Microsoft/Windows2025. 2. 21. 11:50
하드웨어/Network 장비2025. 2. 20. 22:53
intel 10G NIC 이야기 하는데 broadcom 꺼 써놓은거 보면
기술지원부서에 엄청나게 클레임이 들어왔었던듯? ㅋㅋ
| 해결 허용되는 값은 100의 합계와 일치해야 합니다. 유효한 값 범위는 다음과 같습니다. 1~(물리적 포트의 파티션 수 100개 + 1개). 다음은 가능한 범위의 두 가지 예입니다. 물리적 포트에 4개의 파티션이 있는 경우 범위는 다음과 같습니다. 1~(100~4) + 1 = 97) 물리적 포트에 파티션이 두 개 있는 경우 범위는 다음과 같습니다. 1~(100~2) + 1 = 99) 이는 정상적인 작동입니다. 다른 공급업체가 제공하는 것과 일치하는 설정이나 값은 필요하지 않습니다. (Broadcom 0 - 100) 공급업체, 브랜드, 모델 등에 따라 다릅니다. |
[링크 : https://www.dell.com/support/kbdoc/ko-kr/000202342/인텔-x710]
VF는 PCIe의 기능이라..
| A PCI Express (PCIe) Virtual Function (VF) is a lightweight PCIe function on a network adapter that supports single root I/O virtualization (SR-IOV). The VF is associated with the PCIe Physical Function (PF) on the network adapter, and represents a virtualized instance of the network adapter. Each VF has its own PCI Configuration space. Each VF also shares one or more physical resources on the network adapter, such as an external network port, with the PF and other VFs. A VF is not a full-fledged PCIe device. However, it provides a basic mechanism for directly transferring data between a Hyper-V child partition and the underlying SR-IOV network adapter. Software resources associated for data transfer are directly available to the VF and are isolated from use by the other VFs or the PF. However, the configuration of most of these resources is performed by the PF miniport driver that runs in the management operating system of the Hyper-V parent partition. |
[링크 : https://learn.microsoft.com/en-us/windows-hardware/drivers/network/sr-iov-virtual-functions--vfs-]
NIC Partitioning은 또 다른 업체의 용어인가.. VF와 같은 역할을 하는 느낌인데..
| SR-IOV(Single Root I/O Virtualization) 가상 기능(VF)을 구성하여 각 호스트에 필요한 NIC 수를 줄일 수 있습니다. 단일 고속 NIC를 여러 VF로 분할하면 컨트롤 및 데이터 플레인 트래픽에 NIC를 사용할 수 있습니다 |
PF는 물리 포트를 의미하는 것 같고..
| 배포 후 두 매개변수를 수정하면 해당 물리적 기능(PF)에 SR-IOV 포트가 있는 실행 중인 인스턴스가 중단될 수 있습니다. |
| OpenShift Container Platform 클러스터는 다음 방법을 사용하여 두 개의 물리적 기능(PF)에 2개의 VF를 사용하여 본딩 인터페이스에 배포할 수 있습니다. |
| 적합한 하드웨어와 SR-IOV를 사용하여 Linux 기반 가상화 디바이스와 NFV(Network Functions Virtualization) 모듈 간의 통신을 활성화할 수 있습니다. |
+
25.02.22
SR-IOV가 더 좋아 보이는 것 같긴한데,
intel VMDq를 설명하는 유튜브니 SR-IOV가 무조건(?) 좋다고 볼 순 없어야 할 것 같은데
무슨 차이이려나..
아무튼 hypervisor의 nic interrupt 부하를 줄이기 위해
이러한 기술이 필요하다는 건 이해되지만, 두개가 어떻게 다른진 모르겠다.
[링크 : https://www.youtube.com/watch?v=QvKXbpV6WXk]
[링크 : https://www.reddit.com/r/networking/comments/10hc9a1/io_virtualization_sriov_versus_npar/]
이어지는 시리즈인데, Hypervisor의 cpu 집중된 부하를 줄이기 위해
NIC을 여러개로 만들어서 개별 VM의 CPU로 분산 부하를 처리하고
SR-IOV는 개별 VM의 CPU 개입도 우회하여 guest 의 VF driver로 바로 꽂아준다고.
