embeded/FPGA - ALTERA2026. 11. 18. 21:42

최대 클럭은 아니고

de0-nano 에서 100Mhz 일단 시도한거

nios ii/e 가 150Mhz 에서 차력쑈 해서 5.50 BogoMIPS인데 8.8배나 빠르게 나온다. 캐시 늘리면 더 빨라지려나?

그런데 bogoMIPS가 8배나 차이나는것에 비해서는 그렇게 획기적으로 빠르진 않은 느낌.

/root # cat /proc/cpuinfo
CPU:            Nios II/f
MMU:            none
FPU:            none
Clocking:       100.00 MHz
BogoMips:       48.94
Calibration:    24473600 loops
HW:
 MUL:           yes
 MULX:          no
 DIV:           no
Icache:         4kB, line length: 32
Dcache:         2kB, line length: 32



부팅 엄청 빨리 끝나네

[    0.000000] Linux version 3.5.0-rc4 (root@DESKTOP-0000000) (gc[    0.880000] msgmni has been set to 58
[    0.890000] io scheduler noop registered (default)
[    0.890000] ttyAL0 at MMIO 0x10040 (irq = 3) is a Altera UART
[    0.900000] ttyJ0 at MMIO 0x10000 (irq = 0) is a Altera JTAG UART
[    0.900000] console [ttyJ0] enabled, bootconsole disabled
[    0.900000] console [ttyJ0] enabled, bootconsole disabled
[    0.910000] PPP generic driver version 2.4.2
[    0.910000] SLIP: version 0.8.4-NET3.019-NEWTTY (dynamic channels, max=256).
[    0.920000] TCP: cubic registered
[    0.920000] NET: Registered protocol family 17
[    0.940000] Freeing unused kernel memory: 624k freed (0x219f000 - 0x223b000)
DE0-Nano root filesystem ready; login as root (no password).
init started: BusyBox v1.18.4 (2026-11-17 08:09:33 KST)
starting pid 19, tty '/dev/ttyJ0': '/sbin/getty -L ttyJ0 115200 vt100'

DE0-Nano Nios II uClinux - local development console
de0-nano login: root
Jan  1 00:00:08 login[19]: root login on 'ttyJ0'


BusyBox v1.18.4 (2026-11-17 08:09:33 KST) hush - the humble shell
Enter 'help' for a list of built-in commands.

/root # dmesg
<5>[    0.000000] Linux version 3.5.0-rc4 (root@DESKTOP- 0000000) (gcc version 4.1.2) #23 Wed Nov 18 21:01:11 KST 2026
<6>[    0.000000] bootconsole [early0] enabled
<6>[    0.000000] early_console initialized at 0x80010000
<7>[    0.000000] On node 0 totalpages: 8192
<7>[    0.000000] free_area_init_node: node 0, pgdat 02288f14, node_mem_map 022977e0
<7>[    0.000000]   DMA zone: 64 pages used for memmap
<7>[    0.000000]   DMA zone: 0 pages reserved
<7>[    0.000000]   DMA zone: 8128 pages, LIFO batch:0
<7>[    0.000000] pcpu-alloc: s0 r0 d32768 u32768 alloc=1*32768
<7>[    0.000000] pcpu-alloc: [0] 0
<4>[    0.000000] Built 1 zonelists in Zone order, mobility grouping on.  Total pages: 8128
<5>[    0.000000] Kernel command line: console=ttyJ0,115200 loglevel=8 rdinit=/init
<6>[    0.000000] PID hash table entries: 128 (order: -3, 512 bytes)
<6>[    0.000000] Dentry cache hash table entries: 4096 (order: 2, 16384 bytes)
<6>[    0.000000] Inode-cache hash table entries: 2048 (order: 1, 8192 bytes)
<6>[    0.000000] Memory available: 29796k/2644k RAM (1658k kernel code, 986k data)
<6>[    0.000000] NR_IRQS:64
<6>[    0.100000] Calibrating delay loop... 48.94 BogoMIPS (lpj=244736)
<6>[    0.100000] pid_max: default: 32768 minimum: 301
<6>[    0.100000] Mount-cache hash table entries: 512
<6>[    0.130000] devtmpfs: initialized
<6>[    0.140000] NET: Registered protocol family 16
<6>[    0.180000] bio: create slab <bio-0> at 0
<6>[    0.190000] Switching to clocksource timer
<6>[    0.210000] NET: Registered protocol family 2
<6>[    0.220000] IP route cache hash table entries: 1024 (order: 0, 4096 bytes)
<6>[    0.220000] TCP established hash table entries: 1024 (order: 1, 8192 bytes)
<6>[    0.230000] TCP bind hash table entries: 1024 (order: 0, 4096 bytes)
<6>[    0.230000] TCP: Hash tables configured (established 1024 bind 1024)
<6>[    0.230000] TCP: reno registered
<6>[    0.230000] UDP hash table entries: 256 (order: 0, 4096 bytes)
<6>[    0.230000] UDP-Lite hash table entries: 256 (order: 0, 4096 bytes)
<6>[    0.230000] NET: Registered protocol family 1
<6>[    0.880000] msgmni has been set to 58
<6>[    0.890000] io scheduler noop registered (default)
<6>[    0.890000] ttyAL0 at MMIO 0x10040 (irq = 3) is a Altera UART
<6>[    0.900000] ttyJ0 at MMIO 0x10000 (irq = 0) is a Altera JTAG UART
<6>[    0.900000] console [ttyJ0] enabled, bootconsole disabled
<6>[    0.910000] PPP generic driver version 2.4.2
<6>[    0.910000] SLIP: version 0.8.4-NET3.019-NEWTTY (dynamic channels, max=256).
<6>[    0.920000] TCP: cubic registered
<6>[    0.920000] NET: Registered protocol family 17
<5>[    0.940000] Freeing unused kernel memory: 624k freed (0x219f000 - 0x223b000)
/root #





