Applies to Windows installations CCSv4 and higher:

---------------------------------------------------

xds510usb and xd510usb_win64 files have been removed and replaced with signed

windows drivers and placed in:

Program Files\SpectrumDigital\Emulation\Drivers for 32-bit Windows and

Program Files (x86)\SpectrumDigital\Emulation\Drivers for 64-bit Windows

During the CCS installation process windows system level drivers are quietly

pre-installed.  On Vista, the system level drivers install may not succeed as

security checks may block the install.  When you plug in a USB HW device if

Vista does not automatically find the USB drivers then the install did not

succeed and you have two options:

1) When the install Wizard cannot find the drivers simply have the Wizard

search the directories listed above with the search subdirectory check box

checked.

2) Manually pre-install the drivers before plugging in the USB HW.

To do this use Explorer and go to the appropriate driver directory listed

above and the appropriate subdirectory, i386 for 32-bit Windows or amd64 for

64-bit Windows and run DPInst.exe.  If you are not sure if drivers were

pre-installed during the CCS install you can safely run DPInst.exe again.

Warning: Spectrum Digital XDS510USB drivers are included with the installation of CCS v4/v5

Deprecation notices:

The 32-bit version of Code Composer Studio for Linux is discontinued in favor of a 64-bit version since CCSv6.2.0.

Windows XP support is deprecated with the release of CCSv7.0.0.

Spectrum Digital XDS510USB JTAG debuggers are not supported with 64bit CCS installations. Currently this impacts Linux and MacOS.

Stellaris (LM3S and LM4F) devices are not supported starting with CCSv7.0.0.

Simply unzip and copy the License File for Older versions into <install dir>/ccs_base/DebugServer/license.

What is not supported

• Serial Wire Output for TPIU trace output


• Standard Console I/O operations (fread, fwrite, fopen, etc.) are not yet supported on the current release of CCS when using the on-board emulator

//=======================================================

//  Structural coding

//=======================================================

assign reset_n = 1'b1;

You need change in Pin Planner:

DRAM_LDQM to DRAM_DQM[0]

DRAM_UDQM to DRAM_DQM[1]

and

DRAM_BA_0 to DRAM_BA[0]

DRAM_BA_1 to DRAM_BA[1]

And then, you can assign these pins to your Nios II as buses.

DRAM_DQM[1..0]

DRAM_BA[1..0]

You must do this because Nios II in SOPC Builder 9.1 SP2 has buses for these connections to the SDRAM

Nios® II Boot from EPCQ or EPCS in Quartus® II 13.1

Workaround/Fix

3.      Make sure the Nios II’s Reset Vector is pointing at EPCS/EPCQ Controller.

Nios II Processor Application Copied from EPCS Flash to RAM Using Boot Copier

The EPCS address space is not mapped into the Altera Avalon EPCS Flash Controller’s Avalon MM slaveinterface. Instead, read or write accesses are done through CSRs. Upon system reset, the EPCS device needs to be initialized before usage.

For these reasons, the EPCS controller-based boot copier is required for initializing the EPCS device and copying the Nios II application to RAM for execution.

The EPCS controller instantiates a block of boot ROM internally at its base address (offset 0x0, just before EPCS controller’s CSRs) for storing the boot copier. Nios II reset vector offset must set to EPCS controller base address, such that upon system reset the boot copier is executed first to initialize the EPCS controller and device.

Info: 2018. 2. 3 오후 1:47:39 - (정보) elf2flash: args = --input=D:/Download/DE0_NANO/software/hello_world_0/hello_world_0.elf --output=D:/Download/DE0_NANO/software/hello_world_0_bsp/flash/hello_world_0_epcs_flash_controller_0.flash --epcs --verbose

Info: 2018. 2. 3 오후 1:47:39 - (미세) elf2flash: Starting

Info: 2018. 2. 3 오후 1:47:39 - (보다 미세) elf2flash: Program Record: 3964 bytes destined for 0x4008000

Info: 2018. 2. 3 오후 1:47:39 - (보다 미세) elf2flash: Program Record: 724 bytes destined for 0x4009250

Info: 2018. 2. 3 오후 1:47:39 - (보다 미세) elf2flash: Start Record: 4008020

Info: 2018. 2. 3 오후 1:47:39 - (미세) elf2flash: Done

Info: Using cable "USB-Blaster [USB-0]", device 1, instance 0x00

Info: Resetting and pausing target processor:

