  1. 2023.08.31 freecad 첫 드로잉 2
  2. 2023.08.29 bitbake --help
  3. 2023.08.28 Do not use Bitbake as root.
  4. 2023.08.28 imx8 yocto
  5. 2023.08.28 makefile 매크로(?)
  6. 2023.08.16 make 조건식
  7. 2023.08.08 gcc cortex-a9 double형 neon 연산 가속 3
  8. 2023.08.05 libreoffice calc 중복제거
  9. 2023.08.04 libreoffice OpenCL 적용하기
  10. 2023.07.28 iperf3
프로그램 사용/freecad2023. 8. 31. 11:05

freecad 에서 도면을 그리려면 먼가 어렵다?

상단의 툴바에서 누르던가 아니면

보기 - 워크벤치 - Draft 혹은 Part Design을 누르면 되는 것 같은데



Draft를 누르면 아래와 같이 격자종이가 나오고



part Design을 누르면 그냥 빈화면만 나온다.

[링크 : https://commox111.tistory.com/65]



part design 에서 점이나 선을 그리려면 활성바디가 없다고 에러가 나는데

좌측에 생성 : 바디(body) 누르면 어떻게 시작은 가능한 듯.

[링크 : https://www.youtube.com/watch?v=x53Jbr16ekI]



아무튼 draft 에서 대충대충 선을 그리고

modification - array tools - circular array로 대충 베어링은 그려볼 수 있을 듯.

'프로그램 사용 > freecad' 카테고리의 다른 글

CSG(Constructive solid geometry) freecad  (0) 2024.08.30
freecad 사용법 다시..  (2) 2024.08.29
freeCAD 는 ubuntu24.04에서 사라졌나?  (0) 2024.08.29
ubuntu용 cad 프로그램  (0) 2020.09.23
freecad 설명  (0) 2018.01.22
Posted by 구차니

명령어 조사중

bitbake -c compile -f recipe 식으로 많이 써왔는데

상세 명령이나 recipre 목록등을 얻는 방법을 찾는 중



Usage: bitbake [options] [recipename/target recipe:do_task ...]

    Executes the specified task (default is 'build') for a given set of target recipes (.bb files).
    It is assumed there is a conf/bblayers.conf available in cwd or in BBPATH which
    will provide the layer, BBFILES and other configuration information.

Options:
  --version             show program's version number and exit
  -h, --help            show this help message and exit
  -b BUILDFILE, --buildfile=BUILDFILE
                        Execute tasks from a specific .bb recipe directly.
                        WARNING: Does not handle any dependencies from other
                        recipes.
  -k, --continue        Continue as much as possible after an error. While the
                        target that failed and anything depending on it cannot
                        be built, as much as possible will be built before
                        stopping.
  -f, --force           Force the specified targets/task to run (invalidating any existing stamp file).
  -c CMD, --cmd=CMD     Specify the task to execute. The exact options
                        available depend on the metadata. Some examples might
                        be 'compile' or 'populate_sysroot' or 'listtasks' may
                        give a list of the tasks available.
  -C INVALIDATE_STAMP, --clear-stamp=INVALIDATE_STAMP
                        Invalidate the stamp for the specified task such as
                        'compile' and then run the default task for the
                        specified target(s).
  -r PREFILE, --read=PREFILE
                        Read the specified file before bitbake.conf.
  -R POSTFILE, --postread=POSTFILE
                        Read the specified file after bitbake.conf.
  -v, --verbose         Enable tracing of shell tasks (with 'set -x'). Also
                        print bb.note(...) messages to stdout (in addition to
                        writing them to ${T}/log.do_<task>).
  -D, --debug           Increase the debug level. You can specify this more
                        than once. -D sets the debug level to 1, where only
                        bb.debug(1, ...) messages are printed to stdout; -DD
                        sets the debug level to 2, where both bb.debug(1, ...)
                        and bb.debug(2, ...) messages are printed; etc.
                        Without -D, no debug messages are printed. Note that
                        -D only affects output to stdout. All debug messages
                        are written to ${T}/log.do_taskname, regardless of the
                        debug level.
  -q, --quiet           Output less log message data to the terminal. You can
                        specify this more than once.
  -n, --dry-run         Don't execute, just go through the motions.
  -S SIGNATURE_HANDLER, --dump-signatures=SIGNATURE_HANDLER
                        Dump out the signature construction information, with
                        no task execution. The SIGNATURE_HANDLER parameter is
                        passed to the handler. Two common values are none and
                        printdiff but the handler may define more/less. none
                        means only dump the signature, printdiff means compare
                        the dumped signature with the cached one.
  -p, --parse-only      Quit after parsing the BB recipes.
  -s, --show-versions   Show current and preferred versions of all recipes.
  -e, --environment     Show the global or per-recipe environment complete
                        with information about where variables were
                        set/changed.
  -g, --graphviz        Save dependency tree information for the specified
                        targets in the dot syntax.
  -I EXTRA_ASSUME_PROVIDED, --ignore-deps=EXTRA_ASSUME_PROVIDED
                        Assume these dependencies don't exist and are already
                        provided (equivalent to ASSUME_PROVIDED). Useful to
                        make dependency graphs more appealing
  -l DEBUG_DOMAINS, --log-domains=DEBUG_DOMAINS
                        Show debug logging for the specified logging domains
  -P, --profile         Profile the command and save reports.
  -u UI, --ui=UI        The user interface to use (knotty, ncurses or teamcity
                        - default knotty).
  --token=XMLRPCTOKEN   Specify the connection token to be used when
                        connecting to a remote server.
  --revisions-changed   Set the exit code depending on whether upstream
                        floating revisions have changed or not.
  --server-only         Run bitbake without a UI, only starting a server
                        (cooker) process.
  -B BIND, --bind=BIND  The name/address for the bitbake xmlrpc server to bind
                        to.
  -T SERVER_TIMEOUT, --idle-timeout=SERVER_TIMEOUT
                        Set timeout to unload bitbake server due to
                        inactivity, set to -1 means no unload, default:
                        Environment variable BB_SERVER_TIMEOUT.
  --no-setscene         Do not run any setscene tasks. sstate will be ignored
                        and everything needed, built.
  --skip-setscene       Skip setscene tasks if they would be executed. Tasks
                        previously restored from sstate will be kept, unlike
                        --no-setscene
  --setscene-only       Only run setscene tasks, don't run any real tasks.
  --remote-server=REMOTE_SERVER
                        Connect to the specified server.
  -m, --kill-server     Terminate any running bitbake server.
  --observe-only        Connect to a server as an observing-only client.
  --status-only         Check the status of the remote bitbake server.
  -w WRITEEVENTLOG, --write-log=WRITEEVENTLOG
                        Writes the event log of the build to a bitbake event
                        json file. Use '' (empty string) to assign the name
                        automatically.
  --runall=RUNALL       Run the specified task for any recipe in the taskgraph
                        of the specified target (even if it wouldn't otherwise
                        have run).
  --runonly=RUNONLY     Run only the specified task within the taskgraph of
                        the specified targets (and any task dependencies those
                        tasks may have).