그림으로만 봐서는 그러면 SR-IOV가 가장 부하가 적을 듯?
 |
 |
[링크 : https://www.youtube.com/watch?v=hRHsk8Nycdg]
| SR-IOV and nPAR are technologies that provide similar capabilities, however they do so in different ways. SR-IOV is of course a PCI SIG standard, while nPAR is specific to a Server OEM both have their strong and weak points. Intel Ethernet devices, including the X520 currently do not support nPAR. The Intel SR-IOV solution is pretty full-featured however and does support most of what you list below. |
[링크 : https://community.intel.com/t5/Ethernet-Products/SR-IOV-vs-nPAR/td-p/219954]
| What is NPAR? NPAR (NIC Partitioning) provides the capability to create multiple native Ethernet interfaces that share a single physical port. What is SR-IOV? SR-IOV (Single Root – IO Virtualization) is a standard that can present single PCIe device (this is called Physical Function) as multiple independent PCIe devices (each one is called Virtual Function) to Operating Systems and hypervisors. NPAR and SR-IOV are the technologies that provide IO virtualization capabilities, however they do so in different ways. This blog captures high level capabilities of NPAR and SR-IOV in VMware ESXi . NPAR SR-IOV NPAR is specific to a Server OEM. SR-IOV is a PCI SIG standard. Implemented at hardware layer. SR-PCIM (Single Root – PCI Manager) has to be implemented at Hypervisor level. On a dual port adapter, each physical port is partitioned into 4 physical functions and each of the 4 partitions is an actual PCI Express function. On a dual port adapter, each physical port is further pa |
[링크 : https://www.tumblr.com/rogerpilney/68069050538/comparison-between-npar-and-sr-iov-in-vmware-esxi]
'하드웨어 > Network 장비' 카테고리의 다른 글
| BCM957810A1008G 히트싱크 분해 (0) | 2025.02.24 |
|---|---|
| ubtuntu 24.04 랜 이름이 왜이래? (0) | 2025.02.22 |
| npar(NIC Partitioning) (0) | 2025.02.19 |
| BCM957810A1008G 메뉴얼 (0) | 2025.02.11 |
| BCM957810A1008G boot oprom (0) | 2025.02.11 |
개소리 왈왈/직딩의 비애2025. 2. 20. 22:41
먼가 불타오르는 것도 없는게
그냥 서서히 죽어간다라는 느낌만 든다
1초 1초 늙는것도 아닌 죽어간다는 느낌
회사도 일이 재미없는 것만 할당되고
이상하게(?) 시간만 가고 짜증만 나고..
'개소리 왈왈 > 직딩의 비애' 카테고리의 다른 글
| k-pass 다자녀 혜택 + 횟수 제한 (0) | 2025.03.10 |
|---|---|
| 2 스택 (0) | 2025.03.07 |
| 차 끌고 일찍 옴, 10g 만져봄 (0) | 2025.02.14 |
| 하.. 현타 (0) | 2025.02.12 |
| 추워!! (0) | 2025.02.07 |
개소리 왈왈/블로그2025. 2. 20. 22:39
요 근래 조금은(?) 하락세에서 반등중
그런다고 해서 월별추세로 봐서 올라갈것 같지도 않은데, 검색엔진 유입이라도 생겼나?
'개소리 왈왈 > 블로그' 카테고리의 다른 글
| 공개 발행할 수 있는 글은 최대 30개 까지. (2) | 2025.02.22 |
|---|---|
| 엥 티스토리 글 번호 왜 이따구야? (0) | 2025.02.22 |
| 해피빈 기부 시즌 (0) | 2024.12.18 |
| 오블완 챌린지 완료 (2) | 2024.11.28 |
| 오블완 챌린지? (3) | 2024.11.07 |
개소리 왈왈/컴퓨터2025. 2. 20. 14:59
자꾸 link가 떨어지는데 랜 카드가 문제인지 케이블이 문제인지 몰라서
또 셋트로 지름!
이제 LP 2개, 표준형 2개! ㅋㅋ
걍 처음부터 2개씩 살걸..(원래 2배수 지르는 닝겐)
'개소리 왈왈 > 컴퓨터' 카테고리의 다른 글
| 10g NIC 도착 (0) | 2025.02.24 |
|---|---|
| mx4 4g 써멀 지름 (0) | 2025.02.24 |
| 줍줍 7세대? (0) | 2025.02.11 |
| 10g nic 지름 (0) | 2025.02.10 |
| 레노버 보증조회 그리고 fan error? (0) | 2025.02.09 |
Programming/C++ STL2025. 2. 20. 12:32
자동 형변환(?)은 지원안하는지
문자열 끝에 "blah blah : " + value 하니 에러가 발생해서 찾아보니
std::to_string() 이라는 착한 녀석이 존재함을 발견!
[링크 : https://en.cppreference.com/w/cpp/string/basic_string/to_string]
'Programming > C++ STL' 카테고리의 다른 글
| cpp 그래픽 라이브러리 (0) | 2025.04.22 |
|---|---|
| cpp 기본 인자 prototype (0) | 2025.03.28 |
| cpp string 끝에 한글자 지우기 (0) | 2025.02.06 |
| cpp stoi (atoi) (0) | 2025.02.06 |
| std::string:npos (0) | 2025.02.05 |
하드웨어/Network 장비2025. 2. 19. 22:22
듀얼 포트인데 한쪽에서 설정을 켜면 다른 한쪽도 같이 적용 되어버린다.