+

수치만 보면 어마어마한데, 체감은 여전히 느리다.

/root # cat /proc/cpuinfo
CPU:            Nios II/f
MMU:            none
FPU:            none
Clocking:       130.00 MHz
BogoMips:       63.89
Calibration:    31948800 loops
HW:
 MUL:           yes
 MULX:          no
 DIV:           no
Icache:         4kB, line length: 32
Dcache:         2kB, line length: 32

/root # dmesg
<5>[    0.000000] Linux version 3.5.0-rc4 (root@DESKTOP-0000000) (gcc version 4.1.2) #24 Wed Nov 18 22:10:48 KST 2026
<6>[    0.000000] bootconsole [early0] enabled
<6>[    0.000000] early_console initialized at 0x80010000
<7>[    0.000000] On node 0 totalpages: 8192
<7>[    0.000000] free_area_init_node: node 0, pgdat 02288f14, node_mem_map 022977e0
<7>[    0.000000]   DMA zone: 64 pages used for memmap
<7>[    0.000000]   DMA zone: 0 pages reserved
<7>[    0.000000]   DMA zone: 8128 pages, LIFO batch:0
<7>[    0.000000] pcpu-alloc: s0 r0 d32768 u32768 alloc=1*32768
<7>[    0.000000] pcpu-alloc: [0] 0
<4>[    0.000000] Built 1 zonelists in Zone order, mobility grouping on.  Total pages: 8128
<5>[    0.000000] Kernel command line: console=ttyJ0,115200 loglevel=8 rdinit=/init
<6>[    0.000000] PID hash table entries: 128 (order: -3, 512 bytes)
<6>[    0.000000] Dentry cache hash table entries: 4096 (order: 2, 16384 bytes)
<6>[    0.000000] Inode-cache hash table entries: 2048 (order: 1, 8192 bytes)
<6>[    0.000000] Memory available: 29796k/2644k RAM (1658k kernel code, 986k data)
<6>[    0.000000] NR_IRQS:64
<6>[    0.090000] Calibrating delay loop... 63.89 BogoMIPS (lpj=319488)
<6>[    0.090000] pid_max: default: 32768 minimum: 301
<6>[    0.090000] Mount-cache hash table entries: 512
<6>[    0.110000] devtmpfs: initialized
<6>[    0.130000] NET: Registered protocol family 16
<6>[    0.150000] bio: create slab <bio-0> at 0
<6>[    0.160000] Switching to clocksource timer
<6>[    0.180000] NET: Registered protocol family 2
<6>[    0.190000] IP route cache hash table entries: 1024 (order: 0, 4096 bytes)
<6>[    0.190000] TCP established hash table entries: 1024 (order: 1, 8192 bytes)
<6>[    0.190000] TCP bind hash table entries: 1024 (order: 0, 4096 bytes)
<6>[    0.190000] TCP: Hash tables configured (established 1024 bind 1024)
<6>[    0.190000] TCP: reno registered
<6>[    0.190000] UDP hash table entries: 256 (order: 0, 4096 bytes)
<6>[    0.190000] UDP-Lite hash table entries: 256 (order: 0, 4096 bytes)
<6>[    0.200000] NET: Registered protocol family 1
<6>[    0.720000] msgmni has been set to 58
<6>[    0.740000] io scheduler noop registered (default)
<6>[    0.740000] ttyAL0 at MMIO 0x10040 (irq = 3) is a Altera UART
<6>[    0.740000] ttyJ0 at MMIO 0x10000 (irq = 0) is a Altera JTAG UART
<6>[    0.740000] console [ttyJ0] enabled, bootconsole disabled
<6>[    0.750000] PPP generic driver version 2.4.2
<6>[    0.760000] SLIP: version 0.8.4-NET3.019-NEWTTY (dynamic channels, max=256).
<6>[    0.760000] TCP: cubic registered
<6>[    0.760000] NET: Registered protocol family 17
<5>[    0.770000] Freeing unused kernel memory: 624k freed (0x219f000 - 0x223b000)



+

극한으로 낮춰보기 ㅋㅋ

bogommips 는 여전히 높은데 체감은 그리 빠르지 않고

이건 jtag uart 쪽 문제인가..?