Info: OK

Info: Reading System ID at address 0x04012030:

Info: verified

Info: Processor data bus width is 32 bits

Info: Looking for EPCS registers at address 0x04011000 (with 32bit alignment)

Info:   Initial values: 0001703A 04C00074 9801483A 9CFFF804 983FFD1E 0000203A

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011100 (with 32bit alignment)

Info:   Initial values: 93000237 6300080C 603FFD26 90000335 A8000C26 03010004

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011200 (with 32bit alignment)

Info:   Initial values: 02C02004 002EE03A 00000F06 90000335 4000683A 0017883A

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011300 (with 32bit alignment)

Info:   Initial values: 003FD006 5280040C 501496FA 701CD07A 729CB03A 843FFFC4

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011400 (with 32bit alignment)

Info:   Initial values: 00000000 00000000 00000260 00000000 00000000 00000001

Info:   Valid registers found

Info: EPCS signature is 0x16

Info: EPCS identifier is 0x010216

Info: Leaving target processor paused

Error: No EPCS layout data - looking for section [EPCS-010216]

Error: Unable to use EPCS device

Error: Error code: 8 for command: nios2-flash-programmer "D:/Download/DE0_NANO/software/hello_world_0_bsp/flash/hello_world_0_epcs_flash_controller_0.flash" --base=0x4011000 --epcs --sidp=0x4012030 --id=0x0 --timestamp=1517632677 --device=1 --instance=0 '--cable=USB-Blaster on localhost [USB-0]' --program --verbose

Info: 2018. 2. 3 오후 1:47:52 - (정보) elf2flash: args = --input=D:/Download/DE0_NANO/software/hello_world_0/hello_world_0.elf --output=D:/Download/DE0_NANO/software/hello_world_0_bsp/flash/hello_world_0_epcs_flash_controller_0.flash --epcs --verbose

Info: 2018. 2. 3 오후 1:47:52 - (미세) elf2flash: Starting

Info: 2018. 2. 3 오후 1:47:52 - (보다 미세) elf2flash: Program Record: 3964 bytes destined for 0x4008000

Info: 2018. 2. 3 오후 1:47:52 - (보다 미세) elf2flash: Program Record: 724 bytes destined for 0x4009250

Info: 2018. 2. 3 오후 1:47:52 - (보다 미세) elf2flash: Start Record: 4008020

Info: 2018. 2. 3 오후 1:47:52 - (미세) elf2flash: Done

Info: Using cable "USB-Blaster [USB-0]", device 1, instance 0x00

Info: Resetting and pausing target processor:

Info: OK

Info: Reading System ID at address 0x04012030:

Info: verified

Info: Processor data bus width is 32 bits

Info: Looking for EPCS registers at address 0x04011000 (with 32bit alignment)

Info:   Initial values: 0001703A 04C00074 9801483A 9CFFF804 983FFD1E 0000203A

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011100 (with 32bit alignment)

Info:   Initial values: 93000237 6300080C 603FFD26 90000335 A8000C26 03010004

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011200 (with 32bit alignment)

Info:   Initial values: 02C02004 002EE03A 00000F06 90000335 4000683A 0017883A

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011300 (with 32bit alignment)

Info:   Initial values: 003FD006 5280040C 501496FA 701CD07A 729CB03A 843FFFC4

Info:   Not here: reserved fields are non-zero

Info: Looking for EPCS registers at address 0x04011400 (with 32bit alignment)

Info:   Initial values: 00000016 00000016 00000260 00000000 00000016 00000001

Info:   Not here: reserved fields are non-zero

Info: Leaving target processor paused

Error: No EPCS registers found: tried looking at addresses

Error:  0x04011000,

Error:  0x04011100,

Error:  0x04011200,

Error:  0x04011300 and

Error:  0x04011400

Error: Error code: 8 for command: nios2-flash-programmer "D:/Download/DE0_NANO/software/hello_world_0_bsp/flash/hello_world_0_epcs_flash_controller_0.flash" --base=0x4011000 --epcs --sidp=0x4012030 --id=0x0 --timestamp=1517632677 --device=1 --instance=0 '--cable=USB-Blaster on localhost [USB-0]' --program --verbose

B.5 "No EPCS Registers Found" Error

When you run the flash programmer to program an EPCS device, you get the error:

"No EPCS registers found: tried looking at addresses...."