우분투에서 SF(single Function)으로는 enp1s0f0 / enp1s0f1 라고 떴는데
NPAR로 설정하고 콜드 리부팅하니 enp1s0f0~7 까지 생겨난다.
| 3: enp1s0f0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP mode DEFAULT group default qlen 1000 link/ether f4:e9:d4:8c:d6:60 brd ff:ff:ff:ff:ff:ff promiscuity 0 allmulti 0 minmtu 46 maxmtu 9600 addrgenmode eui64 numtxqueues 46 numrxqueues 16 gso_max_size 65536 gso_max_segs 65535 tso_max_size 65536 tso_max_segs 65535 gro_max_size 65536 portid f4e9d48cd660 parentbus pci parentdev 0000:01:00.0 4: enp1s0f1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP mode DEFAULT group default qlen 1000 link/ether f4:e9:d4:8c:d6:62 brd ff:ff:ff:ff:ff:ff promiscuity 0 allmulti 0 minmtu 46 maxmtu 9600 addrgenmode eui64 numtxqueues 46 numrxqueues 16 gso_max_size 65536 gso_max_segs 65535 tso_max_size 65536 tso_max_segs 65535 gro_max_size 65536 portid f4e9d48cd662 parentbus pci parentdev 0000:01:00.1 |
그나저나 우분투에서 8개 까지만 출력하게 하다 보니 2번은 가출(!!)
전체목록을 가야 보인다. 링크는 설정에서100% bandwidth로 되어 있어서 10G가 그대로 뜬다.
10%면 1G로 뜨나 확인을 해봐야겠다.
 |
 |
맥이 짝수로 점프하는데 그럼.. 홀수는 누가 쓰고 있을까?
이전글에서확인해보니 iSCSI에서 해당 홀수 mac을 쓰고 있다. 그러면.. FCoE는 Ethernet이니 별도의 MAC은 할당되어 있지 않는건가?
2025.02.11 - [하드웨어/Network 장비] - BCM957810A1008G boot oprom
| $ ifconfig enp1s0f0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.0.1 netmask 255.255.255.0 broadcast 192.168.0.255 ether f4:e9:d4:8c:d6:60 txqueuelen 1000 (Ethernet) RX packets 56 bytes 7322 (7.3 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 44 bytes 2776 (2.7 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 16 memory 0xe0000000-e07fffff enp1s0f1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.0.2 netmask 255.255.255.0 broadcast 192.168.0.255 ether f4:e9:d4:8c:d6:62 txqueuelen 1000 (Ethernet) RX packets 55 bytes 7521 (7.5 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 46 bytes 2890 (2.8 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 17 memory 0xe1000000-e17fffff enp1s0f2: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet6 fe80::10a0:6d46:dd8b:5874 prefixlen 64 scopeid 0x20<link> ether f4:e9:d4:8c:d6:64 txqueuelen 1000 (Ethernet) RX packets 61 bytes 8164 (8.1 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 18 bytes 3024 (3.0 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 17 memory 0xe2000000-e27fffff enp1s0f3: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet6 fe80::56f0:e7ae:639d:4ac0 prefixlen 64 scopeid 0x20<link> ether f4:e9:d4:8c:d6:66 txqueuelen 1000 (Ethernet) RX packets 57 bytes 7967 (7.9 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 16 bytes 2588 (2.5 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 18 memory 0xe3000000-e37fffff enp1s0f4: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet6 fe80::6455:3064:bef9:3b30 prefixlen 64 scopeid 0x20<link> ether f4:e9:d4:8c:d6:68 txqueuelen 1000 (Ethernet) RX packets 57 bytes 7785 (7.7 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 18 bytes 2859 (2.8 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 18 memory 0xe4000000-e47fffff enp1s0f5: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet6 fe80::4d88:313b:1a0f:af85 prefixlen 64 scopeid 0x20<link> ether f4:e9:d4:8c:d6:6a txqueuelen 1000 (Ethernet) RX packets 59 bytes 8362 (8.3 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 18 bytes 2859 (2.8 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 19 memory 0xe5000000-e57fffff enp1s0f6: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet6 fe80::7a24:ce1e:ab69:f11b prefixlen 64 scopeid 0x20<link> ether f4:e9:d4:8c:d6:6c txqueuelen 1000 (Ethernet) RX packets 61 bytes 8164 (8.1 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 21 bytes 3400 (3.4 