$ bitbake -c listtasks
Nothing to do.  Use 'bitbake world' to build everything, or run 'bitbake --help' for usage information.



$ bitbake-layers show-recipes

[링크 : https://stackoverflow.com/questions/32850160/bitbake-how-to-list-all-recipe-and-append-files-used-in-an-image]



For an updated list for a specific recipe, run:

bitbake -c listtasks <recipe>

fetchall Fetch all source
build
devshell
package_write_ipk
cleansstate Clean the build/sstate-cache directory
configure
clean clean $WORKDIR
cleanall clean $WORKDIR and sstate-cache
populate_lic
package_write
populate_sysroot
buildall
populate_lic_setscene
patch
listtasks list all tasks that can be run for a target
compile
package_setscene
fetch
checkuri
package_write_ipk_setscene
package
unpack
install
populate_sysroot_setscene
checkuriall

[링크 : https://www.openembedded.org/wiki/List_of_Executable_tasks]

'프로그램 사용 > yocto project' 카테고리의 다른 글

yocto build on i5-3570  (0) 2023.09.07
Do not use Bitbake as root.  (0) 2023.08.28
imx8 yocto  (0) 2023.08.28
imx8 yocto build on ubuntu 22.04  (0) 2023.02.10
라즈베리 파이 with yocto project  (2) 2015.07.30
Posted by 구차니

bitbake로 yocto를 빌드 하려고 하는데 에러가 나서 찾아보니

메시지 자체는 root로 bitbake 하지 말란건데, 설정상으로는 sanity를 inherit 하지 않도록 하면 되는 듯.



분별을(제정신을) 상속 안받으면 제정신이 아니게 되는건가...(!)

sanity 미국∙영국 [ˈsænəti]  영국식 1. [명사] 온전한 정신 (상태)
2. [명사] 분별 (→sane), (↔insanity)



# Sanity checks for common user misconfigurations
#
# See sanity.bbclass
#
# Expert users can confirm their sanity with "touch conf/sanity.conf"
BB_MIN_VERSION = "1.49.2"

SANITY_ABIFILE = "${TMPDIR}/abi_version"

SANITY_VERSION ?= "1"
LOCALCONF_VERSION  ?= "1"
LAYER_CONF_VERSION ?= "7"
SITE_CONF_VERSION  ?= "1"

#INHERIT += "sanity"

[링크 : http://./sources/poky/meta/conf/sanity.conf]

'프로그램 사용 > yocto project' 카테고리의 다른 글

yocto build on i5-3570  (0) 2023.09.07
bitbake --help  (0) 2023.08.29
imx8 yocto  (0) 2023.08.28
imx8 yocto build on ubuntu 22.04  (0) 2023.02.10
라즈베리 파이 with yocto project  (2) 2015.07.30
Posted by 구차니

문서가 개정되어서 하기 쉽게 잘 나와있는 듯.



Rev. LF6.1.22_2.0.0 — 30 June 2023

The recommended minimum Ubuntu version is 20.04 or later.

$ sudo apt install gawk wget git diffstat unzip texinfo gcc build-essential chrpath socat cpio python3 python3-pip python3-pexpect xz-utils debianutils iputils-ping python3-git python3-jinja2 libegl1-mesa libsdl1.2-dev python3- subunit mesa-common-dev zstd liblz4-tool file locales

// lz4c 어쩌구 나오면
$ sudo apt install lz4

// repo 설치
$ mkdir ~/bin (this step may not be needed if the bin folder already exists)
$ curl https://storage.googleapis.com/git-repo-downloads/repo > ~/bin/repo
$ chmod a+x ~/bin/repo

// repo 초기화
$ repo init -u https://github.com/nxp-imx/imx-manifest -b imx-linux-mickledore -m imx-6.1.22-2.0.0.xml
$ repo sync

$ DISTRO=<distro name> MACHINE=<machine name> source imx-setup-release.sh -b <build dir>

$ bitbake imx-image-multimedia

[링크 : https://www.nxp.com/docs/en/user-guide/IMX_YOCTO_PROJECT_USERS_GUIDE.pdf]



python 패키지 명이 바뀌어서 손을 대보는데 그래도 안되서

혹시나 하는 마음에 3.9를 설치해보니 정상적으로 설치안되었다고 -_-

$ bitbake -c compile -f weston
Traceback (most recent call last):
  File "/home/falinux/work/work/yocto/sources/poky/bitbake/bin/bitbake", line 19, in <module>
    import bb
  File "/home/falinux/work/work/yocto/sources/poky/bitbake/lib/bb/__init__.py", line 128, in <module>
    from bb import fetch2 as fetch
  File "/home/falinux/work/work/yocto/sources/poky/bitbake/lib/bb/fetch2/__init__.py", line 26, in <module>
    import bb.persist_data, bb.utils
  File "/home/falinux/work/work/yocto/sources/poky/bitbake/lib/bb/persist_data.py", line 22, in <module>
    from collections import Mapping
ImportError: cannot import name 'Mapping' from 'collections' (/usr/lib/python3.10/collections/__init__.py)

$ bitbake -c compile -f weston
WARNING: Host distribution "ubuntu-22.04" has not been validated with this version of the build system; you may possibly experience unexpected failures. It is recommended that you use a tested distribution.
ERROR:  OE-core's config sanity checker detected a potential misconfiguration.
    Either fix the cause of this error or at your own risk disable the checker (see sanity.conf).
    Following is the list of potential problems / advisories:

    Your Python 3 is not a full install. Please install the module distutils.sysconfig (see the Getting Started guide for further information).