B.5.1 Probable Cause

The flash programmer can connect with a Nios II JTAG debug module in the FPGA, but it cannot successfully find an EPCS device located at the specified base address.

>> 플래시 프로그래머는 FPGA의 Nios II JTAG 디버그 모듈과 연결할 수 있지만, 지정된 base address에서 EPCS 장치를 발견하는데 성공하지 못했다.

B.5.2 Suggested Actions

• Reconfigure the FPGA with a valid target design via JTAG using the Intel Quartus Prime programmer. If the FPGA is configured by another method, such as by a configuration controller, the pins that connect to the EPCS device might be disabled.

>> 쿼터스 프로그래머를 이용해 JTAG으로 FPGA를 재설정하라. 만약에 FPGA가 configuration controller 와 같은 다른 방법으로 설정된다면 EPCS 장치와 연결되는 핀들이 비활성화 되었을 수 도 있다.

• If you are using quartus_pgm --nios2 from the command line, ensure you specified the correct base address for your EPCS device. You can find the flash memory's base address in Platform Designer.

>> 커맨드 라인에서 quartus_pgm --nios2 을 사용한다면, EPCS 장치에 올바른 base address가 지정되었다 확인하라. Platform Deisigner의 플래시 장치에서 base address를 찾을 수 있다.

• Ensure that the EPCS device is correctly connected to the FPGA on the board. Verify the EPCS connection by running the "Test EPCS" routine in the "Memory Test" software template provided by the Nios II EDS. If the test fails, there is a problem with your memory connection. There are two places to look for the problem:

>> EPCS가 FPGA 보드에 정상적으로 연결되었는지 확인하라. Nios II EDS에 소프트웨어 템플릿으로 제공된 "Memory Test"안의 "Test EPCS"를 실행함으로서 EPCS 연결을 확인하라.

— The physical connection on your target board

— The pin assignments on the top-level FPGA design

• Use the Intel Quartus Prime Programmer to program the EPCS device directly via a JTAG download cable, and verify that the EPCS device successfully configures the FPGA.

• Run quartus_pgm --nios2 from the command line with the --epcs parameter. This command displays information about the flash memory in the EPCS device. For more information, refer to the "Using the Flash Programmer from the Command Line" chapter.

Related Links

Using the Flash Programmer from the Command Line on page 16

Using cable "USB-Blaster [USB-0]", device 1, instance 0x00

Resetting and pausing target processor: OK

Reading System ID at address 0x04012030: verified

Initializing CPU cache (if present)

OK

Downloading 02000000 ( 0%)

Downloading 02010000 (49%)

Downloading 020200A0 (94%)

Downloading 04008000 (99%)

Downloaded 129KB in 1.9s (67.8KB/s)

Verifying 02000000 ( 0%)

Verify failed between address 0x2000000 and 0x200FFFF

Leaving target processor paused

Downloading ELF Process failed

My problem is resolved now, I just changed the clock source of the EPCS CONTROLLER. The clock was driven from the system clock using a CLOCK BRIDGE.

Now, the clock is driven from a PLL OUTPUT ( the system and the EPCS CONTROLLER clocks are now independent).

Thank you Daixiwen & dsl for helping me.

DE0_Nano_SOPC DE0_Nano_SOPC_inst(

                      // the_epcs

                       .data0_to_the_epcs(EPCS_DATA0),

                       .dclk_from_the_epcs(EPCS_DCLK),

                       .sce_from_the_epcs(EPCS_NCSO),

                       .sdo_from_the_epcs(EPCS_ASDO),

                      // the_sdram

                       .zs_addr_from_the_sdram(DRAM_ADDR),

                       .zs_ba_from_the_sdram(DRAM_BA),

                       .zs_cas_n_from_the_sdram(DRAM_CAS_N),

                       .zs_cke_from_the_sdram(DRAM_CKE),

                       .zs_cs_n_from_the_sdram(DRAM_CS_N),

                       .zs_dq_to_and_from_the_sdram(DRAM_DQ),

                       .zs_dqm_from_the_sdram(DRAM_DQM),

                       .zs_ras_n_from_the_sdram(DRAM_RAS_N),

                       .zs_we_n_from_the_sdram(DRAM_WE_N),

                    );

