and Data Interacting with Move
Multiple variables can interact with the same data in different ways in Rust. Let’s look at an example using an integer in Listing 4-2.

    let x = 5;
    let y = x;
Listing 4-2: Assigning the integer value of variable x to y

We can probably guess what this is doing: “bind the value 5 to x; then make a copy of the value in x and bind it to y.” We now have two variables, x and y, and both equal 5. This is indeed what is happening, because integers are simple values with a known, fixed size, and these two 5 values are pushed onto the stack.

Now let’s look at the String version:

    let s1 = String::from("hello");
    let s2 = s1;
This looks very similar, so we might assume that the way it works would be the same: that is, the second line would make a copy of the value in s1 and bind it to s2. But this isn’t quite what happens.



간단(?)하게 생각하면 중괄호 끝날때가 scope의 끝이고

(사용자에게 보이진 않지만) 그때 마다 drop 함수가 호출되고 메모리 관리가 수행되는 것으로 생각된다.

그리고 이 때 소유권에 따라 사용되지 않는 변수는 사라지게 된다.

There is a natural point at which we can return the memory our String needs to the allocator: when s goes out of scope. When a variable goes out of scope, Rust calls a special function for us. This function is called drop, and it’s where the author of String can put the code to return the memory. Rust calls drop automatically at the closing curly bracket.

Note: In C++, this pattern of deallocating resources at the end of an item’s lifetime is sometimes called Resource Acquisition Is Initialization (RAII). The drop function in Rust will be familiar to you if you’ve used RAII patterns.



간단하게 생각하면... 메모리 포인터에 대해서 언어 레벨에서 관리하여

동일 포인터를 포인터 변수에 저장할 수 없도록 관리 하는 것이 소유권이라고 봐도 무방할 것 같다.

Earlier, we said that when a variable goes out of scope, Rust automatically calls the drop function and cleans up the heap memory for that variable. But Figure 4-2 shows both data pointers pointing to the same location. This is a problem: when s2 and s1 go out of scope, they will both try to free the same memory. This is known as a double free error and is one of the memory safety bugs we mentioned previously. Freeing memory twice can lead to memory corruption, which can potentially lead to security vulnerabilities.

To ensure memory safety, after the line let s2 = s1;, Rust considers s1 as no longer valid. Therefore, Rust doesn’t need to free anything when s1 goes out of scope. Check out what happens when you try to use s1 after s2 is created; it won’t work:

This code does not compile!
    let s1 = String::from("hello");
    let s2 = s1;

    println!("{}, world!", s1);
You’ll get an error like this because Rust prevents you from using the invalidated reference:

$ cargo run
   Compiling ownership v0.1.0 (file:///projects/ownership)
error[E0382]: borrow of moved value: `s1`
 --> src/main.rs:5:28
  |
2 |     let s1 = String::from("hello");
  |         -- move occurs because `s1` has type `String`, which does not implement the `Copy` trait
3 |     let s2 = s1;
  |              -- value moved here
4 |
5 |     println!("{}, world!", s1);
  |                            ^^ value borrowed here after move
  |
  = note: this error originates in the macro `$crate::format_args_nl` which comes from the expansion of the macro `println` (in Nightly builds, run with -Z macro-backtrace for more info)
help: consider cloning the value if the performance cost is acceptable
  |
3 |     let s2 = s1.clone();
  |                ++++++++

For more information about this error, try `rustc --explain E0382`.
error: could not compile `ownership` due to previous error
If you’ve heard the terms shallow copy and deep copy while working with other languages, the concept of copying the pointer, length, and capacity without copying the data probably sounds like making a shallow copy. But because Rust also invalidates the first variable, instead of being called a shallow copy, it’s known as a move. In this example, we would say that s1 was moved into s2. So, what actually happens is shown in Figure 4-4.

[링크 : https://doc.rust-lang.org/book/ch04-01-what-is-ownership.html]



+

단일 소유자면 어떻게 공유를 해? 했는데 검색해보니 다행히(!)

멀티 쓰레드 환경에서의 다중 소유권 내용이 존재한다.

다만 Rc는 thread safe하지 않으니 arc를 쓰란다.

Multiple Ownership with Multiple Threads
In Chapter 15, we gave a value multiple owners by using the smart pointer Rc<T> to create a reference counted value. Let’s do the same here and see what happens. We’ll wrap the Mutex<T> in Rc<T> in Listing 16-14 and clone the Rc<T> before moving ownership to the thread.
Filename: src/main.rs

This code does not compile!
use std::rc::Rc;
use std::sync::Mutex;
use std::thread;

fn main() {
    let counter = Rc::new(Mutex::new(0));
    let mut handles = vec![];

    for _ in 0..10 {
        let counter = Rc::clone(&counter);
        let handle = thread::spawn(move || {
            let mut num = counter.lock().unwrap();

            *num += 1;
        });
        handles.push(handle);
    }

    for handle in handles {
        handle.join().unwrap();
    }

    println!("Result: {}", *counter.lock().unwrap());
}
Listing 16-14: Attempting to use Rc<T> to allow multiple threads to own the Mutex<T>

Once again, we compile and get... different errors! The compiler is teaching us a lot.

$ cargo run
   Compiling shared-state v0.1.0 (file:///projects/shared-state)
error[E0277]: `Rc<Mutex<i32>>` cannot be sent between threads safely
  --> src/main.rs:11:36
   |
11 |           let handle = thread::spawn(move || {
   |                        ------------- ^------
   |                        |             |
   |  ______________________|_____________within this `[closure@src/main.rs:11:36: 11:43]`
   | |                      |
   | |                      required by a bound introduced by this call
12 | |             let mut num = counter.lock().unwrap();
13 | |
14 | |             *num += 1;
15 | |         });
   | |_________^ `Rc<Mutex<i32>>` cannot be sent between threads safely
   |
   = help: within `[closure@src/main.rs:11:36: 11:43]`, the trait `Send` is not implemented for `Rc<Mutex<i32>>`
note: required because it's used within this closure
  --> src/main.rs:11:36
   |
11 |         let handle = thread::spawn(move || {
   |                                    ^^^^^^^
note: required by a bound in `spawn`
  --> /rustc/d5a82bbd26e1ad8b7401f6a718a9c57c96905483/library/std/src/thread/mod.rs:704:8
   |
   = note: required by this bound in `spawn`

For more information about this error, try `rustc --explain E0277`.
error: could not compile `shared-state` due to previous error

Wow, that error message is very wordy! Here’s the important part to focus on: `Rc<Mutex<i32>>` cannot be sent between threads safely. The compiler is also telling us the reason why: the trait `Send` is not implemented for `Rc<Mutex<i32>>` . We’ll talk about Send in the next section: it’s one of the traits that ensures the types we use with threads are meant for use in concurrent situations.