Summary: There was 1 WARNING message shown.
Summary: There was 1 ERROR message shown, returning a non-zero exit code.



3.10 부터 패키지 명칭이 바뀌어서 그런일이 생기는 듯

For version 3.10 or above –

from collections.abc import MutableMapping
For version 3.9 or lower –

from collections import MutableMapping

[링크 : https://stackoverflow.com/questions/70943244/attributeerror-module-collections-has-no-attribute-mutablemapping]



+

걍 docker 쓸까..

[링크 :https://github.com/nxp-imx/imx-docker]

'프로그램 사용 > yocto project' 카테고리의 다른 글

bitbake --help  (0) 2023.08.29
Do not use Bitbake as root.  (0) 2023.08.28
imx8 yocto build on ubuntu 22.04  (0) 2023.02.10
라즈베리 파이 with yocto project  (2) 2015.07.30
yocto project 구조  (0) 2015.07.29
Posted by 구차니

$# 인자의 갯수

$@ 현재 타겟의 이름 (나열)

$* 현재 타겟의 이름 (하나로)

$^ 현재 타겟의 종속 항목 리스트

[링크 : https://yooloo.tistory.com/m/131]

[링크 : https://bowbowbow.tistory.com/12]

'프로그램 사용 > make, configure' 카테고리의 다른 글

make 조건식  (0) 2023.08.16
cmake ninja, cmake 옵션주기  (0) 2022.12.07
cmake 옵션 확인  (0) 2021.01.20
cmake 빌드 에러시  (0) 2021.01.19
make order  (0) 2016.06.16
Posted by 구차니

지시자. 그러니까 아래서 make foo로 시작하는 부분에 대해서는

조건식이 없는걸로 봐서는 그 이전에 미리 조건식에 의해서 분기를 처리하고

그 아래에서는 조건식 없이 해야 하는건가?



libs_for_gcc = -lgnu
normal_libs =

ifeq ($(CC),gcc)
  libs=$(libs_for_gcc)
else
  libs=$(normal_libs)
endif

foo: $(objects)
        $(CC) -o foo $(objects) $(libs)

[링크 : https://www.gnu.org/software/make/manual/html_node/Conditional-Example.html]

    [링크 : https://www.gnu.org/software/make/manual/html_node/Conditionals.html]







'프로그램 사용 > make, configure' 카테고리의 다른 글

makefile 매크로(?)  (0) 2023.08.28
cmake ninja, cmake 옵션주기  (0) 2022.12.07
cmake 옵션 확인  (0) 2021.01.20
cmake 빌드 에러시  (0) 2021.01.19
make order  (0) 2016.06.16
Posted by 구차니
프로그램 사용/gcc2023. 8. 8. 11:17

문득 cpu 사양 다시 볼까? 싶어서 보니

어? NEON이 아니라 NEON MPE?

NEON™ media-processing engine
Single and double precision Vector Floating Point Unit (VFPU)

[링크 : https://docs.xilinx.com/v/u/en-US/ds190-Zynq-7000-Overview]



그래서 cortex-A9 NEON MPE 명령을 뒤져보는데

VADD나 VSUB VMUL VDIV에 대해서 찾아보니 NEON으로는 float까지만 되도, double은 VFP를 통해서 가능할 것 같은데

D
Double precision floating-point values

F
Single precision floating-point values

H
Half precision floating-point values

I
Integer values

P
Polynomials with single-bit coefficients

X
Operation is independent of data representation.


Name Advanced SIMD VFP Description
VADD I, F F, D Add
VDIV - F, D Divide
VMUL I, F, P F, D Multiply
VSUB I, F F, D Subtract

[링크 : https://developer.arm.com/documentation/ddi0409/i/instruction-timing/cortex-a9-neon-mpe-instructions?lang=en]

타입을 바꾸어 봐도 안되서 골머리를 싸매다가(float는 된다매!!! double은 vfp로 된다매!!!)

main.c:187:2: missed: couldn't vectorize loop
main.c:177:6: missed: not vectorized: unsupported data-type double


main.c:187:2: missed: couldn't vectorize loop
main.c:177:6: missed: not vectorized: unsupported data-type float



금단의 플래그를 설정하니 잘 된다. -_-

main.c:194:2: optimized: loop vectorized using 16 byte vectors
main.c:188:2: optimized: loop vectorized using 16 byte vectors



IEEE를 무시하고 안전하지 않은 연산도 적용되고 하다보니 영 쓰기가 불안한데...

In addition GCC offers the -ffast-math flag which is a shortcut for several options, presenting the least conforming but fastest math mode. It enables -fno-trapping-math, -funsafe-math-optimizations, -ffinite-math-only, -fno-errno-math, -fno-signaling-nans, -fno-rounding-math, -fcx-limited-range and -fno-signed-zeros. Each of these flags violates IEEE in a different way. -ffast-math also may disable some features of the hardware IEEE implementation such as the support for denormals or flush-to-zero behavior. An example for such a case is x86_64 with it's use of SSE and SSE2 units for floating point math.

[링크 : https://gcc.gnu.org/wiki/FloatingPointMath]


아무튼 어제 어디서 보다 찾았던 associative 옵션을 못찾아서 헤매다가 다시 생각나서 보는데

associative하지 않다.. 이게 무슨 의미지?

Goldberg 논문에 나온 것 처럼 floating-point의 계산은 associative하지 않다.
그러므로 ffast-math 연산 방식에서는 실제 값에 오류를 포함할 수 밖에 없다.
이러한 점 때문에 ffast-math 방식은 IEEE에서 정의한 방식을 따르지 못한다.

위와 같은 특징 때문에, 정확한 값을 계산해야하는 것이라면 ffast-math를 사용하면 안된다.
하지만 대충 어림잡아서 맞는 값을 원하는 것이라면?

[링크 : https://www.cv-learn.com/20210107-gcc-ffast-math/]


float 형의 오차로 인해서 계산때 마다 동일 결과가 나오지 않는다는 의미군..

