$ gst-inspect-1.0 nveglglessink
Factory Details:
Rank secondary (128)
Long-name EGL/GLES vout Sink
Klass Sink/Video
Description An EGL/GLES Video Output Sink Implementing the VideoOverlay interface
Author Reynaldo H. Verdejo Pinochet <reynaldo@collabora.com>, Sebastian Dröge <sebastian.droege@collabora.co.uk>
Plugin Details:
Name nveglglessink
Description EGL/GLES sink
Filename /usr/lib/aarch64-linux-gnu/gstreamer-1.0/libgstnveglglessink.so
Version 1.2.3
License LGPL
Source module gst-plugins-bad
Source release date 2014-02-08
Binary package GStreamer Nvidia Bad Plug-ins source release
Origin URL Unknown package origin
GObject
+----GInitiallyUnowned
+----GstObject
+----GstElement
+----GstBaseSink
+----GstVideoSink
+----GstEglGlesSink
Implemented Interfaces:
GstVideoOverlay
Pad Templates:
SINK template: 'sink'
Availability: Always
Capabilities:
video/x-raw(memory:EGLImage)
format: { (string)RGBA, (string)BGRA, (string)ARGB, (string)ABGR, (string)RGBx, (string)BGRx, (string)xRGB, (string)xBGR, (string)AYUV, (string)Y444, (string)I420, (string)YV12, (string)NV12, (string)NV21, (string)Y42B, (string)Y41B, (string)RGB, (string)BGR, (string)RGB16 }
width: [ 1, 2147483647 ]
height: [ 1, 2147483647 ]
framerate: [ 0/1, 2147483647/1 ]
video/x-raw(meta:GstVideoGLTextureUploadMeta)
format: { (string)RGBA, (string)BGRA, (string)ARGB, (string)ABGR, (string)RGBx, (string)BGRx, (string)xRGB, (string)xBGR, (string)AYUV, (string)Y444, (string)I420, (string)YV12, (string)NV12, (string)NV21, (string)Y42B, (string)Y41B, (string)RGB, (string)BGR, (string)RGB16 }
width: [ 1, 2147483647 ]
height: [ 1, 2147483647 ]
framerate: [ 0/1, 2147483647/1 ]
video/x-raw
format: { (string)RGBA, (string)BGRA, (string)ARGB, (string)ABGR, (string)RGBx, (string)BGRx, (string)xRGB, (string)xBGR, (string)AYUV, (string)Y444, (string)I420, (string)YV12, (string)NV12, (string)NV21, (string)Y42B, (string)Y41B, (string)RGB, (string)BGR, (string)RGB16 }
width: [ 1, 2147483647 ]
height: [ 1, 2147483647 ]
framerate: [ 0/1, 2147483647/1 ]
video/x-raw(memory:NVMM)
format: { (string)BGRx, (string)RGBA, (string)I420, (string)NV12, (string)BGR, (string)RGB }
width: [ 1, 2147483647 ]
height: [ 1, 2147483647 ]
framerate: [ 0/1, 2147483647/1 ]
Element has no clocking capabilities.
Element has no URI handling capabilities.
Pads:
SINK: 'sink'
Pad Template: 'sink'
Element Properties:
name : The name of the object
flags: readable, writable
String. Default: "eglglessink0"
parent : The parent of the object
flags: readable, writable
Object of type "GstObject"
sync : Sync on the clock
flags: readable, writable
Boolean. Default: true
max-lateness : Maximum number of nanoseconds that a buffer can be late before it is dropped (-1 unlimited)
flags: readable, writable
Integer64. Range: -1 - 9223372036854775807 Default: 20000000
qos : Generate Quality-of-Service events upstream
flags: readable, writable
Boolean. Default: true
async : Go asynchronously to PAUSED
flags: readable, writable
Boolean. Default: true
ts-offset : Timestamp offset in nanoseconds
flags: readable, writable
Integer64. Range: -9223372036854775808 - 9223372036854775807 Default: 0
enable-last-sample : Enable the last-sample property
flags: readable, writable
Boolean. Default: true
last-sample : The last sample received in the sink
flags: readable
Boxed pointer of type "GstSample"
blocksize : Size in bytes to pull per buffer (0 = default)
flags: readable, writable
Unsigned Integer. Range: 0 - 4294967295 Default: 4096
render-delay : Additional render delay of the sink in nanoseconds
flags: readable, writable
Unsigned Integer64. Range: 0 - 18446744073709551615 Default: 0
throttle-time : The time to keep between rendered buffers (0 = disabled)
flags: readable, writable
Unsigned Integer64. Range: 0 - 18446744073709551615 Default: 0
max-bitrate : The maximum bits per second to render (0 = disabled)
flags: readable, writable
Unsigned Integer64. Range: 0 - 18446744073709551615 Default: 0
show-preroll-frame : Whether to render video frames during preroll
flags: readable, writable
Boolean. Default: true
create-window : If set to true, the sink will attempt to create it's own window to render to if none is provided. This is currently only supported when the sink is used under X11
flags: readable, writable
Boolean. Default: true
force-aspect-ratio : If set to true, the sink will attempt to preserve the incoming frame's geometry while scaling, taking both the storage's and display's pixel aspect ratio into account
flags: readable, writable
Boolean. Default: true
display : If set, the sink will use the passed X Display for rendering
flags: readable, writable
Pointer.
window-x : X coordinate of window
flags: readable, writable
Unsigned Integer. Range: 0 - 2147483647 Default: 10
window-y : Y coordinate of window
flags: readable, writable
Unsigned Integer. Range: 0 - 2147483647 Default: 10
window-width : Width of window
flags: readable, writable
Unsigned Integer. Range: 0 - 2147483647 Default: 0
window-height : Height of window
flags: readable, writable
Unsigned Integer. Range: 0 - 2147483647 Default: 0
rows : Rows of Display
flags: readable, writable
Unsigned Integer. Range: 1 - 2147483647 Default: 1
columns : Columns of display
flags: readable, writable
Unsigned Integer. Range: 1 - 2147483647 Default: 1
profile : gsteglglessink jitter information
flags: readable, writable
Unsigned Integer. Range: 0 - 4294967295 Default: 0
winsys : Takes in strings "x11" or "wayland" to specify the windowing system to be used
flags: readable, writable
String. Default: "x11"
bufapi-version : Set to use new buf API
flags: readable, writable
Boolean. Default: false |