Unfortunately, Rc<T> is not safe to share across threads. When Rc<T> manages the reference count, it adds to the count for each call to clone and subtracts from the count when each clone is dropped. But it doesn’t use any concurrency primitives to make sure that changes to the count can’t be interrupted by another thread. This could lead to wrong counts—subtle bugs that could in turn lead to memory leaks or a value being dropped before we’re done with it. What we need is a type exactly like Rc<T> but one that makes changes to the reference count in a thread-safe way.

Atomic Reference Counting with Arc<T>
Fortunately, Arc<T> is a type like Rc<T> that is safe to use in concurrent situations. The a stands for atomic, meaning it’s an atomically reference counted type. Atomics are an additional kind of concurrency primitive that we won’t cover in detail here: see the standard library documentation for std::sync::atomic for more details. At this point, you just need to know that atomics work like primitive types but are safe to share across threads.

You might then wonder why all primitive types aren’t atomic and why standard library types aren’t implemented to use Arc<T> by default. The reason is that thread safety comes with a performance penalty that you only want to pay when you really need to. If you’re just performing operations on values within a single thread, your code can run faster if it doesn’t have to enforce the guarantees atomics provide.

Let’s return to our example: Arc<T> and Rc<T> have the same API, so we fix our program by changing the use line, the call to new, and the call to clone. The code in Listing 16-15 will finally compile and run:

Filename: src/main.rs

use std::sync::{Arc, Mutex};
use std::thread;

fn main() {
    let counter = Arc::new(Mutex::new(0));
    let mut handles = vec![];

    for _ in 0..10 {
        let counter = Arc::clone(&counter);
        let handle = thread::spawn(move || {
            let mut num = counter.lock().unwrap();

            *num += 1;
        });
        handles.push(handle);
    }

    for handle in handles {
        handle.join().unwrap();
    }

    println!("Result: {}", *counter.lock().unwrap());
}
Listing 16-15: Using an Arc<T> to wrap the Mutex<T> to be able to share ownership across multiple threads

This code will print the following:

Result: 10
We did it! We counted from 0 to 10, which may not seem very impressive, but it did teach us a lot about Mutex<T> and thread safety. You could also use this program’s structure to do more complicated operations than just incrementing a counter. Using this strategy, you can divide a calculation into independent parts, split those parts across threads, and then use a Mutex<T> to have each thread update the final result with its part.

Note that if you are doing simple numerical operations, there are types simpler than Mutex<T> types provided by the std::sync::atomic module of the standard library. These types provide safe, concurrent, atomic access to primitive types. We chose to use Mutex<T> with a primitive type for this example so we could concentrate on how Mutex<T> works.

[링크 : https://doc.rust-lang.org/book/ch16-03-shared-state.html]



스마트 포인터 하니 왜 cpp가 떠오르냐..(안봤음!)

아무튼 말 장난같은데

"소유권과 빌리는 컨셉에서 레퍼런스와 스마트 포인터 사이에는 추가적인 차이점이 있다." 라는 표현이 존재한다.

소유자가 1개가 원칙이나 스마트 포인터를 통해 소유자가 1 이상일 수 도 있다로 확장이 되려나?

Smart Pointers
A pointer is a general concept for a variable that contains an address in memory. This address refers to, or “points at,” some other data. The most common kind of pointer in Rust is a reference, which you learned about in Chapter 4. References are indicated by the & symbol and borrow the value they point to. They don’t have any special capabilities other than referring to data, and have no overhead.

Smart pointers, on the other hand, are data structures that act like a pointer but also have additional metadata and capabilities. The concept of smart pointers isn’t unique to Rust: smart pointers originated in C++ and exist in other languages as well. Rust has a variety of smart pointers defined in the standard library that provide functionality beyond that provided by references. To explore the general concept, we’ll look at a couple of different examples of smart pointers, including a reference counting smart pointer type. This pointer enables you to allow data to have multiple owners by keeping track of the number of owners and, when no owners remain, cleaning up the data.

Rust, with its concept of ownership and borrowing, has an additional difference between references and smart pointers: while references only borrow data, in many cases, smart pointers own the data they point to.

Though we didn’t call them as such at the time, we’ve already encountered a few smart pointers in this book, including String and Vec<T> in Chapter 8. Both these types count as smart pointers because they own some memory and allow you to manipulate it. They also have metadata and extra capabilities or guarantees. String, for example, stores its capacity as metadata and has the extra ability to ensure its data will always be valid UTF-8.

[링크 : https://doc.rust-lang.org/book/ch15-00-smart-pointers.html]

'Programming > rust' 카테고리의 다른 글

rust mut  (0) 2023.05.25
rust visibility and privacy  (0) 2023.05.25
rust was  (0) 2023.05.20
c에서 rust 호출하기  (0) 2023.05.11
rust 실행파일  (0) 2023.05.11
Posted by 구차니

아래 명령은 openfoam221 쉘안에서 하니 되긴한데

openfoam2212:~/src/OpenFOAMTeaching/JozsefNagy/
minimonk$ fluentMeshToFoam elbow_tri.msh
/*---------------------------------------------------------------------------*\
| =========                 |                                                 |
| \\      /  F ield         | OpenFOAM: The Open Source CFD Toolbox           |
|  \\    /   O peration     | Version:  2212                                  |
|   \\  /    A nd           | Website:  www.openfoam.com |
|    \\/     M anipulation  |                                                 |
\*---------------------------------------------------------------------------*/
Build  : _f8e05934-20230403 OPENFOAM=2212 patch=230110 version=2212
Arch   : "LSB;label=32;scalar=64"
Exec   : fluentMeshToFoam elbow_tri.msh
Date   : May 24 2023
Time   : 16:38:06
Host   : mini2760p
PID    : 23712
I/O    : uncollated
Case   : /home/minimonk/src/OpenFOAMTeaching/JozsefNagy
nProcs : 1
trapFpe: Floating point exception trapping enabled (FOAM_SIGFPE).
fileModificationChecking : Monitoring run-time modified files using timeStampMaster (fileModificationSkew 5, maxFileModificationPolls 20)
allowSystemOperations : Allowing user-supplied system call operations

// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
Create time



--> FOAM FATAL ERROR: (openfoam-2212 patch=230110)
cannot find file "/home/minimonk/src/OpenFOAMTeaching/JozsefNagy/system/controlDict"

    From virtual Foam::autoPtr<Foam::ISstream> Foam::fileOperations::uncollatedFileOperation::readStream(Foam::regIOobject&, const Foam::fileName&, const Foam::word&, bool) const
    in file global/fileOperations/uncollatedFileOperation/uncollatedFileOperation.C at line 561.

FOAM exiting

openfoam2212:~/src/OpenFOAMTeaching/JozsefNagy/
minimonk$

[링크 : https://youtu.be/KznljrgWSvo?t=1129]

[링크 : https://www.youtube.com/watch?v=KznljrgWSvo]

[링크 : https://openfoamwiki.net/index.php/Fluent3DMeshToFoam]

[링크 : https://github.com/jnmlujnmlu/OpenFOAMTeaching/tree/master/JozsefNagy]





$ openfoam
openfoam = /usr/lib/openfoam/openfoam2212

 * Using:     OpenFOAM-v2212 (2212) - visit www.openfoam.com
 * Build:     _f8e05934-20230403 (patch=230110)
 * Arch:      label=32;scalar=64
 * Platform:  linux64GccDPInt32Opt (mpi=sys-openmpi)

OpenFOAM shell session - use 'exit' to quit

openfoam2212:~/src/tutorials/incompressible/icoFoam/elbow_tri/
minimonk$ fluentMeshToFoam elbow_tri.msh
/*---------------------------------------------------------------------------*\
| =========                 |                                                 |
| \\      /  F ield         | OpenFOAM: The Open Source CFD Toolbox           |
|  \\    /   O peration     | Version:  2212                                  |
|   \\  /    A nd           | Website:  www.openfoam.com |
|    \\/     M anipulation  |                                                 |
\*---------------------------------------------------------------------------*/
Build  : _f8e05934-20230403 OPENFOAM=2212 patch=230110 version=2212
Arch   : "LSB;label=32;scalar=64"
Exec   : fluentMeshToFoam elbow_tri.msh
Date   : May 24 2023
Time   : 17:15:20
Host   : mini2760p
PID    : 24479
I/O    : uncollated
Case   : /home/minimonk/src/tutorials/incompressible/icoFoam/elbow_tri
nProcs : 1
trapFpe: Floating point exception trapping enabled (FOAM_SIGFPE).
fileModificationChecking : Monitoring run-time modified files using timeStampMaster (fileModificationSkew 5, maxFileModificationPolls 20)
allowSystemOperations : Allowing user-supplied system call operations

// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
Create time

Reading header: "TGrid 2D 2.4.1"
Reading header: "PreBFC V4.3"
Dimension of grid: 2
Embedded blocks in comment or unknown: (
Embedded blocks in comment or unknown:(
Found end of section in unknown:)
Embedded blocks in comment or unknown:(
Found end of section in unknown:)
Found end of section in unknown:)
Embedded blocks in comment or unknown: (
Embedded blocks in comment or unknown:(
Found end of section in unknown:)
Embedded blocks in comment or unknown:
(
Found end of section in unknown:)
Found end of section in unknown:)
Embedded blocks in comment or unknown: (
Embedded blocks in comment or unknown:(
Found end of section in unknown:)
Found end of section in unknown:)
Number of points: 537

number of faces: 1454
Number of cells: 918
Reading points
Reading points
Reading uniform faces
Reading uniform faces
Reading uniform faces
Reading uniform faces
Reading uniform faces
Reading uniform faces
Tgrid syntax problem: 9 1 396 1
cellGroupZoneID:9
cellGroupStartIndex:1
cellGroupEndIndex:918
cellGroupType:1
Read zone1:3 name:internal-3 patchTypeID:interior
Reading zone data
Read zone1:4 name:wall-4 patchTypeID:wall
Reading zone data
Read zone1:5 name:velocity-inlet-5 patchTypeID:velocity-inlet
Reading zone data
Read zone1:6 name:velocity-inlet-6 patchTypeID:velocity-inlet
Reading zone data
Read zone1:7 name:pressure-outlet-7 patchTypeID:pressure-outlet
Reading zone data
Read zone1:8 name:wall-8 patchTypeID:wall
Reading zone data
Read zone1:9 name:fluid-9 patchTypeID:fluid
Reading zone data


FINISHED LEXING


dimension of grid: 2
Grid is 2-D. Extruding in z-direction by: 1.87548
Creating shapes for 2-D cells
Building patch-less mesh...--> FOAM Warning :
    From Foam::polyMesh::polyMesh(const Foam::IOobject&, Foam::pointField&&, const cellShapeList&, const faceListList&, const wordList&, const wordList&, const Foam::word&, const Foam::word&, const wordList&, bool)
    in file meshes/polyMesh/polyMeshFromShapeMesh.C at line 645
    Found 1990 undefined faces in mesh; adding to default patch defaultFaces
done.

Building boundary and internal patches.
Creating patch 0 for zone: 3 start: 155 end: 1454 type: interior name: internal-3
Creating patch 1 for zone: 4 start: 55 end: 154 type: wall name: wall-4
Creating patch 2 for zone: 5 start: 47 end: 54 type: velocity-inlet name: velocity-inlet-5
Creating patch 3 for zone: 6 start: 43 end: 46 type: velocity-inlet name: velocity-inlet-6
Creating patch 4 for zone: 7 start: 35 end: 42 type: pressure-outlet name: pressure-outlet-7
Creating patch 5 for zone: 8 start: 1 end: 34 type: wall name: wall-8
Creating patch for front and back planes

Patch internal-3 is internal to the mesh  and is not being added to the boundary.
Adding new patch wall-4 of type wall as patch 0
Adding new patch velocity-inlet-5 of type patch as patch 1
Adding new patch velocity-inlet-6 of type patch as patch 2
Adding new patch pressure-outlet-7 of type patch as patch 3
Adding new patch wall-8 of type wall as patch 4
Adding new patch frontAndBackPlanes of type empty as patch 5

Writing mesh... to "constant/polyMesh"  done.