/root # cat /proc/cpuinfo
CPU:            Nios II/f
MMU:            none
FPU:            none
Clocking:       50.00 MHz
BogoMips:       24.01
Calibration:    12006400 loops
HW:
 MUL:           yes
 MULX:          no
 DIV:           no
Icache:         4kB, line length: 32
Dcache:         2kB, line length: 32

/root # dmesg
<5>[    0.000000] Linux version 3.5.0-rc4 (root@DESKTOP-0000000) (gcc version 4.1.2) #24 Wed Nov 18 22:56:40 KST 2026
<6>[    0.000000] bootconsole [early0] enabled
<6>[    0.000000] early_console initialized at 0x80010000
<7>[    0.000000] On node 0 totalpages: 8192
<7>[    0.000000] free_area_init_node: node 0, pgdat 02288f14, node_mem_map 022977e0
<7>[    0.000000]   DMA zone: 64 pages used for memmap
<7>[    0.000000]   DMA zone: 0 pages reserved
<7>[    0.000000]   DMA zone: 8128 pages, LIFO batch:0
<7>[    0.000000] pcpu-alloc: s0 r0 d32768 u32768 alloc=1*32768
<7>[    0.000000] pcpu-alloc: [0] 0
<4>[    0.000000] Built 1 zonelists in Zone order, mobility grouping on.  Total pages: 8128
<5>[    0.000000] Kernel command line: console=ttyJ0,115200 loglevel=8 rdinit=/init
<6>[    0.000000] PID hash table entries: 128 (order: -3, 512 bytes)
<6>[    0.000000] Dentry cache hash table entries: 4096 (order: 2, 16384 bytes)
<6>[    0.000000] Inode-cache hash table entries: 2048 (order: 1, 8192 bytes)
<6>[    0.000000] Memory available: 29796k/2644k RAM (1658k kernel code, 986k data)
<6>[    0.000000] NR_IRQS:64
<6>[    0.100000] Calibrating delay loop... 24.01 BogoMIPS (lpj=120064)
<6>[    0.110000] pid_max: default: 32768 minimum: 301
<6>[    0.120000] Mount-cache hash table entries: 512
<6>[    0.180000] devtmpfs: initialized
<6>[    0.210000] NET: Registered protocol family 16
<6>[    0.280000] bio: create slab <bio-0> at 0
<6>[    0.320000] Switching to clocksource timer
<6>[    0.370000] NET: Registered protocol family 2
<6>[    0.380000] IP route cache hash table entries: 1024 (order: 0, 4096 bytes)
<6>[    0.400000] TCP established hash table entries: 1024 (order: 1, 8192 bytes)
<6>[    0.410000] TCP bind hash table entries: 1024 (order: 0, 4096 bytes)
<6>[    0.410000] TCP: Hash tables configured (established 1024 bind 1024)
<6>[    0.410000] TCP: reno registered
<6>[    0.410000] UDP hash table entries: 256 (order: 0, 4096 bytes)
<6>[    0.410000] UDP-Lite hash table entries: 256 (order: 0, 4096 bytes)
<6>[    0.420000] NET: Registered protocol family 1
<6>[    1.720000] msgmni has been set to 58
<6>[    1.730000] io scheduler noop registered (default)
<6>[    1.750000] ttyAL0 at MMIO 0x10040 (irq = 3) is a Altera UART
<6>[    1.760000] ttyJ0 at MMIO 0x10000 (irq = 0) is a Altera JTAG UART
<6>[    1.760000] console [ttyJ0] enabled, bootconsole disabled
<6>[    1.790000] PPP generic driver version 2.4.2
<6>[    1.790000] SLIP: version 0.8.4-NET3.019-NEWTTY (dynamic channels, max=256).
<6>[    1.810000] TCP: cubic registered
<6>[    1.810000] NET: Registered protocol family 17
<5>[    1.850000] Freeing unused kernel memory: 624k freed (0x219f000 - 0x223b000)



platform designer에서 확인한 cpu

nios ii/f 가 활성화 가능! 이것이 라이센스의 위력!(무료, 무기한 ㅋㅋㅋ)



D-cache / I-cache 활성화 되었다. 이 설정의 위력인가?



산술 연산자 - nios ii/e 에서는 활성화 불가능했는데 이제 선택이 가능해진다



Divide hardware는 none / SRT Radix-2 라고 하는데 먼진 찾아봐야겠네.

그 와중에 35 사이클.. 어우.. 어셈을 봐서는 그냥 singed div 와 unsigned div 인듯?



MMU도 활성화 가능하다.

오.. 이정도면 uclinux가 아니라 linux가 올라갈수 있겠는데?