module DE0_Nano_SOPC (

output wire [12:0] zs_addr_from_the_sdram,               //                         sdram_wire.addr

output wire [1:0]  zs_ba_from_the_sdram,                 //                                   .ba

output wire        zs_cas_n_from_the_sdram,              //                                   .cas_n

output wire        zs_cke_from_the_sdram,                //                                   .cke

output wire        zs_cs_n_from_the_sdram,               //                                   .cs_n

inout  wire [15:0] zs_dq_to_and_from_the_sdram,          //                                   .dq

output wire [1:0]  zs_dqm_from_the_sdram,                //                                   .dqm

output wire        zs_ras_n_from_the_sdram,              //                                   .ras_n

output wire        zs_we_n_from_the_sdram,               //                                   .we_n

output wire        altpll_sys,                           //                         c0_out_clk.clk

output wire        altpll_sdram,                         //                      altpll_sys_c1.clk

output wire        altpll_io,                            //                         c2_out_clk.clk

output wire        altpll_sys_c3_out,                    //                      altpll_sys_c3.clk

output wire        altpll_adc,                           //                         c4_out_clk.clk

output wire        locked_from_the_altpll_sys,           //          altpll_sys_locked_conduit.export

output wire        phasedone_from_the_altpll_sys,        //       altpll_sys_phasedone_conduit.export

input  wire        in_port_to_the_g_sensor_int,          //   g_sensor_int_external_connection.export

output wire        dclk_from_the_epcs,                   //                      epcs_external.dclk

output wire        sce_from_the_epcs,                    //                                   .sce

output wire        sdo_from_the_epcs,                    //                                   .sdo

input  wire        data0_to_the_epcs,                    //                                   .data0

);

DE0_Nano_SOPC_sdram sdram (

.clk            (altpll_sys),                                            //   clk.clk

.reset_n        (~rst_controller_002_reset_out_reset),                   // reset.reset_n

.az_addr        (sdram_s1_translator_avalon_anti_slave_0_address),       //    s1.address

.az_be_n        (~sdram_s1_translator_avalon_anti_slave_0_byteenable),   //      .byteenable_n

.az_cs          (sdram_s1_translator_avalon_anti_slave_0_chipselect),    //      .chipselect

.az_data        (sdram_s1_translator_avalon_anti_slave_0_writedata),     //      .writedata

.az_rd_n        (~sdram_s1_translator_avalon_anti_slave_0_read),         //      .read_n

.az_wr_n        (~sdram_s1_translator_avalon_anti_slave_0_write),        //      .write_n

.za_data        (sdram_s1_translator_avalon_anti_slave_0_readdata),      //      .readdata

.za_valid       (sdram_s1_translator_avalon_anti_slave_0_readdatavalid), //      .readdatavalid

.za_waitrequest (sdram_s1_translator_avalon_anti_slave_0_waitrequest),   //      .waitrequest

.zs_addr        (zs_addr_from_the_sdram),                                //  wire.export

.zs_ba          (zs_ba_from_the_sdram),                                  //      .export

.zs_cas_n       (zs_cas_n_from_the_sdram),                               //      .export

.zs_cke         (zs_cke_from_the_sdram),                                 //      .export

.zs_cs_n        (zs_cs_n_from_the_sdram),                                //      .export

.zs_dq          (zs_dq_to_and_from_the_sdram),                           //      .export

.zs_dqm         (zs_dqm_from_the_sdram),                                 //      .export

.zs_ras_n       (zs_ras_n_from_the_sdram),                               //      .export

.zs_we_n        (zs_we_n_from_the_sdram)                                 //      .export

);

DE0_Nano_SOPC_epcs epcs (

.clk           (clk_50),                                                           //               clk.clk

.reset_n       (~rst_controller_001_reset_out_reset),                              //             reset.reset_n

.address       (epcs_epcs_control_port_translator_avalon_anti_slave_0_address),    // epcs_control_port.address

.chipselect    (epcs_epcs_control_port_translator_avalon_anti_slave_0_chipselect), //                  .chipselect