End

openfoam2212:~/src/tutorials/incompressible/icoFoam/elbow_tri/

minimonk$ tree
.
├── 0
│   ├── U
│   └── p
├── 0.orig
│   ├── U
│   └── p
├── Allclean
├── Allrun
├── constant
│   ├── polyMesh
│   │   ├── boundary
│   │   ├── cellZones
│   │   ├── faceZones
│   │   ├── faces
│   │   ├── neighbour
│   │   ├── owner
│   │   ├── pointZones
│   │   └── points
│   ├── transportProperties
│   └── transportProperties.bak
├── elbow_quad.msh
├── elbow_tri.msh
└── system
    ├── controlDict
    ├── foamDataToFluentDict
    ├── fvSchemes
    └── fvSolution

5 directories, 22 files
openfoam2212:~/src/tutorials/incompressible/icoFoam/elbow_tri/

minimonk$ ico
ico                                 icoReactingMultiphaseInterFoam      icoUncoupledKinematicParcelFoam     iconv
icoFoam                             icoUncoupledKinematicParcelDyMFoam  icontopbm                           iconvconfig
openfoam2212:~/src/tutorials/incompressible/icoFoam/elbow_tri/
minimonk$ icoFoam
/*---------------------------------------------------------------------------*\
| =========                 |                                                 |
| \\      /  F ield         | OpenFOAM: The Open Source CFD Toolbox           |
|  \\    /   O peration     | Version:  2212                                  |
|   \\  /    A nd           | Website:  www.openfoam.com |
|    \\/     M anipulation  |                                                 |
\*---------------------------------------------------------------------------*/
Build  : _f8e05934-20230403 OPENFOAM=2212 patch=230110 version=2212
Arch   : "LSB;label=32;scalar=64"
Exec   : icoFoam
Date   : May 24 2023
Time   : 17:19:48
Host   : mini2760p
PID    : 24543
I/O    : uncollated
Case   : /home/minimonk/src/tutorials/incompressible/icoFoam/elbow_tri
nProcs : 1
trapFpe: Floating point exception trapping enabled (FOAM_SIGFPE).
fileModificationChecking : Monitoring run-time modified files using timeStampMaster (fileModificationSkew 5, maxFileModificationPolls 20)
allowSystemOperations : Allowing user-supplied system call operations

// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
Create time

Create mesh for time = 0


PISO: Operating solver in PISO mode

Reading transportProperties

Reading field p

Reading field U

Reading/calculating face flux field phi


Starting time loop

Time = 0.05

Courant Number mean: 0.000415941 max: 0.173205
smoothSolver:  Solving for Ux, Initial residual = 1, Final residual = 2.59879e-07, No Iterations 1
smoothSolver:  Solving for Uy, Initial residual = 1, Final residual = 2.7558e-06, No Iterations 1
DICPCG:  Solving for p, Initial residual = 1, Final residual = 0.036127, No Iterations 62
DICPCG:  Solving for p, Initial residual = 0.0964781, Final residual = 0.00388218, No Iterations 3
DICPCG:  Solving for p, Initial residual = 0.00947597, Final residual = 0.000467612, No Iterations 44
time step continuity errors : sum local = 7.42259e-05, global = 1.62183e-06, cumulative = 1.62183e-06
DICPCG:  Solving for p, Initial residual = 0.00302872, Final residual = 0.000137611, No Iterations 9
DICPCG:  Solving for p, Initial residual = 0.00040051, Final residual = 1.89259e-05, No Iterations 11
DICPCG:  Solving for p, Initial residual = 7.55534e-05, Final residual = 7.72999e-07, No Iterations 55
time step continuity errors : sum local = 1.18435e-07, global = 2.9852e-09, cumulative = 1.62482e-06
ExecutionTime = 0.01 s  ClockTime = 0 s

Time = 0.1

Courant Number mean: 0.0788444 max: 0.397028
smoothSolver:  Solving for Ux, Initial residual = 0.41777, Final residual = 1.43339e-06, No Iterations 2
smoothSolver:  Solving for Uy, Initial residual = 0.415998, Final residual = 7.16337e-06, No Iterations 2
DICPCG:  Solving for p, Initial residual = 0.0174141, Final residual = 0.000701295, No Iterations 60
DICPCG:  Solving for p, Initial residual = 0.503317, Final residual = 0.0203323, No Iterations 3
DICPCG:  Solving for p, Initial residual = 0.0837591, Final residual = 0.00367981, No Iterations 45
time step continuity errors : sum local = 6.59525e-05, global = -1.04379e-06, cumulative = 5.81027e-07
DICPCG:  Solving for p, Initial residual = 0.104572, Final residual = 0.00332569, No Iterations 58
DICPCG:  Solving for p, Initial residual = 0.257662, Final residual = 0.0119158, No Iterations 6
DICPCG:  Solving for p, Initial residual = 0.0349453, Final residual = 6.69377e-07, No Iterations 73
time step continuity errors : sum local = 1.96408e-09, global = -3.1581e-11, cumulative = 5.80996e-07
ExecutionTime = 0.02 s  ClockTime = 0 s

...