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 19 memory 0xe6000000-e67fffff enp1s0f7: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet6 fe80::b1ad:7263:6c7e:7aa4 prefixlen 64 scopeid 0x20<link> ether f4:e9:d4:8c:d6:6e txqueuelen 1000 (Ethernet) RX packets 57 bytes 7967 (7.9 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 17 bytes 2654 (2.6 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 device interrupt 16 memory 0xe7000000-e77fffff enp3s0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.219.111 netmask 255.255.255.0 broadcast 192.168.219.255 inet6 fe80::6245:cbff:fe9d:3a12 prefixlen 64 scopeid 0x20<link> ether 60:45:cb:9d:3a:12 txqueuelen 1000 (Ethernet) RX packets 55 bytes 17755 (17.7 KB) RX errors 0 dropped 7 overruns 0 frame 0 TX packets 99 bytes 12054 (12.0 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536 inet 127.0.0.1 netmask 255.0.0.0 inet6 ::1 prefixlen 128 scopeid 0x10<host> loop txqueuelen 1000 (Local Loopback) RX packets 558 bytes 50639 (50.6 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 558 bytes 50639 (50.6 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 |
'하드웨어 > Network 장비' 카테고리의 다른 글
| ubtuntu 24.04 랜 이름이 왜이래? (0) | 2025.02.22 |
|---|---|
| NPAR와 SR-IOV? (0) | 2025.02.20 |
| BCM957810A1008G 메뉴얼 (0) | 2025.02.11 |
| BCM957810A1008G boot oprom (0) | 2025.02.11 |
| SFP(Small Form-factor Pluggable) (0) | 2025.02.10 |
하드웨어/FC_SAN_10G2025. 2. 19. 21:55
G4560 / 4GB / 128GB SATA SSD 에서 테스트 했는데
SSD도 문제가 있나.. 아니면 리눅스도 이제 4GB로는 무리인가.. 부팅도 오래걸리고, 설치도 엄청 오래 걸렸다.
최대 설정가능한 MTU는 ip 명령을 통해 확인이 가능하고
| $ ip -d link list 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 promiscuity 0 allmulti 0 minmtu 0 maxmtu 0 addrgenmode eui64 numtxqueues 1 numrxqueues 1 gso_max_size 65536 gso_max_segs 65535 tso_max_size 524280 tso_max_segs 65535 gro_max_size 65536 2: enp3s0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP mode DEFAULT group default qlen 1000 link/ether 60:45:cb:9d:3a:12 brd ff:ff:ff:ff:ff:ff promiscuity 0 allmulti 0 minmtu 68 maxmtu 9194 addrgenmode eui64 numtxqueues 1 numrxqueues 1 gso_max_size 64000 gso_max_segs 64 tso_max_size 64000 tso_max_segs 64 gro_max_size 65536 parentbus pci parentdev 0000:03:00.0 3: enp1s0f0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP mode DEFAULT group default qlen 1000 link/ether f4:e9:d4:8c:d6:60 brd ff:ff:ff:ff:ff:ff promiscuity 0 allmulti 0 minmtu 46 maxmtu 9600 addrgenmode eui64 numtxqueues 46 numrxqueues 16 gso_max_size 65536 gso_max_segs 65535 tso_max_size 65536 tso_max_segs 65535 gro_max_size 65536 portid f4e9d48cd660 parentbus pci parentdev 0000:01:00.0 4: enp1s0f1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP mode DEFAULT group default qlen 1000 link/ether f4:e9:d4:8c:d6:62 brd ff:ff:ff:ff:ff:ff promiscuity 0 allmulti 0 minmtu 46 maxmtu 9600 addrgenmode eui64 numtxqueues 46 numrxqueues 16 gso_max_size 65536 gso_max_segs 65535 tso_max_size 65536 tso_max_segs 65535 gro_max_size 65536 portid f4e9d48cd662 parentbus pci parentdev 0000:01:00.1 $ sudo ifconfig enp1s0f1 mtu 9600 |
[링크: https://unix.stackexchange.com/questions/552107/how-to-get-maximum-supported-mtu-size-for-interface]
위는 MTU 1500
아래는 MTU 9600 로 설정하고 테스트 했는데
커널 내부 전송이었는지 10G NIC 인데 40G가 나오고 난리.. -_-
아무튼 MTU가 커지니 좀 안정적으로 40G 이상 나오는 것 정도로 정리되는데
