쓸일이 곧 생길게야.... (동공지진)
[링크 : https://github.com/torvalds/linux/blob/master/tools/spi/spidev_test.c]
+ 2021.02.08
It's easy to be confused here, and the vendor documentation you'll
find isn't necessarily helpful. The four modes combine two mode bits:
- CPOL indicates the initial clock polarity. CPOL=0 means the
clock starts low, so the first (leading) edge is rising, and
the second (trailing) edge is falling. CPOL=1 means the clock
starts high, so the first (leading) edge is falling.
- CPHA indicates the clock phase used to sample data; CPHA=0 says
sample on the leading edge, CPHA=1 means the trailing edge.
Since the signal needs to stablize before it's sampled, CPHA=0
implies that its data is written half a clock before the first
clock edge. The chipselect may have made it become available.
[링크 : https://www.kernel.org/doc/Documentation/spi/spi-summary]