결합의((a × b) × c = a × (b × c)의 예에서처럼 계산식이 부분의 순서와 상관없이 동일한 결과가 나오는)

[링크 : https://en.dict.naver.com/#/entry/enko/43a6bbaaacf546199c5d4c57b6b88ebb]


그래서 한번 -ffast-math 대신 적용해보려는데 다른 상위 옵션에 의해서 무시 당했다고 나온다.

누가 상위 옵션이려나?

-o -W -Wall -fopt-info-vec -march=armv7-a -mfpu=neon -O3 -fassociative-math

cc1: warning: ‘-fassociative-math’ disabled; other options take precedence


-ffast-math 보단 순한 맛이긴 한데 적용이 안되면 의미 없지 머..

-fassociative-math
Allow re-association of operands in series of floating-point operations. This violates the ISO C and C++ language standard by possibly changing computation result. NOTE: re-ordering may change the sign of zero as well as ignore NaNs and inhibit or create underflow or overflow (and thus cannot be used on code that relies on rounding behavior like (x + 2**52) - 2**52. May also reorder floating-point comparisons and thus may not be used when ordered comparisons are required. This option requires that both -fno-signed-zeros and -fno-trapping-math be in effect. Moreover, it doesn’t make much sense with -frounding-math. For Fortran the option is automatically enabled when both -fno-signed-zeros and -fno-trapping-math are in effect.

The default is -fno-associative-math.

[링크 : https://gcc.gnu.org/onlinedocs/gcc/Optimize-Options.html]

'프로그램 사용 > gcc' 카테고리의 다른 글

gcc tree vectorize  (0) 2023.01.26
gcc fstack-protector-strong  (0) 2022.12.06
gcc vectorization 실패  (0) 2022.06.02
gcc / 문자열 선언  (0) 2022.03.17
static link  (0) 2022.02.07
Posted by 구차니

엑셀은 간단했는데 ㅠㅠ



중복 제거할 영역 선택
상단 메뉴에서 'Data > More Filters > Standard Filter...' 선택
필드 이름을 '-none-'으로 변경, 하단 'Options > No duplications' 체크
중복 제거 확인

[링크 : https://davelogs.tistory.com/103]

Posted by 구차니

libreoffice 에서 그래프 그리는데 버벅대서 찾아보다 보니 openCL 로 가속이 가능하다고 한다.

[링크 : https://hamonikr.org/board_bFBk25/54522]



근데 정작 그래프 그리는데에는 도움이 안된다.

그냥 셀들 계산이 많을때는 도움이 될 듯.





-----

설정 뒤져보니 OpenCL 선택사항이라는게 있는데

OpenCL 사용 가능한 상황이라면, 아래에서 "OpenCL 사용 허용" 에 체크하고 적용 혹은 확인 누르면



libreoffice 다시 시작 하냐고 물어보는데 다시시작하고



설정을 보면 OpenCL을 사용할 수 있습니다로 바뀐다.



물론 그전에 OpenCL 이 사용가능한지 확인하고 설치해야 한다.

clinfo 실행해서 Number of platforms 가 0이 뜨면 OpenCL 사용 불가능한 상태

$ sudo apt install clinfo
$ clinfo
Number of platforms                               0

[링크 : https://ask.libreoffice.org/t/unable-to-activate-opencl/45714/3]


intel 10세대 노트북에 내장형 밖에 없어서 intel opencl을 설치해준다.

$ sudo add-apt-repository ppa:intel-opencl/intel-opencl
$ sudo apt-get update
$ sudo apt install intel-opencl-icd

[링크 : https://marcokhan.tistory.com/250]


clinfo 실행하면 Number of platforms에 1이 딱!