| $ iperf3 -s ----------------------------------------------------------- Server listening on 5201 (test #1) ----------------------------------------------------------- Accepted connection from 192.168.0.1, port 46302 [ 5] local 192.168.0.1 port 5201 connected to 192.168.0.1 port 46304 [ ID] Interval Transfer Bitrate [ 5] 0.00-1.00 sec 5.09 GBytes 43.7 Gbits/sec [ 5] 1.00-2.00 sec 4.58 GBytes 39.4 Gbits/sec [ 5] 2.00-3.00 sec 3.87 GBytes 33.2 Gbits/sec [ 5] 3.00-4.00 sec 4.58 GBytes 39.4 Gbits/sec [ 5] 4.00-5.00 sec 4.47 GBytes 38.4 Gbits/sec [ 5] 5.00-6.00 sec 4.80 GBytes 41.3 Gbits/sec [ 5] 6.00-7.00 sec 4.78 GBytes 41.0 Gbits/sec [ 5] 7.00-8.00 sec 3.46 GBytes 29.8 Gbits/sec [ 5] 8.00-9.00 sec 2.80 GBytes 24.1 Gbits/sec [ 5] 9.00-10.00 sec 3.33 GBytes 28.6 Gbits/sec [ 5] 10.00-10.00 sec 768 KBytes 23.8 Gbits/sec - - - - - - - - - - - - - - - - - - - - - - - - - [ ID] Interval Transfer Bitrate [ 5] 0.00-10.00 sec 41.8 GBytes 35.9 Gbits/sec receiver |
$ iperf3 -c 192.168.0.1 Connecting to host 192.168.0.1, port 5201 [ 5] local 192.168.0.1 port 46304 connected to 192.168.0.1 port 5201 [ ID] Interval Transfer Bitrate Retr Cwnd [ 5] 0.00-1.00 sec 5.09 GBytes 43.7 Gbits/sec 0 1.62 MBytes [ 5] 1.00-2.00 sec 3.34 GBytes 28.7 Gbits/sec 3 3.31 MBytes [ 5] 2.00-3.00 sec 3.86 GBytes 33.2 Gbits/sec 0 4.12 MBytes [ 5] 3.00-4.00 sec 4.58 GBytes 39.3 Gbits/sec 0 4.12 MBytes [ 5] 4.00-5.00 sec 4.47 GBytes 38.4 Gbits/sec 0 4.12 MBytes [ 5] 5.00-6.00 sec 4.80 GBytes 41.3 Gbits/sec 0 4.12 MBytes [ 5] 6.00-7.00 sec 4.75 GBytes 40.8 Gbits/sec 0 4.12 MBytes [ 5] 7.00-8.00 sec 3.45 GBytes 29.6 Gbits/sec 0 4.12 MBytes [ 5] 8.00-9.00 sec 2.79 GBytes 23.9 Gbits/sec 0 4.12 MBytes [ 5] 9.00-10.00 sec 3.32 GBytes 28.6 Gbits/sec 2 4.12 MBytes - - - - - - - - - - - - - - - - - - - - - - - - - [ ID] Interval Transfer Bitrate Retr [ 5] 0.00-10.00 sec 41.8 GBytes 35.9 Gbits/sec 5 sender [ 5] 0.00-10.00 sec 41.8 GBytes 35.9 Gbits/sec receiver iperf Done. |
| ----------------------------------------------------------- Server listening on 5201 (test #4) ----------------------------------------------------------- Accepted connection from 192.168.0.1, port 39920 [ 5] local 192.168.0.1 port 5201 connected to 192.168.0.1 port 39926 [ ID] Interval Transfer Bitrate [ 5] 0.00-1.00 sec 4.99 GBytes 42.8 Gbits/sec [ 5] 1.00-2.00 sec 5.43 GBytes 46.6 Gbits/sec [ 5] 2.00-3.00 sec 5.30 GBytes 45.5 Gbits/sec [ 5] 3.00-4.00 sec 5.39 GBytes 46.3 Gbits/sec [ 5] 4.00-5.00 sec 5.31 GBytes 45.6 Gbits/sec [ 5] 5.00-6.00 sec 5.21 GBytes 44.7 Gbits/sec [ 5] 6.00-7.00 sec 5.39 GBytes 46.3 Gbits/sec [ 5] 7.00-8.00 sec 5.35 GBytes 46.0 Gbits/sec [ 5] 8.00-9.00 sec 5.37 GBytes 46.1 Gbits/sec [ 5] 9.00-10.00 sec 5.61 GBytes 48.2 Gbits/sec [ 5] 10.00-10.00 sec 512 KBytes 17.4 Gbits/sec - - - - - - - - - - - - - - - - - - - - - - - - - [ ID] Interval Transfer Bitrate [ 5] 0.00-10.00 sec 53.4 GBytes 45.8 Gbits/sec receiver |
$ iperf3 -c 192.168.0.1 Connecting to host 192.168.0.1, port 5201 [ 5] local 192.168.0.1 port 39926 connected to 192.168.0.1 port 5201 [ ID] Interval Transfer Bitrate Retr Cwnd [ 5] 0.00-1.00 sec 4.99 GBytes 42.8 Gbits/sec 0 1.12 MBytes [ 5] 1.00-2.00 sec 5.41 GBytes 46.4 Gbits/sec 0 1.19 MBytes [ 5] 2.00-3.00 sec 5.30 GBytes 45.5 Gbits/sec 0 1.37 MBytes [ 5] 3.00-4.00 sec 3.92 GBytes 33.7 Gbits/sec 0 1.37 MBytes [ 5] 4.00-5.00 sec 4.99 GBytes 42.9 Gbits/sec 0 1.37 MBytes [ 5] 5.00-6.00 sec 5.21 GBytes 44.7 Gbits/sec 0 3.18 MBytes [ 5] 6.00-7.00 sec 5.39 GBytes 46.3 Gbits/sec 0 3.18 MBytes [ 5] 7.00-8.00 sec 5.35 GBytes 46.0 Gbits/sec 0 3.18 MBytes [ 5] 8.00-9.00 sec 5.35 GBytes 46.0 Gbits/sec 0 3.18 MBytes [ 5] 9.00-10.00 sec 5.62 GBytes 48.2 Gbits/sec 0 3.18 MBytes - - - - - - - - - - - - - - - - - - - - - - - - - [ ID] Interval Transfer Bitrate Retr [ 5] 0.00-10.00 sec 53.4 GBytes 45.8 Gbits/sec 0 sender [ 5] 0.00-10.00 sec 53.4 GBytes 45.8 Gbits/sec receiver iperf Done. |
-P 1 혹은 옵션 없이 하면 50% 정도 먹고
-P 4로 4 프로세스 사용하도록 하면 100%은 찍는데
물리 cpu가 2개에 HT 4개인 녀석이라, 40GBps 를 초과하진 못한다.