.dataavailable (),                                                                 //                  .dataavailable

.endofpacket   (),                                                                 //                  .endofpacket

.read_n        (~epcs_epcs_control_port_translator_avalon_anti_slave_0_read),      //                  .read_n

.readdata      (epcs_epcs_control_port_translator_avalon_anti_slave_0_readdata),   //                  .readdata

.readyfordata  (),                                                                 //                  .readyfordata

.write_n       (~epcs_epcs_control_port_translator_avalon_anti_slave_0_write),     //                  .write_n

.writedata     (epcs_epcs_control_port_translator_avalon_anti_slave_0_writedata),  //                  .writedata

.irq           (irq_synchronizer_004_receiver_irq),                                //               irq.irq

.dclk          (dclk_from_the_epcs),                                               //          external.export

.sce           (sce_from_the_epcs),                                                //                  .export

.sdo           (sdo_from_the_epcs),                                                //                  .export

.data0         (data0_to_the_epcs)                                                 //                  .export

);

unsaved_epcs_flash_controller_0 epcs_flash_controller_0 (

.clk        (clk_clk),                                                                //               clk.clk

.reset_n    (~rst_controller_reset_out_reset),                                        //             reset.reset_n

.reset_req  (rst_controller_reset_out_reset_req),                                     //                  .reset_req

.address    (mm_interconnect_0_epcs_flash_controller_0_epcs_control_port_address),    // epcs_control_port.address

.chipselect (mm_interconnect_0_epcs_flash_controller_0_epcs_control_port_chipselect), //                  .chipselect

.read_n     (~mm_interconnect_0_epcs_flash_controller_0_epcs_control_port_read),      //                  .read_n

.readdata   (mm_interconnect_0_epcs_flash_controller_0_epcs_control_port_readdata),   //                  .readdata

.write_n    (~mm_interconnect_0_epcs_flash_controller_0_epcs_control_port_write),     //                  .write_n

.writedata  (mm_interconnect_0_epcs_flash_controller_0_epcs_control_port_writedata),  //                  .writedata

.irq        (irq_mapper_receiver1_irq),                                               //               irq.irq

.dclk       (),                                                                       //          external.export

.sce        (),                                                                       //                  .export

.sdo        (),                                                                       //                  .export

.data0      ()                                                                        //                  .export

);

module unsaved (

input  wire       clk_clk,                          //                       clk.clk

output wire [7:0] pio_0_external_connection_export, // pio_0_external_connection.export

input  wire       reset_reset_n                     //                     reset.reset_n

);

module unsaved (

input  wire        clk_clk,                          //                       clk.clk

output wire        epcs_dclk,                        //                      epcs.dclk

output wire        epcs_sce,                         //                          .sce

output wire        epcs_sdo,                         //                          .sdo

input  wire        epcs_data0,                       //                          .data0

output wire [7:0]  pio_0_external_connection_export, // pio_0_external_connection.export

input  wire        reset_reset_n,                    //                     reset.reset_n

output wire [12:0] sdram_addr,                       //                     sdram.addr

output wire [1:0]  sdram_ba,                         //                          .ba

output wire        sdram_cas_n,                      //                          .cas_n

output wire        sdram_cke,                        //                          .cke

output wire        sdram_cs_n,                       //                          .cs_n

inout  wire [31:0] sdram_dq,                         //                          .dq

output wire [3:0]  sdram_dqm,                        //                          .dqm

output wire        sdram_ras_n,                      //                          .ras_n

output wire        sdram_we_n                        //                          .we_n

);

Error (13076): The node has multiple drivers due to the always-enabled I/O buffer

Operating Conditions

When Cyclone IV devices are implemented in a system, they are rated according to a set of defined parameters. To maintain the highest possible performance and reliability of Cyclone IV devices, you must consider the operating requirements described in this chapter. Cyclone IV devices are offered in commercial, industrial, extended industrial and, automotive grades. Cyclone IV E devices offer –6 (fastest), –7, –8, –8L, and –9L speed grades for commercial devices, –8L speed grades for industrial devices, and –7 speed grade for extended industrial and automotive devices. Cyclone IV GX devices offer –6 (fastest), –7, and –8 speed grades for commercial devices and –7 speed grade for industrial devices.