$ clinfo
Number of platforms                               1
  Platform Name                                   Intel(R) OpenCL HD Graphics
  Platform Vendor                                 Intel(R) Corporation
  Platform Version                                OpenCL 3.0
  Platform Profile                                FULL_PROFILE
  Platform Extensions                             cl_khr_byte_addressable_store cl_khr_fp16 cl_khr_global_int32_base_atomics cl_khr_global_int32_extended_atomics cl_khr_icd cl_khr_local_int32_base_atomics cl_khr_local_int32_extended_atomics cl_intel_command_queue_families cl_intel_subgroups cl_intel_required_subgroup_size cl_intel_subgroups_short cl_khr_spir cl_intel_accelerator cl_intel_driver_diagnostics cl_khr_priority_hints cl_khr_throttle_hints cl_khr_create_command_queue cl_intel_subgroups_char cl_intel_subgroups_long cl_khr_il_program cl_intel_mem_force_host_memory cl_khr_subgroup_extended_types cl_khr_subgroup_non_uniform_vote cl_khr_subgroup_ballot cl_khr_subgroup_non_uniform_arithmetic cl_khr_subgroup_shuffle cl_khr_subgroup_shuffle_relative cl_khr_subgroup_clustered_reduce cl_intel_device_attribute_query cl_khr_suggested_local_work_size cl_khr_fp64 cl_khr_subgroups cl_intel_spirv_device_side_avc_motion_estimation cl_intel_spirv_media_block_io cl_intel_spirv_subgroups cl_khr_spirv_no_integer_wrap_decoration cl_intel_unified_shared_memory cl_khr_mipmap_image cl_khr_mipmap_image_writes cl_intel_planar_yuv cl_intel_packed_yuv cl_intel_motion_estimation cl_intel_device_side_avc_motion_estimation cl_intel_advanced_motion_estimation cl_khr_int64_base_atomics cl_khr_int64_extended_atomics cl_khr_image2d_from_buffer cl_khr_depth_images cl_khr_3d_image_writes cl_intel_media_block_io cl_intel_va_api_media_sharing cl_intel_sharing_format_query cl_khr_pci_bus_info
  Platform Extensions with Version                cl_khr_byte_addressable_store                                    0x400000 (1.0.0)
                                                  cl_khr_fp16                                                      0x400000 (1.0.0)
                                                  cl_khr_global_int32_base_atomics                                 0x400000 (1.0.0)
                                                  cl_khr_global_int32_extended_atomics                             0x400000 (1.0.0)
                                                  cl_khr_icd                                                       0x400000 (1.0.0)
                                                  cl_khr_local_int32_base_atomics                                  0x400000 (1.0.0)
                                                  cl_khr_local_int32_extended_atomics                              0x400000 (1.0.0)
                                                  cl_intel_command_queue_families                                  0x400000 (1.0.0)
                                                  cl_intel_subgroups                                               0x400000 (1.0.0)
                                                  cl_intel_required_subgroup_size                                  0x400000 (1.0.0)
                                                  cl_intel_subgroups_short                                         0x400000 (1.0.0)
                                                  cl_khr_spir                                                      0x400000 (1.0.0)
                                                  cl_intel_accelerator                                             0x400000 (1.0.0)
                                                  cl_intel_driver_diagnostics                                      0x400000 (1.0.0)
                                                  cl_khr_priority_hints                                            0x400000 (1.0.0)
                                                  cl_khr_throttle_hints                                            0x400000 (1.0.0)
                                                  cl_khr_create_command_queue                                      0x400000 (1.0.0)
                                                  cl_intel_subgroups_char                                          0x400000 (1.0.0)
                                                  cl_intel_subgroups_long                                          0x400000 (1.0.0)
                                                  cl_khr_il_program                                                0x400000 (1.0.0)
                                                  cl_intel_mem_force_host_memory                                   0x400000 (1.0.0)
                                                  cl_khr_subgroup_extended_types                                   0x400000 (1.0.0)
                                                  cl_khr_subgroup_non_uniform_vote                                 0x400000 (1.0.0)
                                                  cl_khr_subgroup_ballot                                           0x400000 (1.0.0)
                                                  cl_khr_subgroup_non_uniform_arithmetic                           0x400000 (1.0.0)
                                                  cl_khr_subgroup_shuffle                                          0x400000 (1.0.0)
                                                  cl_khr_subgroup_shuffle_relative                                 0x400000 (1.0.0)
                                                  cl_khr_subgroup_clustered_reduce                                 0x400000 (1.0.0)
                                                  cl_intel_device_attribute_query                                  0x400000 (1.0.0)
                                                  cl_khr_suggested_local_work_size                                 0x400000 (1.0.0)
                                                  cl_khr_fp64                                                      0x400000 (1.0.0)
                                                  cl_khr_subgroups                                                 0x400000 (1.0.0)
                                                  cl_intel_spirv_device_side_avc_motion_estimation                 0x400000 (1.0.0)
                                                  cl_intel_spirv_media_block_io                                    0x400000 (1.0.0)
                                                  cl_intel_spirv_subgroups                                         0x400000 (1.0.0)
                                                  cl_khr_spirv_no_integer_wrap_decoration                          0x400000 (1.0.0)
                                                  cl_intel_unified_shared_memory                                   0x400000 (1.0.0)
                                                  cl_khr_mipmap_image                                              0x400000 (1.0.0)
                                                  cl_khr_mipmap_image_writes                                       0x400000 (1.0.0)
                                                  cl_intel_planar_yuv                                              0x400000 (1.0.0)
                                                  cl_intel_packed_yuv                                              0x400000 (1.0.0)
                                                  cl_intel_motion_estimation                                       0x400000 (1.0.0)
                                                  cl_intel_device_side_avc_motion_estimation                       0x400000 (1.0.0)
                                                  cl_intel_advanced_motion_estimation                              0x400000 (1.0.0)
                                                  cl_khr_int64_base_atomics                                        0x400000 (1.0.0)
                                                  cl_khr_int64_extended_atomics                                    0x400000 (1.0.0)
                                                  cl_khr_image2d_from_buffer                                       0x400000 (1.0.0)
                                                  cl_khr_depth_images                                              0x400000 (1.0.0)
                                                  cl_khr_3d_image_writes                                           0x400000 (1.0.0)
                                                  cl_intel_media_block_io                                          0x400000 (1.0.0)
                                                  cl_intel_va_api_media_sharing                                    0x400000 (1.0.0)
                                                  cl_intel_sharing_format_query                                    0x400000 (1.0.0)
                                                  cl_khr_pci_bus_info                                              0x400000 (1.0.0)
  Platform Numeric Version                        0xc00000 (3.0.0)
  Platform Extensions function suffix             INTEL
  Platform Host timer resolution                  1ns