[링크: https://www.reddit.com/r/homelab/comments/11v94kz/new_10g_network_iperf_3_maxing_out_at_6_gbitssec/]
'하드웨어 > FC_SAN_10G' 카테고리의 다른 글
| BCM957810A1008G 10g linux 로그 (0) | 2025.02.23 |
|---|---|
| 10g with cat 8 S-FTP 케이블 (0) | 2025.02.23 |
| 10g nic 테스트, link unstable (0) | 2025.02.22 |
| BCM957810A1008G 10G nic 도착 (0) | 2025.02.11 |
| 10G FCoE CEE? (0) | 2025.02.03 |
모종의 음모/CAN2025. 2. 19. 16:35
| $ modprobe vcan modprobe: ERROR: could not insert 'vcan': Operation not permitted $ sudo modprobe vcan $ sudo ip link add dev vcan0 type vcan $ ifconfig br-638c83b169eb: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 inet 172.18.0.1 netmask 255.255.0.0 broadcast 172.18.255.255 ether 02:42:d5:e6:f1:21 txqueuelen 0 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 docker0: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 inet 172.17.0.1 netmask 255.255.0.0 broadcast 172.17.255.255 ether 02:42:40:63:97:cb txqueuelen 0 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 enxf8e43b9b776b: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.220.108 netmask 255.255.0.0 broadcast 192.168.255.255 inet6 fe80::81f4:65ad:f7cc:2f2c prefixlen 64 scopeid 0x20<link> ether f8:e4:3b:9b:77:6b txqueuelen 1000 (Ethernet) RX packets 3619726 bytes 2156366501 (2.1 GB) RX errors 0 dropped 106170 overruns 0 frame 0 TX packets 1452518 bytes 317915291 (317.9 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536 inet 127.0.0.1 netmask 255.0.0.0 inet6 ::1 prefixlen 128 scopeid 0x10<host> loop txqueuelen 1000 (Local Loopback) RX packets 160829 bytes 14028478 (14.0 MB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 160829 bytes 14028478 (14.0 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 wlo1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.220.107 netmask 255.255.0.0 broadcast 192.168.255.255 inet6 fe80::104b:d69c:878f:cfaa prefixlen 64 scopeid 0x20<link> ether 8c:55:4a:28:25:bc txqueuelen 1000 (Ethernet) RX packets 809871 bytes 90255020 (90.2 MB) RX errors 0 dropped 99865 overruns 0 frame 0 TX packets 53067 bytes 6125665 (6.1 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 $ ifconfig -a br-638c83b169eb: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 inet 172.18.0.1 netmask 255.255.0.0 broadcast 172.18.255.255 ether 02:42:d5:e6:f1:21 txqueuelen 0 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 docker0: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 inet 172.17.0.1 netmask 255.255.0.0 broadcast 172.17.255.255 ether 02:42:40:63:97:cb txqueuelen 0 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 enxf8e43b9b776b: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.220.108 netmask 255.255.0.0 broadcast 192.168.255.255 inet6 fe80::81f4:65ad:f7cc:2f2c prefixlen 64 scopeid 0x20<link> ether f8:e4:3b:9b:77:6b txqueuelen 1000 (Ethernet) RX packets 3620125 bytes 2156544266 (2.1 GB) RX errors 0 dropped 106183 overruns 0 frame 0 TX packets 1452676 bytes 317938700 (317.9 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536 inet 127.0.0.1 netmask 255.0.0.0 inet6 ::1 prefixlen 128 scopeid 0x10<host> loop txqueuelen 1000 (Local Loopback) RX packets 160841 bytes 14030154 (14.0 MB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 160841 bytes 14030154 (14.0 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 vcan0: flags=128<NOARP> mtu 72 unspec 00-00-00-00-00-00-00-00-00-00-00-00-00-00-00-00 txqueuelen 1000 (UNSPEC) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 wlo1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.220.107 netmask 255.255.0.0 broadcast 192.168.255.255 inet6 