Time = 74.95

Courant Number mean: 0.0810354 max: 0.50158
smoothSolver:  Solving for Ux, Initial residual = 1.22107e-05, Final residual = 3.41265e-08, No Iterations 1
smoothSolver:  Solving for Uy, Initial residual = 9.0529e-06, Final residual = 9.0529e-06, No Iterations 0
DICPCG:  Solving for p, Initial residual = 0.000279752, Final residual = 1.15931e-05, No Iterations 5
DICPCG:  Solving for p, Initial residual = 4.33362e-05, Final residual = 1.84484e-06, No Iterations 20
DICPCG:  Solving for p, Initial residual = 1.21591e-05, Final residual = 9.52858e-07, No Iterations 6
time step continuity errors : sum local = 2.40141e-10, global = 4.53557e-11, cumulative = 5.99696e-07
DICPCG:  Solving for p, Initial residual = 9.88006e-05, Final residual = 4.91478e-06, No Iterations 4
DICPCG:  Solving for p, Initial residual = 1.34255e-05, Final residual = 9.18873e-07, No Iterations 18
DICPCG:  Solving for p, Initial residual = 5.38886e-06, Final residual = 9.52181e-07, No Iterations 1
time step continuity errors : sum local = 2.39966e-10, global = -3.02947e-12, cumulative = 5.99693e-07
ExecutionTime = 6.25 s  ClockTime = 7 s

Time = 75

Courant Number mean: 0.0810354 max: 0.501578
smoothSolver:  Solving for Ux, Initial residual = 1.29443e-05, Final residual = 3.26777e-08, No Iterations 1
smoothSolver:  Solving for Uy, Initial residual = 8.86138e-06, Final residual = 8.86138e-06, No Iterations 0
DICPCG:  Solving for p, Initial residual = 0.000425003, Final residual = 1.9758e-05, No Iterations 3
DICPCG:  Solving for p, Initial residual = 3.72637e-05, Final residual = 1.5002e-06, No Iterations 47
DICPCG:  Solving for p, Initial residual = 1.25032e-05, Final residual = 9.53705e-07, No Iterations 4
time step continuity errors : sum local = 2.40409e-10, global = -2.83052e-12, cumulative = 5.9969e-07
DICPCG:  Solving for p, Initial residual = 8.65794e-05, Final residual = 4.13674e-06, No Iterations 8
DICPCG:  Solving for p, Initial residual = 1.40349e-05, Final residual = 8.71206e-07, No Iterations 15
DICPCG:  Solving for p, Initial residual = 4.26225e-06, Final residual = 7.88447e-07, No Iterations 1
time step continuity errors : sum local = 1.98748e-10, global = -4.50203e-11, cumulative = 5.99645e-07
ExecutionTime = 6.26 s  ClockTime = 7 s

End

openfoam2212:~/src/tutorials/incompressible/icoFoam/elbow_tri/
minimonk$



여기는 연산하는 거고

이제 보는건  paraview를 쓰면 된다.

1. 좌측 상단의 폴더 눌러서 파일 열기



2. elbow_tri/system 디렉토리에서 파일을 모든 유형으로 선택하고 controlDict를 연다.



3. OpenFoam 유형으로 연다.



4. apply를 누른다.

(처음 열어 보면 그냥 wireframe만 나오는데, icoFoam 까지 하고 나서 다시 열면 색상이 보인다)



5. 상단에 U로 바꾸어 주고 재생 버튼을 누르면 75초간 시뮬레이션 한 결과가 재생된다.



오.. 신기해라(영혼 없음)

'프로그램 사용 > openFOAM' 카테고리의 다른 글

mpirun illegal instruction  (0) 2023.09.01
openFOAM + freecad + salome  (0) 2023.06.07
openfoam on ubuntu  (0) 2023.05.24
openFOAM tutorial  (4) 2023.05.24
openfoam7 on ubuntu 18.04  (0) 2020.08.09
Posted by 구차니
Programming/golang2023. 5. 24. 16:10

고루틴이 종료되는 시점을 확인하는 방법으로 보면 되려나?



여러개의 고루틴을 종료할때 까지 기다리기 위해  wait gorup을 이용할 수 있다.

package main

import (
    "fmt"
    "sync"
    "time"
)

func worker(id int) {
    fmt.Printf("Worker %d starting\n", id)

    time.Sleep(time.Second)
    fmt.Printf("Worker %d done\n", id)
}

func main() {

    var wg sync.WaitGroup

    for i := 1; i <= 5; i++ {
        wg.Add(1)

        i := i

        go func() {
            defer wg.Done()
            worker(i)
        }()
    }

    wg.Wait()

}

[링크 : https://gobyexample.com/waitgroups]

[링크 : https://pyrasis.com/book/GoForTheReallyImpatient/Unit35/06]

[링크 : https://pkg.go.dev/sync#WaitGroup.Add]

'Programming > golang' 카테고리의 다른 글

golang echo 서버 이상한 버그 발견?  (0) 2023.06.27
go ws server client example  (0) 2023.06.08
golang echo server middleware  (0) 2023.05.24
golang 동시성  (0) 2023.05.24
golang 고루틴과 채널  (0) 2023.05.16
Posted by 구차니
Programming/golang2023. 5. 24. 15:41

golang의 echo를 이용해서 웹서버 만드는건 쉬운데

서버 돌려 두면 별도의 go routine으로 돌테니 어떻게 구성을 해야

IPC를 통해 받은 변수를 깨지지 않게 처리할 수 있을까?



걍 결론은.. mutex로 귀결인가?

func (s *Stats) Handle(c echo.Context) error {
s.mutex.RLock()
defer s.mutex.RUnlock()
return c.JSON(http.StatusOK, s)
}

func main() {
e := echo.New()

// Debug mode
e.Debug = true

//-------------------
// Custom middleware
//-------------------
// Stats
s := NewStats()
e.Use(s.Process)
e.GET("/stats", s.Handle) // Endpoint to get stats

// Server header
e.Use(ServerHeader)

// Handler
e.GET("/", func(c echo.Context) error {
return c.String(http.StatusOK, "Hello, World!")
})

// Start server
e.Logger.Fatal(e.Start(":1323"))
}

[링크 : https://echo.labstack.com/cookbook/middleware/]

'Programming > golang' 카테고리의 다른 글

go ws server client example  (0) 2023.06.08
golang waitgroup  (0) 2023.05.24
golang 동시성  (0) 2023.05.24
golang 고루틴과 채널  (0) 2023.05.16
golang switch, select  (0) 2023.05.16
Posted by 구차니
Programming/golang2023. 5. 24. 15:38

atomic 패키지는 특정 변수의 값 증가등에 대해서 atomic operation 해주는 것 같고 copy는 없는 것 같고

sync.mutex가 역시 가장 무난한 선택인가 싶다.

channel은 내가 원하는 패키지에서 사용가능한 방법은 아난 것 같군..



atomic > mutex > channel

[링크 : https://woojinger.tistory.com/100]

[링크 : https://dev-yakuza.posstree.com/ko/golang/goroutine/]

[링크 : https://pkg.go.dev/sync/atomic]

'Programming > golang' 카테고리의 다른 글

golang waitgroup  (0) 2023.05.24
golang echo server middleware  (0) 2023.05.24
golang 고루틴과 채널  (0) 2023.05.16
golang switch, select  (0) 2023.05.16
golang uds  (0) 2023.05.16
Posted by 구차니

예전에는 직접 빌드했던것 같은데 이제 빌드된 바이너리도 배포하고 좋아졌네

curl https://dl.openfoam.com/add-debian-repo.sh | sudo bash
sudo apt-get update
sudo apt-get install openfoam2212-default
openfoam2212

[링크 : https://develop.openfoam.com/Development/openfoam/-/wikis/precompiled/debian]



헉.. 용량이..