  Platform Name                                   Intel(R) OpenCL HD Graphics
Number of devices                                 1
  Device Name                                     Intel(R) UHD Graphics [0x9b41]
  Device Vendor                                   Intel(R) Corporation
  Device Vendor ID                                0x8086
  Device Version                                  OpenCL 3.0 NEO
  Device Numeric Version                          0xc00000 (3.0.0)
  Driver Version                                  1.0.0
  Device OpenCL C Version                         OpenCL C 1.2
  Device OpenCL C all versions                    OpenCL C                                                         0x400000 (1.0.0)
                                                  OpenCL C                                                         0x401000 (1.1.0)
                                                  OpenCL C                                                         0x402000 (1.2.0)
                                                  OpenCL C                                                         0xc00000 (3.0.0)
  Device OpenCL C features                        __opencl_c_int64                                                 0xc00000 (3.0.0)
                                                  __opencl_c_3d_image_writes                                       0xc00000 (3.0.0)
                                                  __opencl_c_images                                                0xc00000 (3.0.0)
                                                  __opencl_c_read_write_images                                     0xc00000 (3.0.0)
                                                  __opencl_c_atomic_order_acq_rel                                  0xc00000 (3.0.0)
                                                  __opencl_c_atomic_order_seq_cst                                  0xc00000 (3.0.0)
                                                  __opencl_c_atomic_scope_all_devices                              0xc00000 (3.0.0)
                                                  __opencl_c_atomic_scope_device                                   0xc00000 (3.0.0)
                                                  __opencl_c_generic_address_space                                 0xc00000 (3.0.0)
                                                  __opencl_c_program_scope_global_variables                        0xc00000 (3.0.0)
                                                  __opencl_c_work_group_collective_functions                       0xc00000 (3.0.0)
                                                  __opencl_c_subgroups                                             0xc00000 (3.0.0)
                                                  __opencl_c_pipes                                                 0xc00000 (3.0.0)
                                                  __opencl_c_fp64                                                  0xc00000 (3.0.0)
  Latest comfornace test passed                   v2021-06-16-00
  Device Type                                     GPU
  Device Profile                                  FULL_PROFILE
  Device Available                                Yes
  Compiler Available                              Yes
  Linker Available                                Yes
  Max compute units                               24
  Max clock frequency                             1150MHz
  Device Partition                                (core)
    Max number of sub-devices                     0
    Supported partition types                     None
    Supported affinity domains                    (n/a)
  Max work item dimensions                        3
  Max work item sizes                             256x256x256
  Max work group size                             256
  Preferred work group size multiple (device)     32
  Preferred work group size multiple (kernel)     32
  Max sub-groups per work group                   32
  Sub-group sizes (Intel)                         8, 16, 32
  Preferred / native vector sizes
    char                                                16 / 16
    short                                                8 / 8
    int                                                  4 / 4
    long                                                 1 / 1
    half                                                 8 / 8        (cl_khr_fp16)
    float                                                1 / 1
    double                                               1 / 1        (cl_khr_fp64)
  Half-precision Floating-point support           (cl_khr_fp16)
    Denormals                                     Yes
    Infinity and NANs                             Yes
    Round to nearest                              Yes
    Round to zero                                 Yes
    Round to infinity                             Yes
    IEEE754-2008 fused multiply-add               Yes
    Support is emulated in software               No
  Single-precision Floating-point support         (core)
    Denormals                                     Yes
    Infinity and NANs                             Yes
    Round to nearest                              Yes
    Round to zero                                 Yes
    Round to infinity                             Yes
    IEEE754-2008 fused multiply-add               Yes
    Support is emulated in software               No
    Correctly-rounded divide and sqrt operations  Yes
  Double-precision Floating-point support         (cl_khr_fp64)
    Denormals                                     Yes
    Infinity and NANs                             Yes
    Round to nearest                              Yes
    Round to zero                                 Yes
    Round to infinity                             Yes
    IEEE754-2008 fused multiply-add               Yes
    Support is emulated in software               No
  Address bits                                    64, Little-Endian
  Global memory size                              13228806144 (12.32GiB)
  Error Correction support                        No
  Max memory allocation                           4294959104 (4GiB)
  Unified memory for Host and Device              Yes
  Shared Virtual Memory (SVM) capabilities        (core)
    Coarse-grained buffer sharing                 Yes
    Fine-grained buffer sharing                   No
    Fine-grained system sharing                   No
    Atomics                                       No
  Minimum alignment for any data type             128 bytes
  Alignment of base address                       1024 bits (128 bytes)
  Preferred alignment for atomics
    SVM                                           64 bytes
    Global                                        64 bytes
    Local                                         64 bytes
  Atomic memory capabilities                      relaxed, acquire/release, sequentially-consistent, work-group scope, device scope, all-devices scope
  Atomic fence capabilities                       relaxed, acquire/release, sequentially-consistent, work-item scope, work-group scope, device scope, all-devices scope
  Max size for global variable                    65536 (64KiB)
  Preferred total size of global vars             4294959104 (4GiB)
  Global Memory cache type                        Read/Write
  Global Memory cache size                        524288 (512KiB)
  Global Memory cache line size                   64 bytes
  Image support                                   Yes
    Max number of samplers per kernel             16
    Max size for 1D images from buffer            268434944 pixels
    Max 1D or 2D image array size                 2048 images
    Base address alignment for 2D image buffers   4 bytes
    Pitch alignment for 2D image buffers          4 pixels
    Max 2D image size                             16384x16384 pixels
    Max planar YUV image size                     16384x16352 pixels
    Max 3D image size                             16384x16384x2048 pixels
    Max number of read image args                 128
    Max number of write image args                128
    Max number of read/write image args           128
  Pipe support                                    Yes
  Max number of pipe args                         16
  Max active pipe reservations                    1
  Max pipe packet size                            1024
  Local memory type                               Local
  Local memory size                               65536 (64KiB)
  Max number of constant args                     8
  Max constant buffer size                        4294959104 (4GiB)
  Generic address space support                   Yes
  Max size of kernel argument                     2048 (2KiB)
  Queue properties (on host)
    Out-of-order execution                        Yes
    Profiling                                     Yes
  Device enqueue capabilities                     (n/a)
  Queue properties (on device)
    Out-of-order execution                        No
    Profiling                                     No
    Preferred size                                0
    Max size                                      0
  Max queues on device                            0
  Max events on device                            0
  Prefer user sync for interop                    Yes
  Profiling timer resolution                      83ns
  Execution capabilities
    Run OpenCL kernels                            Yes
    Run native kernels                            No
    Non-uniform work-groups                       Yes
    Work-group collective functions               Yes
    Sub-group independent forward progress        Yes
    IL version                                    SPIR-V_1.2
    ILs with version                              SPIR-V                                                           0x402000 (1.2.0)
    SPIR versions                                 1.2
  printf() buffer size                            4194304 (4MiB)
  Built-in kernels                                block_motion_estimate_intel;block_advanced_motion_estimate_check_intel;block_advanced_motion_estimate_bidirectional_check_intel;
  Built-in kernels with version                   block_motion_estimate_intel                                      0x400000 (1.0.0)
                                                  block_advanced_motion_estimate_check_intel                       0x400000 (1.0.0)
                                                  block_advanced_motion_estimate_bidirectional_check_intel         0x400000 (1.0.0)
  Motion Estimation accelerator version (Intel)   2
    Device-side AVC Motion Estimation version     1
      Supports texture sampler use                Yes
      Supports preemption                         No
  Device Extensions                               cl_khr_byte_addressable_store cl_khr_fp16 cl_khr_global_int32_base_atomics cl_khr_global_int32_extended_atomics cl_khr_icd cl_khr_local_int32_base_atomics cl_khr_local_int32_extended_atomics cl_intel_command_queue_families cl_intel_subgroups cl_intel_required_subgroup_size cl_intel_subgroups_short cl_khr_spir cl_intel_accelerator cl_intel_driver_diagnostics cl_khr_priority_hints cl_khr_throttle_hints cl_khr_create_command_queue cl_intel_subgroups_char cl_intel_subgroups_long cl_khr_il_program cl_intel_mem_force_host_memory cl_khr_subgroup_extended_types cl_khr_subgroup_non_uniform_vote cl_khr_subgroup_ballot cl_khr_subgroup_non_uniform_arithmetic cl_khr_subgroup_shuffle cl_khr_subgroup_shuffle_relative cl_khr_subgroup_clustered_reduce cl_intel_device_attribute_query cl_khr_suggested_local_work_size cl_khr_fp64 cl_khr_subgroups cl_intel_spirv_device_side_avc_motion_estimation cl_intel_spirv_media_block_io cl_intel_spirv_subgroups cl_khr_spirv_no_integer_wrap_decoration cl_intel_unified_shared_memory cl_khr_mipmap_image cl_khr_mipmap_image_writes cl_intel_planar_yuv cl_intel_packed_yuv cl_intel_motion_estimation cl_intel_device_side_avc_motion_estimation cl_intel_advanced_motion_estimation cl_khr_int64_base_atomics cl_khr_int64_extended_atomics cl_khr_image2d_from_buffer cl_khr_depth_images cl_khr_3d_image_writes cl_intel_media_block_io cl_intel_va_api_media_sharing cl_intel_sharing_format_query cl_khr_pci_bus_info
  Device Extensions with Version                  cl_khr_byte_addressable_store                                    0x400000 (1.0.0)
                                                  cl_khr_fp16                                                      0x400000 (1.0.0)
                                                  cl_khr_global_int32_base_atomics                                 0x400000 (1.0.0)
                                                  cl_khr_global_int32_extended_atomics                             0x400000 (1.0.0)
                                                  cl_khr_icd                                                       0x400000 (1.0.0)
                                                  cl_khr_local_int32_base_atomics                                  0x400000 (1.0.0)
                                                  cl_khr_local_int32_extended_atomics                              0x400000 (1.0.0)
                                                  cl_intel_command_queue_families                                  0x400000 (1.0.0)
                                                  cl_intel_subgroups                                               0x400000 (1.0.0)
                                                  cl_intel_required_subgroup_size                                  0x400000 (1.0.0)
                                                  cl_intel_subgroups_short                                         0x400000 (1.0.0)
                                                  cl_khr_spir                                                      0x400000 (1.0.0)
                                                  cl_intel_accelerator                                             0x400000 (1.0.0)
                                                  cl_intel_driver_diagnostics                                      0x400000 (1.0.0)
                                                  cl_khr_priority_hints                                            0x400000 (1.0.0)
                                                  cl_khr_throttle_hints                                            0x400000 (1.0.0)
                                                  cl_khr_create_command_queue                                      0x400000 (1.0.0)
                                                  cl_intel_subgroups_char                                          0x400000 (1.0.0)
                                                  cl_intel_subgroups_long                                          0x400000 (1.0.0)
                                                  cl_khr_il_program                                                0x400000 (1.0.0)
                                                  cl_intel_mem_force_host_memory                                   0x400000 (1.0.0)
                                                  cl_khr_subgroup_extended_types                                   0x400000 (1.0.0)
                                                  cl_khr_subgroup_non_uniform_vote                                 0x400000 (1.0.0)
                                                  cl_khr_subgroup_ballot                                           0x400000 (1.0.0)
                                                  cl_khr_subgroup_non_uniform_arithmetic                           0x400000 (1.0.0)
                                                  cl_khr_subgroup_shuffle                                          0x400000 (1.0.0)
                                                  cl_khr_subgroup_shuffle_relative                                 0x400000 (1.0.0)
                                                  cl_khr_subgroup_clustered_reduce                                 0x400000 (1.0.0)
                                                  cl_intel_device_attribute_query                                  0x400000 (1.0.0)
                                                  cl_khr_suggested_local_work_size                                 0x400000 (1.0.0)
                                                  cl_khr_fp64                                                      0x400000 (1.0.0)
                                                  cl_khr_subgroups                                                 0x400000 (1.0.0)
                                                  cl_intel_spirv_device_side_avc_motion_estimation                 0x400000 (1.0.0)
                                                  cl_intel_spirv_media_block_io                                    0x400000 (1.0.0)
                                                  cl_intel_spirv_subgroups                                         0x400000 (1.0.0)
                                                  cl_khr_spirv_no_integer_wrap_decoration                          0x400000 (1.0.0)
                                                  cl_intel_unified_shared_memory                                   0x400000 (1.0.0)
                                                  cl_khr_mipmap_image                                              0x400000 (1.0.0)
                                                  cl_khr_mipmap_image_writes                                       0x400000 (1.0.0)
                                                  cl_intel_planar_yuv                                              0x400000 (1.0.0)
                                                  cl_intel_packed_yuv                                              0x400000 (1.0.0)
                                                  cl_intel_motion_estimation                                       0x400000 (1.0.0)
                                                  cl_intel_device_side_avc_motion_estimation                       0x400000 (1.0.0)
                                                  cl_intel_advanced_motion_estimation                              0x400000 (1.0.0)
                                                  cl_khr_int64_base_atomics                                        0x400000 (1.0.0)
                                                  cl_khr_int64_extended_atomics                                    0x400000 (1.0.0)
                                                  cl_khr_image2d_from_buffer                                       0x400000 (1.0.0)
                                                  cl_khr_depth_images                                              0x400000 (1.0.0)
                                                  cl_khr_3d_image_writes                                           0x400000 (1.0.0)
                                                  cl_intel_media_block_io                                          0x400000 (1.0.0)
                                                  cl_intel_va_api_media_sharing                                    0x400000 (1.0.0)
                                                  cl_intel_sharing_format_query                                    0x400000 (1.0.0)
                                                  cl_khr_pci_bus_info                                              0x400000 (1.0.0)