fe80::104b:d69c:878f:cfaa prefixlen 64 scopeid 0x20<link> ether 8c:55:4a:28:25:bc txqueuelen 1000 (Ethernet) RX packets 809990 bytes 90270371 (90.2 MB) RX errors 0 dropped 99877 overruns 0 frame 0 TX packets 53074 bytes 6126348 (6.1 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 $ sudo ifconfig vcan0 up $ ifconfig br-638c83b169eb: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 inet 172.18.0.1 netmask 255.255.0.0 broadcast 172.18.255.255 ether 02:42:d5:e6:f1:21 txqueuelen 0 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 docker0: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 inet 172.17.0.1 netmask 255.255.0.0 broadcast 172.17.255.255 ether 02:42:40:63:97:cb txqueuelen 0 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 enxf8e43b9b776b: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.220.108 netmask 255.255.0.0 broadcast 192.168.255.255 inet6 fe80::81f4:65ad:f7cc:2f2c prefixlen 64 scopeid 0x20<link> ether f8:e4:3b:9b:77:6b txqueuelen 1000 (Ethernet) RX packets 3620430 bytes 2156573250 (2.1 GB) RX errors 0 dropped 106197 overruns 0 frame 0 TX packets 1452764 bytes 317953427 (317.9 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536 inet 127.0.0.1 netmask 255.0.0.0 inet6 ::1 prefixlen 128 scopeid 0x10<host> loop txqueuelen 1000 (Local Loopback) RX packets 160841 bytes 14030154 (14.0 MB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 160841 bytes 14030154 (14.0 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 vcan0: flags=193<UP,RUNNING,NOARP> mtu 72 unspec 00-00-00-00-00-00-00-00-00-00-00-00-00-00-00-00 txqueuelen 1000 (UNSPEC) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 wlo1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.220.107 netmask 255.255.0.0 broadcast 192.168.255.255 inet6 fe80::104b:d69c:878f:cfaa prefixlen 64 scopeid 0x20<link> ether 8c:55:4a:28:25:bc txqueuelen 1000 (Ethernet) RX packets 810099 bytes 90278671 (90.2 MB) RX errors 0 dropped 99889 overruns 0 frame 0 TX packets 53074 bytes 6126348 (6.1 MB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 |
[링크 : https://ola-page.tistory.com/66]
| $ candump candump - dump CAN bus traffic. Usage: candump [options] <CAN interface>+ (use CTRL-C to terminate candump) Options: -t <type> (timestamp: (a)bsolute/(d)elta/(z)ero/(A)bsolute w date) -H (read hardware timestamps instead of system timestamps) -c (increment color mode level) -i (binary output - may exceed 80 chars/line) -a (enable additional ASCII output) -S (swap byte order in printed CAN data[] - marked with '`' ) -s <level> (silent mode - 0: off (default) 1: animation 2: silent) -l (log CAN-frames into file. Sets '-s 2' by default) -L (use log file format on stdout) -n <count> (terminate after reception of <count> CAN frames) -r <size> (set socket receive buffer to <size>) -D (Don't exit if a "detected" can device goes down. -d (monitor dropped CAN frames) -e (dump CAN error frames in human-readable format) -x (print extra message infos, rx/tx brs esi) -T <msecs> (terminate after <msecs> without any reception) Up to 16 CAN interfaces with optional filter sets can be specified on the commandline in the form: <ifname>[,filter]* Filters: Comma separated filters can be specified for each given CAN interface: <can_id>:<can_mask> (matches when <received_can_id> & mask == can_id & mask) <can_id>~<can_mask> (matches when <received_can_id> & mask != can_id & mask) #<error_mask> (set error frame filter, see include/linux/can/error.h) [j|J] (join the given CAN filters - logical AND semantic) CAN IDs, masks and data content are given and expected in hexadecimal