$ sudo apt-get install openfoam2212-default
패키지 목록을 읽는 중입니다... 완료
의존성 트리를 만드는 중입니다
상태 정보를 읽는 중입니다... 완료
다음의 추가 패키지가 설치될 것입니다 :
  flex gfortran gfortran-7 libcgal-dev libcgal13 libfl-dev libfl2 libgfortran-7-dev libgmp-dev libgmpxx4ldbl libhwloc-dev
  libibverbs-dev libmpfr-dev libnuma-dev libopenmpi-dev libptscotch-6.0 libptscotch-dev libreadline-dev libscotch-6.0 libscotch-dev
  libtinfo-dev mpi-default-bin mpi-default-dev openfoam-selector openfoam2212 openfoam2212-common openfoam2212-dev
  openfoam2212-source openfoam2212-tools openfoam2212-tutorials
제안하는 패키지:
  bison flex-doc gfortran-multilib gfortran-doc gfortran-7-multilib gfortran-7-doc libgfortran4-dbg libcoarrays-dev libmpfi-dev
  libntl-dev gmp-doc libgmp10-doc libmpfr-doc openmpi-doc readline-doc gnuplot
다음 새 패키지를 설치할 것입니다:
  flex gfortran gfortran-7 libcgal-dev libcgal13 libfl-dev libfl2 libgfortran-7-dev libgmp-dev libgmpxx4ldbl libhwloc-dev
  libibverbs-dev libmpfr-dev libnuma-dev libopenmpi-dev libptscotch-6.0 libptscotch-dev libreadline-dev libscotch-6.0 libscotch-dev
  libtinfo-dev mpi-default-bin mpi-default-dev openfoam-selector openfoam2212 openfoam2212-common openfoam2212-default
  openfoam2212-dev openfoam2212-source openfoam2212-tools openfoam2212-tutorials
0개 업그레이드, 31개 새로 설치, 0개 제거 및 0개 업그레이드 안 함.
131 M바이트 아카이브를 받아야 합니다.
이 작업 후 767 M바이트의 디스크 공간을 더 사용하게 됩니다.




흐음.. 멀 어떻게 해야하나 막막하네?

나가는 방법은 exit

$ openfoam2212
openfoam = /usr/lib/openfoam/openfoam2212

 * Using:     OpenFOAM-v2212 (2212) - visit www.openfoam.com
 * Build:     _f8e05934-20230403 (patch=230110)
 * Arch:      label=32;scalar=64
 * Platform:  linux64GccDPInt32Opt (mpi=sys-openmpi)

OpenFOAM shell session - use 'exit' to quit

openfoam2212:~/
minimonk$ help
GNU bash, version 4.4.20(1)-release (x86_64-pc-linux-gnu)
쉘 명령어는 내부적으로 정의되어 있습니다.  'help'를 입력하면 목록이 보입니다.
`name' 함수에 대해 더 많은 것을 알아보려면 `help name' 을 입력하십시오.
일반적인 쉘에 대해서 더 많은 것을 알아보려면 `info bash' 를 사용하십시오.
목록에 없는 명령어에 대해 더 많은 것을 알아보려면 `man -k' 또는 `info'를 사용하십시오.

별표(*)가 옆에 있는 명령어는 사용할 수 없음을 의미합니다.

 job_spec [&]                                                       history [-c] [-d offset] [n] or history -anrw [filename] or his>
 (( expression ))                                                   if COMMANDS; then COMMANDS; [ elif COMMANDS; then COMMANDS; ]..>
 . filename [arguments]                                             jobs [-lnprs] [jobspec ...] or jobs -x command [args]
 :                                                                  kill [-s sigspec | -n signum | -sigspec] pid | jobspec ... or k>
 [ arg... ]                                                         let arg [arg ...]
 [[ expression ]]                                                   local [option] name[=value] ...
 alias [-p] [name[=value] ... ]                                     logout [n]
 bg [job_spec ...]                                                  mapfile [-d delim] [-n count] [-O origin] [-s count] [-t] [-u f>
 bind [-lpsvPSVX] [-m keymap] [-f filename] [-q name] [-u name] [>  popd [-n] [+N | -N]
 break [n]                                                          printf [-v var] format [arguments]
 builtin [shell-builtin [arg ...]]                                  pushd [-n] [+N | -N | dir]
 caller [expr]                                                      pwd [-LP]
 case WORD in [PATTERN [| PATTERN]...) COMMANDS ;;]... esac         read [-ers] [-a array] [-d delim] [-i text] [-n nchars] [-N nch>
 cd [-L|[-P [-e]] [-@]] [dir]                                       readarray [-n count] [-O origin] [-s count] [-t] [-u fd] [-C ca>
 command [-pVv] command [arg ...]                                   readonly [-aAf] [name[=value] ...] or readonly -p
 compgen [-abcdefgjksuv] [-o option] [-A action] [-G globpat] [-W>  return [n]
 complete [-abcdefgjksuv] [-pr] [-DE] [-o option] [-A action] [-G>  select NAME [in WORDS ... ;] do COMMANDS; done
 compopt [-o|+o option] [-DE] [name ...]                            set [-abefhkmnptuvxBCHP] [-o option-name] [--] [arg ...]
 continue [n]                                                       shift [n]
 coproc [NAME] command [redirections]                               shopt [-pqsu] [-o] [optname ...]
 declare [-aAfFgilnrtux] [-p] [name[=value] ...]                    source filename [arguments]
 dirs [-clpv] [+N] [-N]                                             suspend [-f]
 disown [-h] [-ar] [jobspec ... | pid ...]                          test [expr]
 echo [-neE] [arg ...]                                              time [-p] pipeline
 enable [-a] [-dnps] [-f filename] [name ...]                       times
 eval [arg ...]                                                     trap [-lp] [[arg] signal_spec ...]
 exec [-cl] [-a name] [command [arguments ...]] [redirection ...>   true
 exit [n]                                                           type [-afptP] name [name ...]
 export [-fn] [name[=value] ...] or export -p                       typeset [-aAfFgilnrtux] [-p] name[=value] ...
 false                                                              ulimit [-SHabcdefiklmnpqrstuvxPT] [limit]
 fc [-e ename] [-lnr] [first] [last] or fc -s [pat=rep] [command>   umask [-p] [-S] [mode]
 fg [job_spec]                                                      unalias [-a] name [name ...]
 for NAME [in WORDS ... ] ; do COMMANDS; done                       unset [-f] [-v] [-n] [name ...]
 for (( exp1; exp2; exp3 )); do COMMANDS; done                      until COMMANDS; do COMMANDS; done
 function name { COMMANDS ; } or name () { COMMANDS ; }             variables - Names and meanings of some shell variables
 getopts optstring name [arg]                                       wait [-n] [id ...]
 hash [-lr] [-p pathname] [-dt] [name ...]                          while COMMANDS; do COMMANDS; done
 help [-dms] [pattern ...]                                          { COMMANDS ; }
openfoam2212:~/
minimonk$ quit