NULL platform behavior
  clGetPlatformInfo(NULL, CL_PLATFORM_NAME, ...)  Intel(R) OpenCL HD Graphics
  clGetDeviceIDs(NULL, CL_DEVICE_TYPE_ALL, ...)   Success [INTEL]
  clCreateContext(NULL, ...) [default]            Success [INTEL]
  clCreateContextFromType(NULL, CL_DEVICE_TYPE_DEFAULT)  Success (1)
    Platform Name                                 Intel(R) OpenCL HD Graphics
    Device Name                                   Intel(R) UHD Graphics [0x9b41]
  clCreateContextFromType(NULL, CL_DEVICE_TYPE_CPU)  No devices found in platform
  clCreateContextFromType(NULL, CL_DEVICE_TYPE_GPU)  Success (1)
    Platform Name                                 Intel(R) OpenCL HD Graphics
    Device Name                                   Intel(R) UHD Graphics [0x9b41]
  clCreateContextFromType(NULL, CL_DEVICE_TYPE_ACCELERATOR)  No devices found in platform
  clCreateContextFromType(NULL, CL_DEVICE_TYPE_CUSTOM)  No devices found in platform
  clCreateContextFromType(NULL, CL_DEVICE_TYPE_ALL)  Success (1)
    Platform Name                                 Intel(R) OpenCL HD Graphics
    Device Name                                   Intel(R) UHD Graphics [0x9b41]