values. When the can_id is 8 digits long the CAN_EFF_FLAG is set for 29 bit EFF format. Without any given filter all data frames are received ('0:0' default filter). Use interface name 'any' to receive from all CAN interfaces. Examples: candump -c -c -ta can0,123:7FF,400:700,#000000FF can2,400~7F0 can3 can8 candump -l any,0~0,#FFFFFFFF (log only error frames but no(!) data frames) candump -l any,0:0,#FFFFFFFF (log error frames and also all data frames) candump vcan2,12345678:DFFFFFFF (match only for extended CAN ID 12345678) candump vcan2,123:7FF (matches CAN ID 123 - including EFF and RTR frames) candump vcan2,123:C00007FF (matches CAN ID 123 - only SFF and non-RTR frames) |
| $ cansend vcan0 cansend - send CAN-frames via CAN_RAW sockets. Usage: cansend <device> <can_frame>. <can_frame>: <can_id>#{data} for 'classic' CAN 2.0 data frames <can_id>#R{len} for 'classic' CAN 2.0 data frames <can_id>##<flags>{data} for CAN FD frames <can_id>: 3 (SFF) or 8 (EFF) hex chars {data}: 0..8 (0..64 CAN FD) ASCII hex-values (optionally separated by '.') {len}: an optional 0..8 value as RTR frames can contain a valid dlc field <flags>: a single ASCII Hex value (0 .. F) which defines canfd_frame.flags Examples: 5A1#11.2233.44556677.88 / 123#DEADBEEF / 5AA# / 123##1 / 213##311223344 / 1F334455#1122334455667788 / 123#R / 00000123#R3 |
아래는 데이터 출력 포맷 확인용
인터페이스 / CAN id / 길이 / 데이터(페이로드 길이)
| receive | send |
| $ candump vcan0 vcan0 111 [5] 01 02 03 04 05 |
$ cansend vcan0 111#010203.04.05 |
| vcan0 112 [5] 01 02 03 04 05 | $ cansend vcan0 112#010203.04.05 |
| vcan0 112 [0] | $ cansend vcan0 112# |
| vcan0 112 [00] | $ cansend vcan0 112##1 |
| vcan0 112 [01] 23 | $ cansend vcan0 112##123 |
| vcan0 112 [0] remote request | $ cansend vcan0 112#R |
| vcan0 112 [3] remote request | $ cansend vcan0 112#R3 |
받는 쪽에서 CAN id 제한할 경우, 112를 받도록 설정했기에 113은 무시된다.
| $ candump vcan0,112:FF | $ cansend vcan0 111#R3 |
| vcan0 112 [3] remote request | $ cansend vcan0 112#R3 |
| $ cansend vcan0 113#R3 | |
| vcan0 112 [5] 01 02 03 04 05 | $ cansend vcan0 112#010203.04.05 |
| vcan0 112 [6] 01 02 03 04 05 06 | $ cansend vcan0 112#010203.04.0506 |
| vcan0 112 [7] 01 02 03 04 05 06 07 | $ cansend vcan0 112#010203.04.0506.07 |
| vcan0 112 [0] remote request | $ cansend vcan0 112#R $ cansend vcan0 112#R10 $ cansend vcan0 112#R100 |
| vcan0 112 [1] remote request | $ cansend vcan0 112#R1 |
| vcan0 112 [2] remote request | $ cansend vcan0 112#R2 |
| vcan0 112 [8] remote request | $ cansend vcan0 112#R8 |
그나저나 mask 라는데 이해가 안되네..
123 = 0x7B & 0x7F0 하면 0x7B가 되어야 하니 16개에 대해서 받아들여야 할 거 같은데 왜 119에서 130 까지 12개 받아들여 질까?
| $ candump vcan0,123:7F0 vcan0 120 [0] remote request vcan0 121 [0] remote request vcan0 122 [0] remote request vcan0 123 [0] remote request vcan0 124 [0] remote request vcan0 125 [0] remote request vcan0 126 [0] remote request vcan0 127 [0] remote request vcan0 128 [0] remote request vcan0 129 [0] remote request |
$ cansend vcan0 119#R $ cansend vcan0 120#R $ cansend vcan0 121#R $ cansend vcan0 122#R $ cansend vcan0 123#R $ cansend vcan0 124#R $ cansend vcan0 125#R $ cansend vcan0 126#R $ cansend vcan0 127#R $ cansend vcan0 128#R $ cansend vcan0 129#R $ cansend vcan0 130#R |
'모종의 음모 > CAN' 카테고리의 다른 글
| DeviceNet CAN (0) | 2025.04.01 |
|---|---|
| linux can 테스트(가상 CAN IF) (0) | 2025.02.18 |
| can-utils(cansend, candump) (0) | 2025.02.18 |
| can invader (0) | 2024.01.09 |
| CAN(controller area network) (0) | 2023.10.31 |
하드웨어/Server Case & board2025. 2. 18. 18:58
서버 메인보드에서 NCSI 라는 명칭이 나오길래 찾아보는 중
서버 보드에 관리용 포트로 보이는게 두개 있는데
하나는 IPMI 라고 bios에서 써있고
다른 하나는 NCSI 라고 써있다.