Command 'quit' not found, but can be installed with:

sudo snap install quit

openfoam2212:~/
minimonk$ exit
exit



'프로그램 사용 > openFOAM' 카테고리의 다른 글

openFOAM + freecad + salome  (0) 2023.06.07
openFOAM tutorial with youtube  (0) 2023.05.24
openFOAM tutorial  (4) 2023.05.24
openfoam7 on ubuntu 18.04  (0) 2020.08.09
openFOAM tutorial  (0) 2020.07.19
Posted by 구차니

한참 시도하다가 실패했던 openFOAM 사용예를 찾아보려는데

chatGPT 시대니까 한번 시도!

실행 예제:
OpenFOAM을 실행해보기 위해 예제 중 하나를 실행해보겠습니다. tutorials 디렉토리에는 다양한 예제가 포함되어 있습니다. 예를 들어, heatTransfer/buoyantSimpleFoam 디렉토리로 이동한 후 다음 명령을 실행하여 해당 예제를 실행합니다.

shell
Copy code
$ cd $FOAM_TUTORIALS/heatTransfer/buoyantSimpleFoam
$ blockMesh  # 메쉬 생성
$ buoyantSimpleFoam  # 시뮬레이션 실행
이 예제는 열전달과 대류 역학을 시뮬레이션하는 것으로, blockMesh로 메쉬를 생성한 후 buoyantSimpleFoam으로 시뮬레이션을 실행합니다. 실행 결과는 해당 디렉토리 내에 저장됩니다.



일단은 heatTransfer / buoyantSimpleFoam

라는 키워드를 얻었으니 이걸 기반으로 역으로 추적해보면..



머.. 검은 건 글씨고 흰건 종이라는 건 변함없다.. -_ㅠ

[링크 : https://www.tfd.chalmers.se/~hani/kurser/OS_CFD_2016/VarunVenkatesh/Varun_report.pdf]

[링크 : https://www.openfoam.com/documentation/guides/latest/doc/guide-applications-solvers-heat-transfer-buoyantSimpleFoam.html]

[링크 : https://cpp.openfoam.org/v4/dir_90706e5b82a3613c0a5b601bc80a6bc4.html]



+

bard에게 물어보니

OpenFOAM 워크벤츠 프로그램을 엽니다 라고 해서 찾아보니..

뜬금없이(?) freecad에 plugin이 튀어나온다.. bard가 나에게 맞말을 해주는게 아닌 느낌?

[링크 : https://wiki.freecad.org/Cfd_Workbench]



+

$ sudo find / -name cavity
/usr/lib/openfoam/openfoam2212/applications/test/mapDistributePolyMesh/cavity
/usr/lib/openfoam/openfoam2212/applications/test/volField/cavity
/usr/lib/openfoam/openfoam2212/tutorials/mesh/parallel/cavity
/usr/lib/openfoam/openfoam2212/tutorials/compressible/rhoPimpleFoam/RAS/cavity
/usr/lib/openfoam/openfoam2212/tutorials/preProcessing/createZeroDirectory/cavity
/usr/lib/openfoam/openfoam2212/tutorials/incompressible/icoFoam/cavity
/usr/lib/openfoam/openfoam2212/tutorials/incompressible/icoFoam/cavity/cavity
/usr/lib/openfoam/openfoam2212/tutorials/incompressible/pisoFoam/RAS/cavity



파일 경로는 찾았는데 실행 방법을 모르겠다 ㅠㅠ

[링크 :https://www.openfoam.com/documentation/tutorial-guide/2-incompressible-flow/2.1-lid-driven-cavity-flow#x6-60002.1]

[링크 : https://www.openfoam.com/documentation/tutorial-guide]



+

paraView 혹은 paraFoam이 먼진 모르겠는데.. 이거 맞나?