ICD loader properties
  ICD loader Name                                 OpenCL ICD Loader
  ICD loader Vendor                               OCL Icd free software
  ICD loader Version                              2.2.14
  ICD loader Profile                              OpenCL 3.0
Posted by 구차니
프로그램 사용/iperf2023. 7. 28. 11:52

iperf/iperf2/ipef3 간에는 서로 호환성이 없는 듯. 기본 포트도 다르게 잡힌다.



크로스 컴파일

/configure --build=i686-linux --host=arm-linux CC={크로스 컴파일러GCC 경로} CXX={크로스 컴파일러G++ 경로}

[링크 : http://forum.falinux.com/zbxe/index.php?document_srl=869098&mid=lecture_tip]



대역폭 설정은 초당 얼마나 많은 데이터를 보내냐를 테스트 하는데 쓰이는데

$ iperf3 --help
Usage: iperf3 [-s|-c host] [options]
       iperf3 [-h|--help] [-v|--version]

Server or Client:
  -p, --port      #         server port to listen on/connect to
  -f, --format   [kmgtKMGT] format to report: Kbits, Mbits, Gbits, Tbits
  -i, --interval  #         seconds between periodic throughput reports
  -F, --file name           xmit/recv the specified file
  -A, --affinity n/n,m      set CPU affinity
  -B, --bind      <host>    bind to the interface associated with the address <host>
  -V, --verbose             more detailed output
  -J, --json                output in JSON format
  --logfile f               send output to a log file
  --forceflush              force flushing output at every interval
  --timestamps    <format>  emit a timestamp at the start of each output line
                            (using optional format string as per strftime(3))
  -d, --debug               emit debugging output
  -v, --version             show version information and quit
  -h, --help                show this message and quit
Server specific:
  -s, --server              run in server mode
  -D, --daemon              run the server as a daemon
  -I, --pidfile file        write PID file
  -1, --one-off             handle one client connection then exit
  --server-bitrate-limit #[KMG][/#]   server's total bit rate limit (default 0 = no limit)
                            (optional slash and number of secs interval for averaging
                            total data rate.  Default is 5 seconds)
  --rsa-private-key-path    path to the RSA private key used to decrypt
                            authentication credentials
  --authorized-users-path   path to the configuration file containing user
                            credentials
Client specific:
  -c, --client    <host>    run in client mode, connecting to <host>
  --sctp                    use SCTP rather than TCP
  -X, --xbind <name>        bind SCTP association to links
  --nstreams      #         number of SCTP streams
  -u, --udp                 use UDP rather than TCP
  --connect-timeout #       timeout for control connection setup (ms)
  -b, --bitrate #[KMG][/#]  target bitrate in bits/sec (0 for unlimited)
                            (default 1 Mbit/sec for UDP, unlimited for TCP)
                            (optional slash and packet count for burst mode)
  --pacing-timer #[KMG]     set the timing for pacing, in microseconds (default 1000)
  --fq-rate #[KMG]          enable fair-queuing based socket pacing in
                            bits/sec (Linux only)
  -t, --time      #         time in seconds to transmit for (default 10 secs)
  -n, --bytes     #[KMG]    number of bytes to transmit (instead of -t)
  -k, --blockcount #[KMG]   number of blocks (packets) to transmit (instead of -t or -n)
  -l, --length    #[KMG]    length of buffer to read or write
                            (default 128 KB for TCP, dynamic or 1460 for UDP)
  --cport         <port>    bind to a specific client port (TCP and UDP, default: ephemeral port)
  -P, --parallel  #         number of parallel client streams to run
  -R, --reverse             run in reverse mode (server sends, client receives)
  --bidir                   run in bidirectional mode.
                            Client and server send and receive data.
  -w, --window    #[KMG]    set window size / socket buffer size
  -C, --congestion <algo>   set TCP congestion control algorithm (Linux and FreeBSD only)
  -M, --set-mss   #         set TCP/SCTP maximum segment size (MTU - 40 bytes)
  -N, --no-delay            set TCP/SCTP no delay, disabling Nagle's Algorithm
  -4, --version4            only use IPv4
  -6, --version6            only use IPv6
  -S, --tos N               set the IP type of service, 0-255.
                            The usual prefixes for octal and hex can be used,
                            i.e. 52, 064 and 0x34 all specify the same value.
  --dscp N or --dscp val    set the IP dscp value, either 0-63 or symbolic.
                            Numeric values can be specified in decimal,
                            octal and hex (see --tos above).
  -L, --flowlabel N         set the IPv6 flow label (only supported on Linux)
  -Z, --zerocopy            use a 'zero copy' method of sending data
  -O, --omit N              omit the first n seconds
  -T, --title str           prefix every output line with this string
  --extra-data str          data string to include in client and server JSON
  --get-server-output       get results from server
  --udp-counters-64bit      use 64-bit counters in UDP test packets
  --repeating-payload       use repeating pattern in payload, instead of
                            randomized payload (like in iperf2)
  --username                username for authentication
  --rsa-public-key-path     path to the RSA public key used to encrypt
                            authentication credentials

[KMG] indicates options that support a K/M/G suffix for kilo-, mega-, or giga-

iperf3 homepage at: https://software.es.net/iperf/
Report bugs to:     https://github.com/esnet/iperf



'프로그램 사용 > iperf' 카테고리의 다른 글

iperf udp 테스트  (0) 2022.03.14
iperf로 100M 랜 / IEEE1394 대역폭 측정  (2) 2011.12.07
iperf - 대역폭 측정  (0) 2009.10.22
Posted by 구차니