$ apt-cache search paraview
libxdmf3 - eXtensible Data Model and Format library
paraview - Parallel Visualization Application
paraview-dev - Parallel Visualization Application. Development header files
paraview-doc - Parallel Visualization Application. Comprehensive documentation
paraview-python - Parallel Visualization Application. python-support
rheolef - efficient Finite Element environment

$ sudo apt-get install paraview
패키지 목록을 읽는 중입니다... 완료
의존성 트리를 만드는 중입니다
상태 정보를 읽는 중입니다... 완료
다음의 추가 패키지가 설치될 것입니다 :
  cython libcgns3.3 libqt4-help libqt5positioning5 libqt5sensors5 libqt5webchannel5 libqt5webkit5 libtcl8.5 libvtk6.3-qt paraview-doc
  paraview-python python-attr python-autobahn python-automat python-cbor python-click python-colorama python-concurrent.futures
  python-constantly python-hyperlink python-incremental python-lz4 python-mpi4py python-nacl python-pam python-pyasn1
  python-pyasn1-modules python-qrcode python-serial python-service-identity python-snappy python-trie python-trollius python-twisted
  python-twisted-bin python-twisted-core python-txaio python-u-msgpack python-ubjson python-vtk6 python-wsaccel python-zope.interface
  tcl8.5
제안하는 패키지:
  cython-doc hdf5-tools h5utils python-attr-doc python-nacl-doc python-pam-dbg python-trie-doc python-twisted-bin-dbg python-glade2
  python-qt3 python-txaio-doc mayavi2 vtk6-doc vtk6-examples tcl-tclreadline
다음 새 패키지를 설치할 것입니다:
  cython libcgns3.3 libqt4-help libqt5positioning5 libqt5sensors5 libqt5webchannel5 libqt5webkit5 libtcl8.5 libvtk6.3-qt paraview
  paraview-doc paraview-python python-attr python-autobahn python-automat python-cbor python-click python-colorama
  python-concurrent.futures python-constantly python-hyperlink python-incremental python-lz4 python-mpi4py python-nacl python-pam
  python-pyasn1 python-pyasn1-modules python-qrcode python-serial python-service-identity python-snappy python-trie python-trollius
  python-twisted python-twisted-bin python-twisted-core python-txaio python-u-msgpack python-ubjson python-vtk6 python-wsaccel
  python-zope.interface tcl8.5
0개 업그레이드, 44개 새로 설치, 0개 제거 및 0개 업그레이드 안 함.
61.2 M바이트 아카이브를 받아야 합니다.
이 작업 후 286 M바이트의 디스크 공간을 더 사용하게 됩니다.
계속 하시겠습니까? [Y/n]

[링크 : https://www.openfoam.com/documentation/user-guide/7-post-processing/7.1-parafoam]

'프로그램 사용 > openFOAM' 카테고리의 다른 글

openFOAM tutorial with youtube  (0) 2023.05.24
openfoam on ubuntu  (0) 2023.05.24
openfoam7 on ubuntu 18.04  (0) 2020.08.09
openFOAM tutorial  (0) 2020.07.19
openFOAM 우분투 패키지  (0) 2020.07.18
Posted by 구차니

이것저것 갑자기 몰리더니

잠시 한가한 중간 틈이 발생



무언가 다른 짓을 해봐야하나?



아무튼 오늘 하나 일차 납품하고 프로그램 테스트는 했으니 별도로 전달해주면 되고

내일 하나 마저 납품하면 어찌 한단락 지어질테니 조금 숨돌릴듯

'개소리 왈왈 > 직딩의 비애' 카테고리의 다른 글

doom eternal 질러?  (0) 2023.07.01
하루가 짧다  (0) 2023.06.29
사설? 다른 길은 안 보이는 ‘코딩 권하는 사회’ 괜찮나?  (0) 2023.05.22
출근  (0) 2023.05.08
우어어 힘들어  (0) 2023.04.25
Posted by 구차니

구글 추천 떠서 보는데, 그냥 웃음만 나온다.

전공자도 절반이상 개발로 벌어먹는 비율이 되지 않는데

비전공자가 고작 몇개월 학원과정 한다고 대기업 취업할 수 있을거라는 뽕을 곧이곧대로 믿은걸까?



직설적으로

현직 프로그래머가 3개월~6개월 과정거쳐서 영어로 베스트셀러 써낼 수 있다고 하면 문과생들도 어이없어서 비웃지 않을까?



아무튼, 시대가 사회가 문제다 라고 치부하기에는

이쪽은 처음부터 지옥이었고, 이미 레드오션일 뿐이니

전공을 포기하고 오겠다는 분들에게  welcome to hell 이라고 해줄 수 밖에..

코딩은 청년에게 남은 위안처이자, 그들이 공정하게 싸울 마지막 무대다. 20대 중반에 들어선 이가 ‘지금까지 걸어온 길이 틀렸다’ ‘지금까지의 공부로는 밥벌이할 수 없다’는 생각이 든다면, 학생과 백수 사이에 놓인 청년이 무엇을 선택할 수 있을까. 한때 공무원시험 준비 학원으로 몰렸던 이들이 이젠 개발자가 되게 해준다는 학원으로 몰려간다. 심지어 국가가 나서서 돈을 쥐여주기도 한다. 더 번듯하고 있어 보인다. 적성에 맞는지 가늠하기엔 이들에게 시간이 없다. 빨리 취업하고, 학자금대출을 갚고, 전셋집이라도 구해서 ‘사람 구실’을 해야 한다. 누가 이들을 탓할 수 있을까. 어쩌면 그 외 다른 길이 보이지 않는, 코딩 권하는 사회가 문제 아닐까.

[링크 : https://v.daum.net/v/20230520004301565]

[링크 : https://h21.hani.co.kr/arti/society/society_general/53878.html]



2019.07.27

[링크 : https://www.teamblind.com/kr/post/IT%EC%97%85%EA%B3%84%EB%A1%9C-%EC%9D%B4%EC%A7%81%ED%95%98%EA%B3%A0%EC%8B%B6%EC%8A%B5%EB%8B%88%EB%8B%A4-1dBT2MnB]

'개소리 왈왈 > 직딩의 비애' 카테고리의 다른 글

하루가 짧다  (0) 2023.06.29
먼가 갑자기 한가해진 느낌?  (2) 2023.05.23
출근  (0) 2023.05.08
우어어 힘들어  (0) 2023.04.25
일이 꼬이려나..  (0) 2023.04.24
Posted by 구차니
개소리 왈왈2023. 5. 22. 19:00

길가다 타일 박스에 모르는 단어가 나와서 찾아보니

유리화라는.의미



glassify 가 아니라 왜 저런(?) 아려운 단어가..

'개소리 왈왈' 카테고리의 다른 글

JWST L2 안착  (0) 2022.01.25
18650 3.7V 배터리 쓰는 선풍기 분해  (0) 2018.04.21
세상에 나쁜 개는 없다 - 차우차우 편  (0) 2018.04.05
네이트온 불안정  (0) 2018.03.12
와 신천지  (0) 2018.02.03
Posted by 구차니
